Summary of Contents for Midland MIDLAND 220
- Page 1 MIDLAND 220...
- Page 2 Midland 220 is the brand new Multi Standard CB transceiver, essential in its functionalities but with advanced performances, such as the ESP2 (noise killing device). Midland 220 is a very practical radio, very easy to install even into the DIN housing of the vehicles (usually suitable for car radios).
- Page 3 FUNCTIONS AND LOCATION O F THE CONTROLS 11 12 1. Channel selector: it permits the manual channel selection. 2. Multifunction back-lighted display. It shows: A) Selected channel (from 1 up 40) or operative frequency B) FREQ button activated C) ESP: reducing noise device activated D) EMG: indicates channel being used or when the emergency channels are activated E) M1 –...
- Page 4 • activate the second functions of the “M” (M1/M4) buttons. M1 / M4: MIDLAND 220 has the possibility to store and to recall, when necessary, 2 channels previously memorized. T o memorize one channel, follow the procedure herebelow: A) Select the channel with the appropriate selector or the “UP/DN”...
-
Page 5: Rear Panel
REAR PANEL EXT-SP S-METER +RED -BLK 14. Antenna connector (SO239 connector type) 15. ”EXT” jack: external loudspeaker jack.(the internal loudspeaker is excluded) 16. S.Meter jack: it allows an external “S. Meter” connection 17. Power 13.8V DC: power supply cable MICROPHONE 1. -
Page 6: How To Operate Your Transceiver
INSTALLATION Safety and convenience are the primary considerations for mounting any piece of mobile equipment. All controls must be readily available to the operator without interfering with the movements necessary for safe operation of the vehicle. Interference from the connecting cables may contribute to the loss of control of the vehicle. - Page 7 “AM/FM/LCR” button for 3 seconds. NOTE2: If you select a frequency band which operates in FM mode only, the “AM/FM/LCR” control enables the LCR function (last channel recall). fREQuENCY BAND CHART Digits Country Band frequency displayed Italy 40CH AM/fM 4W fx 26,965-27,405 MHz Italy 34CH AM/fM 4W...
-
Page 8: Technical Specifications
TECHNICAL SPECIfICATIONS GENERAL Channels ................40 FM (see the frequency band chart) Frequency Range ..................25.615 to 30.105 MHz Frequency Control ........................PLL Operating Temperature Range ..................10°/+55° C DC input voltage ..................... 13.8V DC ±15% Duty cycle ....................... 5/5/90 (1 hour of use) Size .....................170 (L)x 52 (H)x 170 (D) mm Weight ..........................1,020 kg RECEIVER...
