Midland XT511 Alignment Procedure page 7

2. DETAILED SPECIFICATION
A. RECEIVER SECTIONS
1. MAXIMUM USABLE SENSITIVITY
* 1KHz +/-1.5KHz DEV.
* REF. CHANNEL 1 & 8
2. 20dB QUIETING SENSITIVITY
* 1HKz +/-1.5KHz DEV.
* REF. CHANNEL 1 & 8, 12dB SINADDER
3. ADJACENT CHANNEL TWO SIGNAL
SELECTIVITY & SENSITIZATION
* +/- 1 CHANNEL SPACING
4. INTER-MODULATION SPURIOUS RESPONSE
ATTENUATION
5. SPURIOUS EMISSIONS
* CONDUCTIVE CONNECTION
6. RECEIVE FREQUENCY RESPONSE
* REF. 1KHz +/-1.5KHz DEV.
250Hz
3KHz
7. AUDIO OUTPUT LEVEL
* REF. 1KHz +/-1.5KHz DEV.
* (No LOAD )
* Volume Max.
8. AUDIO OUTPUT DISTORTION
* REF. 1KHz +/-1.5KHz DEV.
* ( No LOAD )
9. MAX. S/N RATIO
* REF. 1KHz +/-1.5KHz DEV.
* ( No LOAD )
10. RX VCO REF. VOLTAGE
* REF. CHANNEL 1
* REF. CHANNEL 14
11. SQUELCH THRESHOLD
* REF. 1KHz +/-1.5KHz DEV.*
16. CURRENT CONSUMPTION
* Un-squelched Volume Max.
* Squelched
* Power Off
XT511
PRODUCTION SPECIFICATION
* Normal test condition *
TYP.
-120dBm
-116dBm
-18.0dB
-12.0dB
1.8V
36 dB
1.5V
2.5V
9dBsinadder
130mA
35mA
50uA
LIMIT
<-118dBm
<-110dBm
>50dB
>50dB
<-53dBm
+/-2.0dB
+/-3.0dB
>1.6V
<5%
>30dB
+/-0.3V
+/-0.5V
-3dB - +3dB
+/-40mA
<40mA
<100uA
