American Megatrends StorTrends 3200 Overview

*Each SAS Drive Carrier has two LEDs:
Top LED
Blue/ On = Drive Activity
Bottom LED
Red/ On = Drive Failure
8
2
3
4
1
BACK
1

Power Supply Modules

-LED Description
Red with constant beep = Power Supply Failure
(if system is not muted) Failed Power Supply LED turns AMBER
Power Failure
Power Supply LED is OFF
(check your UPS)
Green = Power Supply DC On
Amber = Power Supply Standby
No Light = No AC Power
2

Mouse/ Keyboard Ports

USB Ports

3

COM1 Port

4

Parallel Port

5

VGA Port

6

PCI Expansion Slots

7

MOTHERBOARD

1 Front Panel Control Flat Ribbon Cable
2 Fan 1, Fan 2, Fan 3 , Fan 5 and Fan 6 Cables
3 IDE1 Flat Ribbon Cable
4 JCOM2 Cable
5 USB 2/3 Cable
6 JL1 Chassis Intrusion Cable
7 4-Pin PWR, 24-Pin ATX PWR and 8-Pin PWR Power Cables
8 SMBPS Cable
9 SAS RAID Controller
Jumper Description
10 J7 Debug Only
11 J27 & J28 12C Bus to PCI-X/ PCI-E Slots
12 J3P 3rd PWR Failure Detect
13 JCF1 Compact Card Master/ Slave Select
14 JPG1 VGA Enable
15 JPL1/ JPL2 GLAN1/ GLAN2 Enable
16 JPS1 SAS Controller Enable Pins
17 JWD Watch Dog Pins
Copyright American Megatrends Inc.
Overview
9
CPU2
Fan3
Fan2
Fan1
6
5
7
8

Ethernet Ports

-LED Description
Left LED
On/ Flashing = Activity
Right LED
Off = No Connection/ 10 Mbps
Green = 100 Mbps
Orange = 1 Gbps
Default Setting
Closed (Normal)
Open (Disabled)
Open (Disabled)
Closed (Master)
Pins 1-2 (Enable)
Pins 1-2 (Enable)
2-3 (Disable)
1-2 (Reset)
Fan5
10
Fan4
NIC2
NIC1
11
CPU1
5
1
2
14
17
9
15
4
Please refer to the StorTrends® 3200 User's Guide for detailed information.

FRONT/ INSIDE

FRONT
1 SAS Drive Bays (0 - 15)
2 Slim DVD-ROM Drive
Dual USB Ports
3
4 COM Port
5 Control Panel and System LEDs
6 System Reset Button
7 Main Power Button
INSIDE
6 7
8 SAS Backplane
9 Chassis Intrusion
10 SAS RAID Controller
Redundant Power Supplies
11
Fan (5), CPU (2), NIC (2)
5
2 3 4 6 8
7 8
BANK4
BANK3
BANK2
BANK1
11 6
Power Failure
Red/ On = Power Module Failure
Overheat/ Fan Failure
Red/ On = Overheating/ Fan Failure
NIC2
Green/ Blinking = LAN Activity
Green/ On = LAN Link exists
NIC1
Green/ Blinking = LAN Activity
Green/ On = LAN Link Exists
HDD
Amber/ On = Activity
Power
Green/ On = Power On
7
12 2
2
1
CPU1
2
2
CPU2
13
3
16
5 10
