Appendix B: Keyboard Commands for ADCC1100

The table below explains the control functions for cameras using the ADCC1100 keyboard. For further
information, refer to American Dynamics ControlCenter
Instructions, ADCC1100-HB-2.
Figure 6. ADCC1100 keyboard layout
Alphanumeric keys
Clear
Monitor
Camera
Close iris
Open iris
Focus far
Focus near
Increment camera
Decrement camera
Note: The LCD display shown here is generated by an Operator Smart Card. A Supervisor/Admin Smart Card
generates a different display that changes the middle tab to "Program Mode" and presents a different set of
icons.

Operator Functions

Function
Logon—Mode 1
Logon—Mode 2
Logon—Mode 3
Select Monitor
Call Camera
Pan/tilt Camera
Zoom Camera
Focus Camera
Adjust Iris
Auto Iris
Camera Flip
Call Preset
Run Tour
MEGAPOWER CPU
OPERATOR'S GUIDE
Soft keys
LCD display
Tab keys
Actions
-Insert smart card
-Insert smart card
-Insert smart card
-enter PIN -press Enter soft key
-Enter monitor # -press MONITOR
-Enter camera # -press CAMERA
-Move joystick left/right or forward/backward
-Twist joystick clockwise to zoom in or counterclockwise to zoom out
-Press FOCUS FAR
-Press iris OPEN or CLOSE
-Press OPERATOR tab key
-press AUTO IRIS soft key
-Press OPERATOR tab key
-press FLIP soft key
-Call camera -enter the Preset #
-Select monitor -enter Tour #
™
ADCC1100 Keyboard Installation and Operation
Joystick
-enter PIN -press Enter soft key
-enter User ID -press Enter soft key
key or FOCUS NEAR
to brighten or darken picture
-press Next
-press Next
-press PRESET
-press Run
11 of 20
LCD display
soft key
soft key
soft key in Operator tab
soft key
8200-0421-02, REV. D
