WKS25
Technical Manual
English
PATENTED FIRE DAMPER
RECTANGULAR SERIES WKS25 - 500 Pa
Cert. N° 1812-CPR-1046
Installation type with fire resistance class

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RECTANGULAR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Lindab RECTANGULAR Series

Summary of Contents for Lindab RECTANGULAR Series

  • Page 1 WKS25 Technical Manual English PATENTED FIRE DAMPER RECTANGULAR SERIES WKS25 - 500 Pa Cert. N° 1812-CPR-1046 Installation type with fire resistance class...
