Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

See warranty card of your country.

5. Before starting the equipment

Connecting to earth
The housing is allowed to be connected to earth
in order to discharge static electricity. To do this,
connect one end of a cable to the earth connec-
tion on the generator (Fig. 3/4) and the other end
to an external earth (for example an earthing rod).

6. Operation

Notice! Before using the appliance for the fi rst
time the tank must be fi lled with petrol.
Add aprox 0,6 ltrs of oil to the oil deposite.
•
Check the fuel level and top it up if necessary
•
Make sure that the generator has sufficient
ventilation
•
Make sure that the ignition cable is secured to
the spark plug
•
Inspect the immediate vicinity of the gene-
rator
•
Disconnect any electrical equipment which
may already be connected to the generator
6.1 Starting the engine
•
Open the petrol cock (13) by turning it down
•
Move the ON/OFF switch (10) to position
„ON" with the key.
•
Move the choke lever (11) to position
•
Start the engine with the reversing starter (12)
by pulling the handle forcefully. If the engine
does not start, pull the handle again.
•
Push the choke lever (11) back again after
the engine has started.
Anl_SA_TC_PG_1100_SPK8.indb 14 Anl_SA_TC_PG_1100_SPK8.indb 14
GB
Warning!
When starting with the reserve starter, the motor
may recoil suddenly as it starts up, resulting in
hand injuries. Wear protective gloves when star-
ting the equipment.
6.2 Connecting consumers to the generator
•
Connect the appliance you want to use to the
230 V~ socket. (Fig. 1/ pic. 3)
Notice! This socket may be loaded continuously
(S1) with 900W and temporarily (S2) for a maxi-
mum of 3 minutes with 1100W. The generator is
suitable for 230 V~ a.c. appliances.
•
Do not connect the generator to the
household network as this may result in da-
mage to the generator itself or to other electri-
cal appliances in your home.
Note: Some electrical appliances (power jigsaws,
drills, etc.) may have a higher level of power con-
sumption when used in diffi cult conditions.
6.3 Switching off the engine
•
Before you switch off the generator, allow it
to run briefly with no consumers so that it can
„cool down"
•
Move the ON/OFF switch (10) to position
„OFF" with the key.
•
Close the petrol cock
Notice! The generator is equipped with an over-
load cut-out.
This shuts down the socket (3). You can reactivate
the socket (5) by pressing the overload cut-out
(3).
Notice! If this happens, reduce the electric power
you are taking from the generator or remove any
defective connected appliances.
.
