Part number SP1360
2012 Hyundai Elantra
1.8L 4cyl.
1-
2 piece SP™ Intake system
1- 3" Web/Nano Fiber dry filter
1- 3" straight hose
1- 2-3/4"straight hose
2- Power-Band
.048
2- Power-Band
.040
1- M6 vibra-mount
1- M6 flange nut
1- Fender washer
1- 4 page instruction
Note: All parts and accessories are sold
"injenonline.com"
on-line a
Note: The C.A.R.B. Exempt sticker must be attached
under the hood in a manner such that it is easily viewed by
an emissions inspector.
Note: The installation of this cold air intake does require mechanical skills. Removal of the front bumper requires
loosening and removing several plastic plugs and screws that may be difficult. It is recommended that this
system be installed by a professional mechanic. Be sure to disconnect the negative terminal before proceeding.
Congratulations! You have just purchased the worlds first tuned intake system.
"The Worlds First Tuned Air Intake System"™
Figure 1
(#1020)
Congratulations! You have just purchased the best engineered,
(#3044)
dyno-proven air intake system available.
(#3043)
(#4004)
Report any defective or missing parts to the Authorized Injen
(#4003)
Technology dealer you purchased this product from.
(#6020)
Before installing any parts of this system, please read the instructions
(#6002)
(#6010)
thoroughly. If you have any questions regarding installation please
contact the dealer you purchased this product from.
Installation DOES require some mechanical skills. A qualified
mechanic is always recommended.
*Do not attempt to install the intake system while the engine is hot.
The installation may require removal of radiator fluid line that may
be hot.
Injen Technology offers a limited lifetime warranty to the original
purchaser against defects in materials and workmanship. Warranty
claims must be handled through the dealer from which the item was
purchased.
Injen Technology 244 Pioneer Place Pomona, CA 91768 USA
Note: This intake system was Dyno-tested with an Injen filter and
Injen parts the use of any other filter or part will void the
warranty and CARB exemption number.
Parts and accessories are available on line at "Injenonline.com"
MR Technology, Leading the way!
Please check the contents of this box immediately.
Please check the contents of this box immediately.
Figure 2
Advertisement
Related Manuals for injen technology SP1360
Summary of Contents for injen technology SP1360
- Page 1 Note: The C.A.R.B. Exempt sticker must be attached under the hood in a manner such that it is easily viewed by Injen Technology offers a limited lifetime warranty to the original an emissions inspector. purchaser against defects in materials and workmanship. Warranty claims must be handled through the dealer from which the item was purchased.
- Page 2 Install the vibra mount to thredded insert closes to the Install the 2-3/4” straight hose to the throttle body and and remove from the vehicle. headlight. Secure the vibra mount and tighten. secure using clamps provided and tighten on the throttle body only. Page 2 of Part# SP1360...
- Page 3 Figure 26 Now tighten the nut using 10mm socket and Now secure the crank case line to the fitting on the Secure using the factory clamp. Re-install bumper extension. intake tube. cover and connect battery terminals. Page 3 of Part# SP1360...
- Page 4 5. Check the filter for excessive dirt build up. Clean or replace the filter with an original Injen filter (can be bought on-line at “injenonline.com”). Congratulations! You have just completed the installation of the best intake system sold on the market. Enjoy the added power and performance of your new intake system. Page 4 of Part# SP1360...
