OPERATING INSTRUCTIONS
III.
T
he following operating instructions are important for the Ricon S2000/5000 Series™ Wheelchair Lift. Please
read this section carefully before operating the lift. Lift operation should never be attempted until the lift user
reads and thoroughly understands the operating instructions.
IT IS THE WHEELCHAIR OCCUPANT'S AND/OR ATTENDANT'S RESPONSIBILITY TO CAREFULLY FOLLOW
ALL SAFETY PRECAUTIONS IN THIS MANUAL (SEE SECTION III.A.) WHEN OPERATING THE LIFT.
A. S2000/5000 FEATURES
•
Welded all steel frame.
•
Automatic folding platform.
•
Automatic inboard platform rollstop.
•
Convenient handrails for user comfort and security.
•
Hand-held control pendant.
•
Powerful integrated valve hydraulic pump.
•
Easy to use manual backup system.
•
Simple electrical system is nearly maintenance free.
•
Skid-resistant platform.
•
The S-Series™ wheelchair lift is rated for loads up to 800 lbs (364 Kg). Available platform sizes
accommodate most manual and power wheelchairs.
WARNING
- 27 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ricon S2000 Series
Summary of Contents for Ricon S2000 Series
- Page 1 OPERATING INSTRUCTIONS III. he following operating instructions are important for the Ricon S2000/5000 Series™ Wheelchair Lift. Please read this section carefully before operating the lift. Lift operation should never be attempted until the lift user reads and thoroughly understands the operating instructions.
- Page 2 Inspect the lift prior to each use. Check for loose nuts and bolts. If any unsafe condition exists, DO NOT use the lift. Return the lift to an authorized Ricon Dealer for repair. • Wheelchair brakes are less effective if the wheels or lift platform are wet. Use extreme care in wet conditions.
- Page 3 Be sure you have read, and understand each of these safety precautions. Review them periodically, and ask any attendants, or other wheelchair users operating your lift to read them as well. If you have any questions, contact your installing Ricon Dealer or call our Service Department at Ricon Corporation. - 29 -...
- Page 4 AN AUTHORIZED DEALER FOR REPAIR. 4) THIS LIFT IS DESIGNED FOR USE BY WHEELCHAIR OCCUPANTS ONLY. RICON CORPORATION DISCLAIMS LIABILITY FOR DAMAGE OR PERSONAL INJURY RESULTING FROM MODIFICATION TO THE LIFT, LACK OF MAINTENANCE AND/OR REPAIR, NEGLIGENCE, ABUSE, OR FAILURE TO FOLLOW LIFT OPERATING INSTRUCTIONS.
- Page 5 E. LIFT OPERATION • Before operating lift, be certain vehicle is safely parked on a level area away from traffic. Allow enough space for lift operation and passenger boarding. • Open door(s) completely. Operator must take special care to ensure that the area is clear before deploying lift.
- Page 6 LOWER PLATFORM - Push and hold UP/DOWN switch in the DOWN position until the platform reaches the ground level completely. Unfasten occupant restraint belt, release wheelchair brakes, and carefully exit platform. 3. TO STOW PLATFORM: NOTE: The occupant restraint belt must be fastened to enable STOW/DEPLOY and UP/DOWN functions. The lift will not operate unless this safety mechanism is properly engaged.
- Page 7 • Turn handle extension ¼ turn counter-clockwise once again and hold valve OPEN until the platform reaches the ground level completely. Turn handle clockwise to CLOSE valve. WARNING ALWAYS FOLLOW OPERATING INSTRUCTIONS TO ENTER AND/OR EXIT THE VEHICLE WHEN USING THE MANUAL BACKUP SYSTEM. STOWING THE PLATFORM: •...
