- Page 1 MULTI-SURFACE EXTRACTOR SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS MODEL: RC2700 CR2 MULTI-SURFACE EXTRACTOR · CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE · ORIGINAL INSTRUCTIONS · MANUAL ALSO AVAILABLE ONLINE AT WWW.PROCHEM-UK.COM CR2 Manual 29/03/21 Page 1 of 29...
- Page 2 Website: www.prochem-uk.com All information and specifications in this manual are current at the date of issue. However, because of Prochem Europe’s policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains variations including accessories used.
-
Page 3: Table Of Contents
CONTENTS PAGE NO. WARRANTY WARNING SECTION IMPORTANT SAFETY INSTRUCTIONS GENERAL DESCRIPTION OF APPLIANCE & IMPORTANT OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS MAINTENANCE MACHINE LAYOUT HARD SURFACE ACCESSORIES & TOOLS ASSEMBLE ACCESSORY RACKS & OPENING MACHINE CHEMICAL FEED SYSTEM & DILUTION RATIO CHART OPERATING INSTRUCTIONS RESTROOM CLEANING MODE OPERATING INSTRUCTIONS CARPET AND... - Page 4 Prochem Europe Sales Department Telephone: +44 (0)20 8974 1515 Prochem Europe Ltd. EEE Producer Registration Number: WEE / AJ0044SY European Directive (2015/863/EU) Restriction of use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS2). This equipment does not contain more than the maximum permitted levels by...
-
Page 5: Warranty
Your Prochem unit is designed to give you many years of reliable service. If a problem should arise during or after the warranty period, contact the Prochem Authorised Distributor or the Prochem Service Department, for details of the services available. Only the original purchaser of the new equipment may seek performance of this warranty –... -
Page 6: Warning Section
WARNINGS! · Warning! Machines shall not be used by children. Children should be supervised to ensure that they do not play with the appliance. This machine can be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the machine in a safe way and understand the hazards involved. -
Page 7: Important Safety Instructions
Please read this manual hoses. carefully and obtain operating instruction from your Prochem Distributor or authorised representative in !! DO NOT use this machine with or near flammable the correct use of this equipment and suitable vapours. These machines can ignite flammable chemicals before attempting to clean. -
Page 8: General Description Of Appliance
! DO NOT use chemicals in the machine other than solution tank. If not properly dissolved, powdered those manufactured or recommended by Prochem cleaning solution may result in damage to the Europe. -
Page 9: General Operating Instructions
PROCHEM’S liability ceases when the carrier picks up the shipment. However, our customer service staff will be happy to furnish any information needed in connection with the claim and will attempt to expedite a resolution. - Page 10 Do not use replacement parts other than genuine manufacturer’s parts as specified in the parts list. · Do not use chemicals in the machine other than those supplied or approved by Prochem Europe limited. CR2 Manual 29/03/21 Page 10 of 29...
-
Page 11: Maintenance
Inspect cord for damage. Do not use machine with a damaged cord. PERIODIC MAINTENANCE Use only chemicals recommended by Prochem Europe or your distributor. Adhere to the appropriate mix ratios for all chemicals Do not add chemical to the solution tank- use the chemical feed system or pre-spray For optimal performance, it is suggested that the operator flush the system after every job or at the end of the day. -
Page 12: Machine Layout
MACHINE LAYOUT Handle- Used to manoeuvre and position the CR2 Recovery tank lid- Allows access to recovery tank and creates a seal to ensure suction Solution tank lid- Allows access to the solution tank and prevents external contamination of solution tank Accessory racks for hoses, cords, tools etc.- Two large racks on one side and three small racks on each side of the machine. - Page 13 MACHINE LAYOUT Chemical dispensing valve- Select between “SOAP” and “RINSE” by turning to left or right as marked Power cord Exhaust port hose barb- Used to connect to hose with blower attachment. Pressure regulator- Decrease pressure by turning counter-clockwise or increase pressure by turning clockwise Priming/pressure relief valve- Prime system in the event of air lock.
