Mounting instructions
Off-line filter - tank connection kit
OLF-5-TAK
Tank connection kit 2.0
Art. No. 3039235
last update 12 / 99
HYDAC Filtertechnik GmbH
page 1 of 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OLF-5-TAK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HYDAC International OLF-5-TAK

  • Page 1 _______________________________________________ Mounting instructions Off-line filter - tank connection kit OLF-5-TAK Tank connection kit 2.0 Art. No. 3039235 last update 12 / 99 HYDAC Filtertechnik GmbH page 1 of 9...
  • Page 2 OLF-5-TAK tank connection kit Trademarks The trademarks of other companies are exclusively used for the products of those companies. © Copyright 1999 by HYDAC Filtertechnik GmbH All rights reserved. This manual may not be reproduced in part or whole without the explicit written agreement from HYDAC Filtertechnik.
  • Page 3: Table Of Contents

    OLF-5-TAK tank connection kit Content Description ..........................4 Mounting ..........................6 2.1 D ..........................6 IMENSIONS AT THE ADAPTER 2.2 F ................................6 LOW RATES 2.3 M ............................7 OUNTING INSTRUCTIONS 2.3.1 Return pipe..............................7 2.3.2 Suction pipe..............................7 2.3.3 Ventilation filter ............................8 2.3.4 Seal................................8 2.3.5...
  • Page 4: Description

    OLF-5-TAK tank connection kit Description Use the OLF-5-TAK tank connection kit 2.0 to quickly mount bypass filter units on hy- draulic installations. This component can be mounted on installations with ventilation fil- ter whose connections conform to DIN 24557/T2.
  • Page 5 OLF-5-TAK tank connection kit ventilation filter bypass filter unit ventilation adapter return hose suction hose HYDAC Filtertechnik GmbH page 5 of 9...
  • Page 6: Mounting

    OLF-5-TAK tank connection kit Mounting Dimensions at the adapter suction line connection thread S G ¾“ return line connection thread R G ½“ suction hose G ¾“ thread cut open on one side Dimension 26,9 x 2,3 DIN 2448 return hose DIN 2391/C 45°angle cut on one side...
  • Page 7: Mounting Instructions

    OLF-5-TAK tank connection kit Mounting instructions Please proceed according to the following order: 2.3.1 Return pipe has to be mounted in order to as- sure that the end of the pipe reaches beneath the oil level in the tank.
  • Page 8: Ventilation Filter

    OLF-5-TAK tank connection kit 2.3.3 Ventilation filter Dismount ventilation filter of hydraulic unit 2.3.4 Seal Remove seal from tank cover and clean surface. Put new seal in place. 2.3.5 Adapter has to be mounted on oil tank with...
  • Page 9: Mount Ventilation Filter

    OLF-5-TAK tank connection kit 2.3.7 Mount ventilation filter Mount ventilation filter on the adapter with a new seal and the correct screws. HYDAC Filtertechnik GmbH page 9 of 9...
