Ricon F9T Service Bulletin

Subject:
Applicable Products:
Effectivity:
Ricon service bulletins are for use by professional service technicians, and are not intended for use by
non-professionals (do-it-yourselfers). Service Bulletins alert technicians to issues that may occur with
Ricon products, and are intended to assist the technician in the proper service of those products.
Professional service technicians have the background and knowledge to perform maintenance work
properly and safely.
An issue described by a service bulletin does not necessarily apply to every unit in a product line. A
Ricon authorized service technician will be able to determine which units can benefit from the
information provided here.

Introduction

This bulletin provides step-by-step procedures for programming the platform stow height and
the platform intermediate height.
The corrective action section of this bulletin is in two parts. The first deals with setting the stow
height and the second deals with setting the intermediate height.
The stow height is factory set and normally does not require resetting. However, if major lift
disassembly is done, or the vertical travel limit has been readjusted, then stow height must be
reprogrammed.
Some dedicated entry models have an additional platform position referred to as "intermediate
height". This height is generally a few inches below floor height, and is also factory-set. The
height may be reprogrammed for specific applications, or after major repair work. Note that
some dedicated entry models move the platform directly from the ground to floor height, without
stopping at an intermediate position.

Incorporation

Ricon recommends this service bulletin be used when major lift disassembly is done, or the
platform vertical travel limit has been

Information

The height of the platform prior to being pulled into the enclosure is referred to as "stow height".
The platform will enter the enclosure without difficulty when stow height is properly set. If the
platform stow height is slightly high or low, the platform movement may be hindered when it
enters the enclosure.
Some dedicated entry applications (baggage bay lift location) require the platform to stop at a
height that is just below floor level. Once stopped, the sliding door at this location is opened,
and then the platform proceeds to floor level.
The stow and intermediate height values are stored indefinitely in the controller memory.
NOTE:
Programming the controller will clear the present value and store a new value.
Caution
•
The platform is heavy and somewhat awkward to handle. Be cautious when moving the
platform by hand, and be alert to the location of your hands at all times.
•
Do not attempt adjustments without the presence of a person capable of rendering aid, and
take notice of all injuries, regardless of how slight. When necessary, administer first aid or
seek medical attention immediately.
•
Exercise caution when operating the lift to avoid injury. Be certain that hands, feet, legs,
and clothing are not in the path of the platform as it moves.
07-08-03
SERVICE BULLETIN
Setting Platform Stow Height and Intermediate Height
F9T & F9TF LiftPRO
All stepwell and baggage bay installations
readjusted.
RSB003.B
®
1 of 4
