American Megatrends StorTrends 3200n Specifications

3U NAS Storage Appliance
HigHligHtS
>
4, 8, or 16 TB 3 U NAS storage appliance
> 16 hot-swappable SAS / SATA Drives
> Cost-effective and scalable
> Network Teaming
>
Universal UPS Support
> Failover / Failback
> SATA / SAS support with hot swap
> Advanced Snapshot
- Redirect on Write (ROW)
- Up to 1,022 Snapshots (R/O and
R/W) per volume
- Up to 2,048 Snapshots per box
- Rollback from any snapshot
- Random snapshot deletion
>
Volume Replication (Snapshot-assisted)
> WAN-Optimization Data Service (WDS)
- Deduplication, Compression, Encryption
and Link Optimization
>
Uses existing Ethernet infrastructure
> Hardware RAID support:
- RAID levels 0, 1, 5, 6, 10, 50, 60
- Online capacity expansion
- Online RAID level migration
- Multiple arrays (same type) per drive
- Read with write-back caching
- Global & dedicated hot-spare
> Supports major file transfer protocols
T
tor rends
w ww.a m i . com
The StorTrends 3200n is an affordable 3U, high-density rack-mount
®
Network Attached Storage (NAS) appliance, perfect for workgroups or
departments. It provides a reliable way to manage, store and protect valuable
business data without complexity. Easy to install, the StorTrends 3200n
enables an administrator to coordinate all functions relating to discovery,
management and planning for future storage growth.
StorTrends® data storage products
provide true enterprise-level features to
small and mid-size business (SMB) users,
and the StorTrends 3200n NAS appliance
is no exception. It makes an ideal
alternative to traditional Direct Attached
Storage (DAS) environments and is
perfect for rapidly growing workgroup or
departmental data storage, because of its
ability to centralize file data storage from
Windows®, UNIX, Linux and Mac® clients
across an existing Ethernet network
and ensure its safety and accessibility.
Network teaming support also ensures
load balancing across the dual Ethernet
ports for exceptional data throughput.
The StorTrends 3200n offers sixteen
hot-swappable drive bays with advanced
SATA and SAS support for multiple
options in performance, capacity and cost,
as well as highly distinguishing software
features in its StorTrends iTX Data Storage
software, preinstalled in each appliance.
The 3200n also has the potential for
significant capacity expansion; when
used as the storage head for a chain of up
to three StorTrends® 3201j JBOD units,
storage capacity can be increased to a
massive 64 TB of storage space.
Volume replication with StorTrends
iTX allows data to be stored on multiple
StorTrends appliances at multiple local
and remote sites, for high availability
and disaster recovery. The Asynchronous
Replication module bundles I/Os and
sends them to the remote server,
boosting network utilization efficiency
© 2008 American Megatrends Inc. - Specifications subject to change without notice
Data Sheet
06 18 2008
and reducing bandwidth cost.
combined with the revolutionary WDS
(WAN-Optimization Data Service) feature,
the 3200n can leverage a "triple-threat" of
data deduplication, data encryption and
link optimization to reduce bandwidth
usage exponentially over conventional
replication speeds.
One of the most powerful features of the
StorTrends 3200n is its Advanced Snapshot
capability with Redirect on Write (ROW)
technology. Administrators can schedule
point-in-time snapshots, and manually
review, rollback and mount any snapshot
in the repository in under a second – for the
power and flexibility to recover lost data
quickly and with precision, just moments
after a catastrophe. The StorTrends 3200n
also includes RAID levels 5 and 6 to bolster
its data protection capability even further.
Additionally, Smart UPS support enables
the appliance to seamlessly transition to
UPS power in the event of a power failure
and initiate a graceful shutdown, while
automatically switching the RAID cache to
write-through mode.
Finally, integrated
management with AMI's ManageTrends™
interface provides a simple configuration
wizard to configure volumes, and logical
disks, and provides 100% control of the
discovery and management of multiple
StorTrends appliances. ManageTrends also
provides event management, a detailed
analysis of enterprise-wide storage usage
and storage server availability reporting.
When
web-based