-
Page 14: Hard Surface Accessories/Tools
HARD SURFACE ACCESSORIES/TOOLS CR2 Manual 29/03/21 Page 14 of 29... -
Page 15: Assemble Accessory Racks & Opening
Assembling the accessory racks: The CR2 is shipped with the accessory racks and hardware in the solution tank. When you receive your CR2, it is necessary to secure the racks to the body. The only tool required to complete the assembly is a Phillips head screwdriver. -
Page 16: Chemical Feed System & Dilution Ratio Chart
Installing metering tips for the Chemical feed system: Remove the semi-clear hose from the bottle cap (#8 on page 7). Metering tips have a threaded pattern that is matched to the bottle cap. Select the appropriate metering tip, using the chart below, and thread it clockwise into the threaded tube on the bottle cap. -
Page 17: Operating Instructions Restroom Cleaning Mode
OPERATING INSTRUCTIONS RESTROOM CLEANING MODE Hard surface Cleaning with Chemical feed system The chemical feed system is designed to deliver accurate chemical dilution for touchless surface cleaning. Fill the solution tank of your CR2 with sufficient water for the task at hand. Connect solution hose and accessory pressure gun. -
Page 18: Operating Instructions Carpet And Upholstery Mode
PRIMED AND WATER IS RUNNING THROUGH CARPET WAND. OPERATING INSTRUCTIONS - CARPET WAND Important: Use only Prochem wands and hand tools with the CR2 machine. They are designed to deliver and maintain the correct amount of solution and pressure when attached to the CR2 pump system. Use of other manufacturer’s wands may cause over-wetting of carpet, damage to the pump system and lack... -
Page 19: Storage / Transport
CLEANING UPHOLSTERY CAUTION – WE STRONGLY RECOMMEND ATTENDING AN UPHOLSTERY CLEANING COURSE BEFORE ATTEMPTING TO CLEAN FABRIC UPHOLSTERY. General instructions Cleaning upholstery with success requires a good knowledge of the type of fabric to be worked on. Look for the cleaning instruction label sewn on the underside of the furniture for the recommended method of cleaning the fabric. -
Page 20: General Fault Finding Guide
GENERAL FAULT - FINDING GUIDE CAUTION - Repairs should only be carried out by a QUALIFIED AND FULLY TRAINED PERSON! NO POWER With both vacuum and pump switches in the 'on' position, the vacuum and pump will not run. PROBABLE CAUSES CORRECTIVE ACTION Defective power cord Replace power cord Blown plug fuse Replace fuse House or building circuit breaker tripped Re-set breaker switch... -
Page 21: Accessories & Chemicals
STAIN REMOVERS, TILE & GROUT CLEANERS & DEODORISERS Speciality products such as those listed above are available from the Prochem range. Refer to the chemical section of the Product Catalogue for more details. Individual Product Safety Data Sheets on all products are... -
Page 22: Parts Diagram Upper
PARTS DIAGRAM UPPER CR2 Manual 29/03/21 Page 22 of 29... -
Page 23: Parts List Upper
PARTS LIST UPPER Item Part Number Stock Code Description 10989-2A E10989A BALL FLOAT A00052 E00052 90 DEGREE ELBOW 0.25” MP X 0.25” FP A00060 BARB, 0.375” X 0.25” MPT, BRASS A00124 E00124 LOCKNUT, 0.25” NPT, BRASS A00139 BARB, 0.25” X 0.25” MP, BRASS A13881 CHECK VALVE A90004... - Page 24 K11185 E11185 90 DEGREE ELBOW, SCH40, MPT SF K11965 RETURN BEND, 1.5” K13724 DRAIN HOSE ASSEMBLY S11179 NON-SKID TAPE S13706-A STRAP WAND VELCRO CR2 Manual 29/03/21 Page 24 of 29...
-
Page 25: Parts Diagram Base
PARTS DIAGRAM BASE CR2 Manual 29/03/21 Page 25 of 29... -
Page 26: Parts List Base
PARTS LIST BASE Item No Part Number Stock Code Description A00052 E00052 90 DEGREE ELBOW, 0.25” MP X 0.25” FP. A00053 E00053 45 DEGREE ELBOW, 0.25” MP X 0.25” FP. A00055 E00055 NIPPLE, 0.125”, CLOSE, BRASS. A00060 BARB, 0.375” X 0.25 MPT, BRASS. A00073 E00073 90 DEGREE ELBOW, BRASS. - Page 27 F11178-1 INTERCOOLER, SINGLE PORT. F11789-1-RC CR2 BASE, GRANITE BLUE. F11790-1 HEATER PORT, COVER PLATE. F13820 LOUVRE, 3”, BLACK. G02517-1 LA4501E MOTOR, VACUUM 5.7”, 3 – STAGE. G03518-L E03518 CASTOR, LOCKING, 4”. G11767 E010313 WHEEL, 10” X 1.75”. G13380 VALVE, PRESSURE RELIEF. G13634 REGULATOR, 300-500PSI.
-
Page 28: Wiring Diagram
WIRING DIAGRAM CR2 Manual 29/03/21 Page 28 of 29... -
Page 29: Ce Declaration Of Conformity
2004/108/EC Electromagnetic Compatibility (EMC) Directive 2015/863/EU RoHS Directive A Technical file is held by Prochem Europe Ltd. Certificate of compliance and test reports have been issued by: Signed (For and on behalf of the Importer / EC Responsible Person) Name:...
