Production Specification - Midland XT511 Alignment Procedure

B. TRANSMITTER SECTIONS
1. TRANSMITTER FREQUENCY TOL.
* REF. CHANNEL 1
2. TRANSMITTER RF POWER
* REQUIRED CONDUCTIVE CONNECTION
* REF. CHANNEL 1
* At 6Vdc
3. TRANSMITTER OCCUPIED BANDWIDTH
* REQUIRED CONDUCTIVE CONNECTION
* REF. CHANNEL 1 @12.5KHz
4. TRANSMITTER SPURIOUS
* REQUIRED CONDUCTIVE CONNECTION
* REF. CHANNEL 8
5. MODULATION SENSITIVITY
* REF. 1KHz AUDIO
* CHANNEL 1 , @+/-1.5KHz
6. MODULATION LIMITING
* REF. 1KHz AUDIO, CHANNEL 1
* (INPUT AUDIO ; 200mVrms)
7. CTCSS CODE DEVIATION
* CH 1
* CH38
8. MODULATION AUDIO DISTORTION
* REF. 1KHz AUDIO +/-1.5KHz
8.TX AUDIO FREQUENCY RESPONSE
* REF. 1KHz AUDIO, CHANNEL 1
* ( INPUT AUDIO ; 3mVrms )
250Hz
3KHz
6KHz
9. TX MODUALTION S/N
* REF. 1KHz AUDIO, CHANNEL 1
* ( REF. INPUT AUDIO ; 12mVrms )
10. TX VCO REF. VOLTAGE
* CHANNEL 1
* CHANNEL 14
11. CURRENT CONSUMPTION
* Hi Power mode
XT511

PRODUCTION SPECIFICATION

Hi Power
Low Power
TYP
3.5W
0.6W
5mV
+/-2.1KHz
0.4KHz
0.4KHz
3%
-31.0dB
+6.0dB
-16.0dB
1.5V
2.5V
1200mA
LIMIT
<+/-200Hz
3.0 - 4.0
0.2 - 0.8
<-50dBC
<-50dBC
+/-2mV
+/-0.2KHz
+/-0.1KHz
+/-0.1KHz
<5%
+/-3.0dB
+/-3.0dB
+/-3.0dB
>30dB
+/-0.5V
+/-0.5V
+/-100mA
