- Page 1 068-1576-4 48 x 72" (122 x 183 cm) Tall Cabinet INSTRUCTION IMPORTANT MANUAL Please read this manual carefully before assembling and Due to continuing improvements, using this product, and save it for reference. the actual product may differ slightly...
-
Page 2: Table Of Contents
068-1576-4 I contact us 1-800-689-9928 TABLE OF CONTENTS SAFETY MAINTENANCE EXPLODED VIEW / PARTS LIST ASSEMBLY INSTRUCTIONS COORDINATING PRODUCTS WARRANTY NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at: 1-800-689-9928. -
Page 3: Safety
SAFETY To reduce the risk of serious injury, read and follow the safety instructions below before assembling and using this product. This product is intended for indoor use only. This product is not designed for commercial nor industrial usage. Keep the product on level surfaces. The product could become unstable and it may tip over if stored or moved on an uneven surface, which may cause personal injury, death or product damage. -
Page 4: Exploded View / Parts List
068-1576-4 I contact us 1-800-689-9928 EXPLODED VIEW / PARTS LIST Description Part No. Qty. Description Part No. Qty. Adjustable foot Safety strap 314230 313066 Safety bracket 212591 Key (001-010) 304196 M6 x 40 hex Right door and middle... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS TOOLS REQUIRED FOR ASSEMBLY • Hex Wrench (23) • Power Drill (not included) • Cross-head Screwdriver (not included; magnetic is preferable) • Measuring Tape (not included) NOTE: Assemble on a flat surface. A piece of cardboard is recommended to keep the product from being scratched during assembly. - Page 6 068-1576-4 I contact us 1-800-689-9928 STEP 2 ATTACH THE TOP PANEL Attach the top panel (22) to the side panels (8 & 21) with four M6 x 16 hex socket head • screws (6) on the top left and right corners. Insert the screws by hand. DO NOT tighten.
- Page 7 STEP 4 INSTALL THE ADJUSTABLE FEET Install the adjustable feet (12) to the bottom. Tighten securely with sixteen M6 x 16 hex socket head screws (6). Back Front STEP 5 SCREW THE FRONT OF THE CABINET Stand up the cabinet. •...
- Page 8 068-1576-4 I contact us 1-800-689-9928 STEP 6 CONNECT THE CABINET TO THE WALL This step must be carried out accordingly. Failure to do so may result in personal injury. The M6 x 40 hex tapping bolts (3) should be drilled into the stud of the wall.
- Page 9 STEP 7 ATTACH THE RIGHT AND MIDDLE DOORS • Screw two M4 x 12 cross-head pan head screws (11) into the top and bottom holes on the inner side of the right side panel (8). DO NOT screw to the end first. Position the right door and middle door (14) to the right side panel (8) by sliding the gourd holes on •...
- Page 10 068-1576-4 I contact us 1-800-689-9928 STEP 8 ATTACH THE ROLLER Attach the bottom roller (15) to the bottom of the middle door with two M6 x 16 hex socket • head screws (6). Make sure the cylindrical part falls into the bottom track. Tighten securely.
- Page 11 STEP 10 ATTACH THE SHELVES NOTE: One of the shelves should be placed in the centre position so as to use the locking mechanism. At the same time, magnet holes on this shelf should be faced to the front to install the magnets. Insert the twelve shelf brackets (20) into the slots on the side panels (8 &...
-
Page 12: Coordinating Products
068-1576-4 I contact us 1-800-689-9928 COORDINATING PRODUCTS This product coordinates well with the units below to offer our best storage solutions. They can be combined into various combinations to meet different storage requirements. 28" (71 cm) 28" (71 cm) Base... -
Page 13: Warranty
This product is not guaranteed if used for industrial or commercial purposes. Made in China. Imported by Mastercraft Canada Toronto, Canada M4S 2B8...
