Butterfly Table With Shelves
Assembly Instructions
Dimensions
Fully Extended
Width - 80cm
Length - 160cm
Height - 73.5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
Middle Table
Width - 80cm
Length - 38.5cm
Height - 73.5cm
322/9761
Issue 1 - 25/10/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 322/9761
Summary of Contents for Argos 322/9761
- Page 1 Length - 38.5cm Height - 73.5cm Height - 73.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Issue 1 - 25/10/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • During assembly do not stand • To reduce • Check you have all the components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Side table top x 2 Middle table top Left side unit (62.5 x 80cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 12mm Screw x 54 32mm Screw x 20 15mm Screw x 8 22mm Bolt x 6 62mm Bolt x 4...
- Page 5 Assembly Instructions Step 1 Assemble drawer Fix Left drawer side and right drawer side to drawer back using screws Slide drawer base into the grooves. Screw metal dowels into holes shown on back of drawer front...
- Page 6 Assembly Instructions Step 1(continued) Position drawer front onto sides Insert 2 small locking nuts into each drawer side. Turn locking nuts clockwise to lock. Cover the holes using caps Fix handle using bolts Fix drawer runners under drawer sides using bolts Repeat with another 2 drawers...
- Page 7 Assembly Instructions Step 2 Assemble shelves Attach bottom , shelf back and shelves using wooden dowels Note: Make sure bottom and shelf back are positioned the same as shown in the figure. The holes in shelves must face to bottom Step 3 Assemble runners and fit dowels...
- Page 8 Assembly Instructions Step 4 Assemble table frame Two people are needed from this step. Carefully position the assembled shelf unit onto the left side unit. Attach bottom ends onto both sides of side unit. Carefully position the assembled right side unit onto the shelf unit.
- Page 9 Assembly Instructions Step 5 Lock metal dowels Turn the table frame upright. Insert 4 large locking nuts into shelf back Turn locking nuts clockwise to lock. Cover the nut using caps Insert 2 large locking nuts into underside of each shelf Turn locking nuts clockwise to lock.
- Page 10 Assembly Instructions Step 6 Assemble connecting steels Fix connecting steels on side units using bolts Note: The bolts head should be flush with the connecting steel after tighten. Turn the table frame upside down on a clean surface. Fix connecting steels on side units using bolts Note: Fully tighten the bolts...
- Page 11 Assembly Instructions Step 7 Assemble table top Place the table tops upside down on a clean, flat surface. Fix side table tops with middle table top using bolts , hinges Assemble fixed blocks onto side table tops using bolts Insert 2 wooden dowels into middle table top Note: Fully tighten the bolts.
- Page 12 Depending on your need open one or both of the side table top. Ensure the rotational stand is locked to the fixed block. Customer Helpline: If you need help or have damaged or missing parts, call the Argos = 0345 6400800...
- Page 13 Width - 56cm Depth - 49cm Height - 90cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing part s, call the Customer Helpline: Argos = 0345 6400800 Issue 1 - 25/10/14...
- Page 14 Safety and Care Advice Important – Please read these instructions fully before starting assembly • During assembly do not stand • To reduce • Check you have all the components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 15 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below The quantities below are for 4 chairs Chair frame x 4 Chair seat x 4 (40.7 x 43 x 49 cm )
- Page 16 Note: Make sure the arrow is pointed to the front side of the chair. Turn the chair upright. Assembly is complete. Customer Helpline: If you need help or have damaged or missing parts, call the Argos = 0345 6400800...
