Part number RD6061
2004-09 Mazda 3 2.3L 4 cyl.
2004-09 Mazda 3 2.0L 4 cyl.
Important: Read the information on the
lower right hand side for vehicles that are
not CARB exempt.
1- 2 piece cold air intake
1-
3" injen/Amsoil dry filter(#1014)
2- 2.75" straight hose
4- Power-Bands (.312) .040 (#4003)
1- 2"- 10mm hose
(coupler)
1- M6 vibra-mount
2- M6 flange nut
1- fender washer
2- m4 x 10mm button head (#6047)
1- m6 x m16 hex bolt
1- instruction
Note: Use only Injen replacement
parts when making any
changes to this kit.
Buy on-line at:
"injenonline.com"
Note: The C.A.R.B Exempt sticker
must be attached under the hood in
a manner such that it is easily viewed
by an emissions inspector
Congratulations! You have just purchased the best engineered,
dyno-proven cold air intake system available.
Report any defective or missing parts to the Authorized Injen
Technology dealer you purchased this product from.
Before installing any parts of this system, please read the instructions
thoroughly. If you have any questions regarding installation please
contact the dealer you purchased this product from.
(#3043)
Installation DOES require some mechanical skills. A qualified
mechanic is always recommended.
(#3077)
*Do not attempt to install the intake system while the engine is hot.
(#6020)
The installation may require removal of radiator fluid line that may be
(#6002)
hot.
(#6010)
Injen Technology offers a limited lifetime warranty to the original
purchaser against defects in materials and workmanship. Warranty
(#6005)
claims must be handled through the dealer from which the item was
purchased.
Injen Technology 244 Pioneer Place Pomona, CA 91768 USA
Note: Changes made to the cold air intake or any filter components may hinder the
The following
These vehicles will be considered to be for off road use only, Look for the following
engine test group numbers listed below:
2005 & 2006 Mazda 3 2.0L 4 cyl. vehicles will not be CARB exempt
2007 & 2008 LEV2, SULEV Engine test group numbers -
Figure 1
Figure 1
Please check the contents of this box immediately.
performance of the intake and void current CARB exemption number.
IMPORTANT:
vehicles are excluded from this Executive order number:
7TKXV02.3NG1
-
8TKXV02.0NH1
-
8TKXV02.3NH1
Advertisement
Table of Contents
Related Manuals for injen technology RD6061
Summary of Contents for injen technology RD6061
- Page 1 2- M6 flange nut (#6002) hot. 1- fender washer (#6010) Injen Technology offers a limited lifetime warranty to the original 2- m4 x 10mm button head (#6047) purchaser against defects in materials and workmanship. Warranty 1- m6 x m16 hex bolt (#6005)
- Page 2 Figure 2 Figure 2 Figure 3 Figure 3 Press the 2 3/4” straight hose over the throttle body. Use two clamps on the Slip the remaining 2 3/4” straight hose over the end of the Primary intake. The 2 3/4” hose but only tighten the clamp on the throttle body. side opposite of the machined adapter and vacuum port is the end where the hose will be placed, use a clamp to fasten the hose to the intake.
- Page 3 5. Check the filter for excessive dirt build up. Clean or replace the filter with an original Injen filter (can be bought on-line at “injenonline.com”). 6. Congratulations! You have just completed the installation of the best intake system sold on the market. Enjoy the added power and performance on your new intake system. Page 3 of part# RD6061...
