Enlarged version
SpeedDome
Camera Dome Indoor
Pendant Mounting
Structure

Installation Guide

FOR INDOOR USE ONLY!
Figure 1. Optima LT camera dome (in housing)

About this Guide

This guide explains how to prepare the camera
dome for installation to an indoor mounting
structure and assumes that the mounting structure
is in place and that data and power cables have
been pulled to the installation site.
This guide does not explain how to install the
mounting structure. For this information, see
information shipped with the mounting structure.
© Sensormatic 2004
SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE
INSTALLATION GUIDE
Optima LT
®
About the Indoor Housing
The indoor housing (Figure 1) is used to attach the
SpeedDome Optima LT camera dome to an indoor
mounting structure. This housing can attach to
mounting structures shown in Table 1.
Table 1. Indoor mounting structures
RHOPN
Pendant Mount
RHIUIBM
I-Beam Mount
RHOSW/RHOLW
Short/Long
Wall Mount
RHOWCA
Corner Mount
RHOWPA
Pole Mount
ROENDC
End Cap
1 of 10
8200-0181-04, REV. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpeedDome Optima LT and is the answer not in the manual?

Questions and answers

Related Manuals for American Dynamics SpeedDome Optima LT

Summary of Contents for American Dynamics SpeedDome Optima LT

  • Page 1: Installation Guide

    INSTALLATION GUIDE About the Indoor Housing The indoor housing (Figure 1) is used to attach the SpeedDome Optima LT camera dome to an indoor mounting structure. This housing can attach to mounting structures shown in Table 1. Table 1. Indoor mounting structures...

  • Page 2: Warnings And Cautions

    DO NOT install this housing in hazardous areas where highly combustible or explosive products are stored or used. SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE WARNING! EU power requirements: This product runs on 24Vac. In the EU, it is intended to be powered from a Limited Power Source.

  • Page 3: Before You Begin

    Data cables: Table 2 shows cable requirements for SensorNet and Manchester networks. For more information about communication protocols and cable networks, see Communication Protocols and Cable Networks, 8000-2573-19. SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE Table 2. Data cable requirements SensorNet Cable type...

  • Page 4: Save Packaging Material

    RJ6SN Universal Transformer 0300-0914-01 Universal Transformer 0300-0914-03 SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE SensorNet Line Termination SensorNet communication protocols require line termination. Accessing slide switch S1 through the hole in the top of the dome, terminate the dome furthest from the video controller or junction box by moving the switch to the “terminated”...
  • Page 5 Figure 2. Screws and latches securing dome assembly to housing Screw (3) Latch (3) SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE Figure 3. Optima LT connections and switches 0404-0103-01 0400-1402-01/-02 0101-0075-01/-02...
  • Page 6 SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE c. Use the drive (taped inside bubble) to tighten the four tamper-proof screws on the bubble assembly.

  • Page 7: Troubleshooting

    2. Check the iris setting. Open iris or set to auto iris. 3. If the problem cannot be corrected, send the dome to a repair center. SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE Video rolls when switching cameras. Perform V-phase adjustment at the controller.

  • Page 8: Specifications

    Signal/Noise ...48dB (typical) Minimum illumination ...1.5 lux (20 IRE) Gain control ...Automatic (AGC) SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE White balance ... Through the Lens (TTL) NTSC version: Pickup device... 768 (H) x 494 (V) pixels Scanning ...

  • Page 9: Electrical Specifications

    • PTC resettable fuse protects transformer • TVS rated at 5.6V, 40A, 0.1 Joules, 8/20µs impulse SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE EIA-422 comm ...Gas discharge tube impulse rated at: SensorNet Communications Address range...0 to 255 Network distance...1 km Maximum loads ...32 per node...

  • Page 10: Mechanical Specifications

    SPEEDDOME OPTIMA LT INDOOR PENDANT MOUNTING STRUCTURE INSTALLATION GUIDE Other Declarations Thank you for using American Dynamics products. We support our products through an extensive and worldwide network of dealers. The dealer, through whom you originally purchased this product, is your point of contact if you have a need for service or support.
