ASSEMBLY INSTRUCTIONS
9. Place the charcoal grate (G) on the support rails
inside the smoker body (A). Place the charcoal
chamber (F) directly onto the charcoal grate (G).
10. Place the water bowl support (D) on the bottom
bracket inside the smoker body (A) as shown.
Place the water bowl (E) on the water
bowl support (D).
9
10
10
A
F
G
A
D
E
