MegaPower
Operator's Guide
Figure 1. MegaPower 3200 Video-Matrix Closed-Circuit Television (CCTV) System
Cameras Cameras
Video
Monitors
Keyboards

About this Guide

This Operator's Guide provides information about
operating the MegaPower 3200 video-matrix
closed-circuit television (CCTV) system.
Another related document is the Administrator's
Guide, 8200-0421-03.
If you need assistance...
Contact Technical Support.

About the Product

The MegaPower CPU (Central Processing Unit) is
the control unit for the MegaPower 3200 video-
matrix CCTV switcher. It enables the setup and
control of cameras, monitors, users, alarms, video
recording, and data communications.
© 2008 Sensormatic Electronics Corp.
MEGAPOWER CPU
OPERATOR'S GUIDE
CPU
®
Video
Matrix
Switcher Bay
ADDL*
MegaPower CPU
The MegaPower CPU (Figure 2) consists of the
following major modules:
• MPU (Multiple Purpose Unit): controls system
operation, provides Ethernet and video data
connections, image capture, and input power.
• Port Module: provides RS-232 communications
ports, high-speed data lines, and alarm relay
connections.
Figure 2. MegaPower CPU
MPU
1 of 20
Data
Protocol
Devices
Data
*ADDL = AD Data Line
Port Module
