Table 3002. ADS-B Transmit Configuration Settings (Cont)
Configuration Item
Disable Squawk
1
Transmit
2
VFR Squawk Code
NOTES:
1 Disable squawk transmit is not configurable on the KGX control panel.
2 VFR squawk code is only set on the KGX control panel.
Configuration Item
Max Targets Output
1
Chelton CSA Enable
Traffic Velocity Validation
3
Display Data Output
NOTES:
1 Chelton CSA Enable is not configurable on the KGX control panel.
2 Traffic Velocity Validation is not configurable on the KGX control panel.
3 Display data output is not configurable on the KGX control panel.
(5) Refer to Paragraph 4.F. for detailed information on determining the correct display output
settings in Table 3003.
C. Serial and ARINC Port Configuration Details
(1) General
(a) The KGX installation requires data interfaces to other equipment for a complete aircraft
installation. The necessary data interfaces are as follows:
• Control input (transceiver only)
• TCAS input
• GPS input
• GPS predictive RAIM input
• Altitude input
• Display output
• GPS output.
