Page 1 PViQ™ Connectivity System User Manual...
Page 2: Table Of Contents
Contents Important Information ...................... 8 General Safety Notices ....................8 Injury Precautions ....................8 Product Damage Precautions .................. 8 Section 1 – PViQ™ Connectivity System Overview ............9 PViQ™ Connectivity Hardware ..................9 Patch Field Hardware ....................9 Intelligent Modules ....................10 Patch Cords and Cables ..................
Page 3 Internet Protocol (IP) Address ................... 32 Web Configuration ..................... 32 Supported Web Browsers ..................32 Logging in to the Web Interface ................32 PViQ™ Connectivity Web UI Pages ................32 Login Page ......................33 Dashboard Page ....................33 Patching Page ......................35 Alarms Page......................
Page 4 Configuring the PViQ™ Connectivity System Time ........... 75 Section 7 – PViQ™ Connectivity System Installation Configurations ......78 Introduction ........................ 78 Cross-Connect ......................78 Cross-Connect Data Center or Edge Solution ............78 Cross-Connect Enterprise or Edge Solution ............79 Interconnect ....................... 79 Interconnect Data Center or Edge Solution ............
Page 5 Maintenance Agreement ..................113 Regulatory Information .................... 113 Section 11 - Support and Other Resources ..............114 Accessing Panduit Support ..................114 Section 12 - Acronyms and Abbreviations ..............115 Documentation Feedback ................... 116 Appendix A: PViQ™ Connectivity Hardware Installation ..........117 Hardware Installation Overview ................
Page 6 Installing the Intelligent Modules ................123 PM and EM Connections ..................124 Connection Points ....................125 Connecting the PM to the EM ................126 Daisy Chaining EMs ..................... 126 Connecting Multiple PMs ..................126 Connection Diagram .................... 126 Attaching the Power Supply ................. 127 Label and Label Cover Installation ...............
Page 7 CLI Method ......................149 SmartZone Connectivity Software Module Method ..........150 Appendix F: PViQ™ Connectivity System Alarm Categories and Codes ....151 Appendix G: Interacting with the PViQ™ Connectivity System Interface Units ... 153 PViQ™ Connectivity System Interface Unit (IU) Overview ........153 Interface Unit (IU) Function Keys ................
Page 8 SNMP Trap Notifications ..................173 Email Alarm Notifications ..................173 Protocol Access Configuration ................173 Secure Deployment, General Guidelines ..............173 Secure Deployment for SNMPv3 Access Only ............174 Secure Deployment for HTTPS Access Only ............175 Best Practice for Password Complexity/Strength ............ 177 Best Practice for Secure Physical Deployment ............
Page 9: Important Information
Only qualified personnel should perform service procedures. Injury Precautions • Use Proper Power Cord with Panduit Adapter. To avoid fire hazard, use only the power cord specified for this product. • Avoid Electric Overload. To avoid injury or fire hazard, do not apply potential to any input, including the common inputs that vary from ground by more than the maximum rating for that input.
Page 10: Section 1 - Pviq™ Connectivity System Overview
Overview PViQ™ Connectivity Hardware The Panduit PViQ™ Connectivity Hardware System consists of a patch field and intelligent modules. The patch panels/trays have 24 data ports and occupy 1 Rack Unit (RU) space in a standard rack or cabinet. The intelligent modules are removeable modules that plug into the back of the patch field panels/trays, eliminating the need for additional RU space for the intelligent connectivity system.
Page 11: Intelligent Modules
Figure 2: Angled PViQ™ Connectivity Patch Panel (without data connectors) PViQ™ Connectivity Fiber Tray On the Fiber Tray, intelligent modules are accessed from the back of the unit. The Fiber Tray is available as pre-terminated or field terminated. The tray is available in single mode or multimode with LC type data connections or MPO type data connections.
Page 12 Figure 4: PViQ™ Connectivity Panel Manager (with mounting bracket, patch cord and interface unit) The PM is a removable module that provides scanning and management capabilities for patch panels or fiber trays. The PM includes LAN connectors for daisy chaining multiple PMs.
Page 13 Figure 6: PViQ™ Connectivity Expansion Module (with mounting bracket, expansion port cable, and IU) NOTE: When installing the EPC make sure the cable coming from the PM (or previous EM) connects into the “Expansion In” port on this EM and the cable going to the next EM in the chain connects to the “Expansion Out”...
Page 14 on the PM IU. The three indicators on the top (MAC, MODE, TRC) indicate the mode that the panel/tray is in. Figure 8: PViQ™ Connectivity PM Interface Unit Mounting Bracket Panel Managers and Expansion Modules are connected to the patch panel/tray using the PViQ™...
Page 15: Patch Cords And Cables
Patch Cords and Cables Enabling the full potential of the PViQ™ Connectivity System requires specific patch cords and cables. Standard Shielded Patch Cord A standard shielded patch cord connects one PM to another PM. Thirty PMs may be connected together and connected back to one Ethernet LAN port. A 0.5M patch cord is provided with every PM.
Page 16 Connectivity Software Modules are compatible with most current major network equipment manufacturer's switch and router products. For questions about the compatibility of your specific hardware, please contact Panduit Technical Support. • 1-866-721-5302 (toll-free) Monday-Friday, 7:30 am – 5:00 pm CST •...
Page 17 unshielded and basic unshielded. Each interconnect copper cord type is available in various lengths and colors. The PViQ™ Connectivity Basic Interconnect Patch Cord (see figure below), also called the “I-Cord,” consists of a standard PViQ™ 9-wire patch cord plug on one side, and a special shielded housing on the far end to allow the system to sense double ended connections and provide visual verification in the PViQ™...
