Summary of Contents for cinetto LIBRO MAXI PS11
- Page 1 CINETTO LIBRO MAXI (PS11) Assembly instructions...
- Page 2 Italiano English Français Tutte le misure espresse in questo opuscolo All dimensions in this leafl et are stated in Toutes les mesures indiquées dans cette bro- sono in millimetri. millimeters. chure sont en millimètres. ATTENZIONE WARNING AVERTISSEMENT Non utilizzare spray ed oli anti frizione o Do not use any anti-friction oil or grease or Ne pas utiliser de spray ni d’huile anti frot- sblocca fi...
-
Page 3: Cabinet Requirements
Cabinet Requirements Top Height Clearance = Min 60mm Bottom Height Clearance = Min 60mm Bottom Depth Clearance = Min 75mm... - Page 4 Door Calculations WA = (WV + 2S - Total gaps) / total panels Maximum carcase/panel overlay is 24mm WA = Door width WV = Internal Carcase width S = Carcase overlay...
- Page 5 Lavorazioni richieste per le ante Working requests for the doors Working requests for the doors Usinage nécessaire pour les portes Verarbeitungsanforderungen für die Türen Laboreo necesario para las puertas 11,5 Ø40 MAX 500 Ø40 Top Drilling and Routing: • 2x 40mm cup holes •...
- Page 6 Anta regolabile Vertical adjustment of the door Vertical adjustment of the door option Optional Réglage vertical de la porte Vertikale Türverstellung Ajuste vertical de la puerta ±3 mm 11,5 Ø4x10 13,5 MAX 500...
-
Page 7: Istruzioni Di Montaggio
Istruzioni di montaggio Assembly instructions Assembly instructions Instructions de montage Montageanleitungen Instrucciones de ensamblaje Fissare il binario Fix the upper rail Fixer le rail supérieur Befestigen Sie die Fijar la guía superior superiore al to the wardrobe au meuble selon le obere Schiene an den al mueble según Fix the upper rail to the wardrobe according to your choice: 1a, 1b. - Page 8 Fissare il binario Fix the lower rail Fixer le rail inférieur Befestigen Sie die Fijar la guía inferior al inferiore al to the wardrobe au meuble selon le untere Schiene an mueble según vuestra mobile secondo la according to your mode choise: 2a, 2b, den Schrank nach der elección: 2a, 2b, 2c,...
- Page 9 10 mm 10 mm...
- Page 10 Anta regolabile Vertical adjustment of the door Vertical adjustment of the door option Optional Réglage vertical de la porte 10 mm Vertikale Türverstellung Ajuste vertical de la puerta 10 mm ±3 mm 4 mm...
- Page 11 Doors must be open. First you need to insert the lower slide and then the upper slide. 10 mm Once the door has been properly hung, lock the carriage by fixing the upper screw...
- Page 13 Anta regolabile Vertical adjustment of the door Vertical adjustment of the door option Optional Réglage vertical de la porte Vertikale Türverstellung Ajuste vertical de la puerta PLEASE CLEAN! PLEASE CLEAN!
- Page 14 Clé à fourche Sechskantenschlüssel Gabelschlüssel llave hexagonal llave inglesa Regolazione verticale Vertical adjustment Vertical adjustment Ajustement vertical Höhenverstellung Regulación vertical Cinetto F.lli S.r.l. Via Rossi, 5/A 35030 Rubano (PD) Italy Tel. +39 049 8977211 Fax +39 049 635822 www.cinetto.it info@cinetto.it...
