size:210x285mm
model no. 068-1224-2
BASE CABINET
Please read this manual carefully before installing this
cabinet and save it for reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 068-1224-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MasterCraft 068-1224-2

  • Page 1 068-1224-2 BASE CABINET Please read this manual carefully before installing this cabinet and save it for reference.
  • Page 3: Warranty

    SAFETY GUIDELINES PARTS LIST ASSEMBLY INSTRUCTIONS MASTERCRAFT LINE WARRANTY...
  • Page 5 PARTS LIST Description Qty. Description Qty. Solid Hardwood Top Wheel With Brake Front Frame Wheel W/O Brake Back Frame M8 x 18L Screw Left Side Panel M8 Washer Right Side Panel M4 x 8L Screw Middle Shelf M4 x 8L Screw Base Panel Back Corner Protector Middle Panel...
  • Page 6 068-1224-2 contact us 1-866-221-8146 Small Drawer (10) Large Drawer (11)
  • Page 7 Step 1: Fig A Open both boxes, locate and remove the cardboard box containing the Solid Hardwood Top (1). Set the other parts to the side. When assembling this item, place the Solid Hardwood Top upside down on the cardboard to avoid scratching the top surface (see Fig A).
  • Page 8 068-1224-2 contact us 1-866-221-8146 Fig C Step 3: Install Right Side Panel (5). Attach Right Side Panel (5) to Back Frame (3), making sure the "Top" of Right Side Panel (5) is on the Solid Hardwood Top (1). Use 3 pcs of Screw (16) and Screwdriver (21) to fasten (see Fig C).
  • Page 9 Step 5: Install Left Side Panel (4). Fig E Attach Left Side Panel (4) to Back Frame (3), making sure the "Top" of Left Side Panel (4) is on the Solid Hardwood Top (1). Use 3 pcs of Screw (16) and Screwdriver (21) to fasten (see Fig E).
  • Page 10 068-1224-2 contact us 1-866-221-8146 Fig G Step 7: Install the Base Panel (7) & Wheel (12) and (13). A: Fit the Bottom Panel (7) between the Back Frame (3) and Front Frame (2) as shown ins Fig G, line up the screw holes and use Screw (16) to tighten it.
  • Page 11 Fig I Step 9: Install the Back Corner Protector (18) and Left & Right Push Bar (20 &19) and Magnet (26). A: Attach the Back Corner Protector (18) to the left and right side of the Back Frame (3), and use 12 pcs Screw (16) and Screwdriver (21) to tighten.
  • Page 13 Step 14: Place the Drawers. Fig P A: Pull out the sliders completely, then attach the drawer to the sliders. Make sure the square holes on the drawer side panels are lined up, and the drawer is hooked onto the sliders completely (see Fig P and Fig Q).
  • Page 14 068-1224-2 contact us 1-866-221-8146 Step 15: Install the Middle Shelf (6). Fig S Place the Middle Shelf (6) in the unit at the desired height and ensure that all four corners are secured on the hooks on the Front and Back Frame (see Fig S).
  • Page 15 Model no. 068-0667-4 Model no. 068-0558-4 Model no. 068-1221-8 MC TALL STORAGE CABINET MC BASE CABINET MC STORAGE CABINET Model no. 068-6099-0 Model no. 068-7305-4 Model no. 068-1226-8 MC WORKBENCH MC ROLLING CABINET MC WALL CABINET Model no. 068-7306-2 Model no. 068-7428-2 Model no.
  • Page 16 1-866-221-8146 one (1) This Mastercraft product carries a three (3) year replacement warranty against defects in workmanship and materials. Mastercraft Canada agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase.
  • Page 19 CONSIGNES DE SÉCURITÉ LISTE DES PIÈCES CONSIGNES D’ASSEMBLAGE GAMME MASTERCRAFT GARANTIE...
  • Page 20 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Le présent guide contient des renseignements relatifs à la SÉCURITÉ ET À LA PRÉVENTION DES PROBLÈMES AVEC LE MATÉRIAL. Il est très important de lire attentivement et de bien comprendre ce guide avant d’utiliser le produit. Les symboles ci-dessous servent à indiquer cette information.
  • Page 21 Plan de travail en bois massif Roulette verrouillable Châssis avant Roulette non verrouillable Châssis arrière Vis M8 x 18L Panneau latéral gauche Rondelle M8 Panneau latéral droit Vis M4 x 8L Tablette centrale Vis M4 x 8L Panneau inférieur Protecteur d'angle arrière Panneau central Barre de poussée droite Porte...
  • Page 22 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Petit tiroir (10) Grand tiroir (11)
  • Page 24 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Fig C Étape 3 : Installez le panneau latéral droit (5). Fixez le panneau latéral droit (5) au châssis arrière (3), en veillant à ce que le dessus du panneau latéral droit (5) soit aligné au plan de travail en bois massif (1).
  • Page 25 Étape 5 : Installez le panneau latéral gauche (4). Fig E Fixez le panneau latéral gauche (4) au châssis arrière (3), en veillant à ce que le dessus du panneau latéral gauche (4) soit aligné au plan de travail en bois massif (1). Utilisez trois vis (16) et le tournevis (21) pour serrer (Fig E).
  • Page 26 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Fig G Étape 7 : Fixez le panneau inférieur (7) aux roulettes (12 et 13). A : Insérez le panneau inférieur (7) entre le châssis arrière (3) et le châssis avant (2) comme illustré, alignez les trous de vis et utilisez le tournevis (16) pour serrer.
  • Page 27 Étape 9 : Installez les protecteurs d'angle Fig I arrière (18), les barres de poussée gauche et droite (20 et 19) et les aimants (26). A : Fixez les protecteurs d'angle arrière (18) aux côtés gauche et droit du châssis arrière (3) à l'aide de douze vis (16) et du tournevis (21).
  • Page 29 Étape 14 : Placez les tiroirs. Fig P A : Sortez complètement les coulisses, puis fixez le tiroir aux coulisses. Assurez-vous que les trous carrés des panneaux latéraux des tiroirs sont alignés et que les tiroirs sont complètement accrochés aux coulisses (Fig P et Q).
  • Page 30 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Étape 15 : Installez la tablette centrale (6). Fig S Placez la tablette centrale (6) dans le meuble, à la hauteur désirée, et vérifiez que les quatre angles sont retenus par les crochets des châssis avant et arrière (Fig S).
  • Page 31 N° de modèle : 068-0667-4 N° de modèle : 068-0558-4 N° de modèle : 068-1221-8 GRANDE ARMOIRE MC ARMOIRE MC ARMOIRE HAUTE MC N° de modèle : 068-6099-0 N° de modèle : 068-7305-4 N° de modèle : 068-1226-8 ÉTABLI MC ARMOIRE SUR ROULETTES MC ARMOIRE MURALE MC N°...
  • Page 32 Communiquez avec nous au : 1-866-221-8146 068-1224-2 Cet article Mastercraft comporte une garantie de remplacement de trois (3) ans contre les défauts de fabrication et de matériau(x). Mastercraft Canada consent à remplacer l’article défectueux sans frais au cours de la période de garantie convenue lorsqu’il est retourné, accompagné de la preuve d’achat, par l’acquéreur initial.