Page 18: Power Supply
Plunger and Visual Indicator PViQ™ Connectivity End Figure 14: Copper Enhanced Interconnect Patch Cord (Shielded) The PViQ™ Connectivity Fiber Interconnect Patch Cord consists of a standard PViQ™ fiber patch cord fiber connector on one side, and a standard fiber connector on the far end to allow the system to sense PViQ™...
Page 19: Installing/ Connecting Pviq™ Connectivity System To The Management Network
Before applying power to the unit, ensure that you have an appropriate power supply for your region. Use the following recommended Panduit power supply for your region listed in Appendix A or a recommended end use LPS power supply where applicable.
Page 20: Interacting With The Pviq™ Connectivity System
SmartZone Software Platform. The SmartZone Asset and Connectivity Software Modules are part of a Windows based Graphical User Interface (GUI) Software Platform that may be purchased separately from Panduit. For details on using the CLI, refer to Section 4 - Accessing the PViQ™ Connectivity System Through the Command Line Interface (CLI).
Page 21: Pviq™ Connectivity System Interface Unit (Iu)
PViQ™ Connectivity System Interface Unit (IU) The PViQ™ Connectivity System has several standard operating modes. These various modes may be accessed through unique combinations of key presses using the Function Keys (the Confirmation Key and Next Key), through the PViQ™ Connectivity Web UI or through the SmartZone Software.
Page 22 two modes that the panel may be transitioning through. Each of these modes has its own use and functionality. It is important to be able to visually determine the current state of the hardware, and to manipulate the hardware into the desired mode, to accomplish various tasks. The following PViQ™...
Page 23 Mode Meaning Move, Add, and Change (MAC) Mode notifies users when pending change orders have been sent to the PViQ™ Connectivity System. The MAC Mode mode may be entered through the SmartZone Asset and Connectivity Software Modules only. The PViQ™ Connectivity Web UI triggers MAC Mode when using “Clear Security Policy”, to guide the removal of the patch cord.
Page 24: Secure Mode
Secure Mode Secure Mode is the normal operating mode. Each panel/tray will be in Secure Mode under normal operating conditions. Once the panel/tray is in Secure Mode, any unauthorized changes that occur in the patch field will result in a “Secure Violation,” and a red LED will light above the port identifying the violation.
Page 25: Trace Mode
Web UI or the SmartZone Connectivity Software Module. If a change is made without a request through the Web UI or SmartZone Connectivity Module (manually connecting or disconnecting patch cords at either end of the cord), a Secure violation occurs. NOTE: When the PViQ™...
Page 26: Mac Mode
Entering and Exiting Trace Mode The PViQ™ Connectivity System may be put into Trace Mode through the PViQ™ Connectivity Web UI or through the PViQ™ Connectivity Panel IU. Refer to Section 2 – PViQ™ Connectivity System Web User Interface (Web UI) for entering and exiting Trace Mode through the Web UI.
Page 27: Learn Mode
Exiting MAC Mode Upon completion of the MAC activity, the PViQ Connectivity Patch Panel will automatically return to Secure Mode. Learn Mode Learn Mode is used to commit the current patch field configuration to the database. Changes to the patch field (for example, moving patch cables from one port to another) are “learned”...
Page 28: Maintenance Mode
Where <x> is the offset number of the panel. To exit Learn Mode, and return to Secure Mode, using the CLI set mode command, enter the command as shown below: set mode <x> secure Where <x> is the offset number of the panel. Refer to the SmartZone Software User Manual to learn how to enter and exit Learn Mode on the PViQ™...
Page 29: Location Mode
Appendix G: Interacting with the PViQ™ Connectivity System Interface Units), by the Command Line Interface (refer to Appendix C: PViQ™ Connectivity CLI Commands) or by the SmartZone Asset and Connectivity Software Modules (refer to the SmartZone Software User Manual). Maintenance Mode is implicitly entered through the Web UI during firmware update.
Page 30: Mode Identification Summary
set mode <x> location Where <x> is the offset number of the panel. This is a future feature in the PViQ™ Connectivity Web UI that has not been implemented yet. Exiting Location Mode To exit Location Mode, and return to Secure Mode, use the CLI set mode command, as shown below: set mode <x>...
Page 31: Port Led Indicators
Maintenance Mode Port LED Indicators Each panel/tray in the PViQ™ Connectivity System has individual LEDs located above each port. The table below describes the basic states for the ports and defines the LED colors associated with these states. NOTE: When the PViQ™ Connectivity System is in the normal operating state (Secure Mode), with no Secure Violations, the Port LED indicators are “off”...
Page 32 Move, Add, or Change (MAC) is Flashing pending on this port. Waiting for Green insert. Move, Add, or Change (MAC) is Flashing pending on this port. Waiting for remove. Solid Panel is in Maintenance Mode ALL ports Solid Secure Violation ONE port PVIQ™...
Page 33: Section 2 - Pviq™ Connectivity System Web User Interface (Web Ui)
PViQ™ Connectivity System. If the default username and password were NOT changed in a prior login to the PViQ™ Connectivity System, use the default username: admin and password: panduit. For security purposes, change the password upon login. PViQ™ Connectivity Web UI Pages There is a total of eight different pages in the PViQ™...
Page 34: Login Page
6. Network – allows you to change system attributes and network configuration of the PViQ™ Connectivity System. 7. Email – allows you to activate email alerts from the PViQ™ Connectivity System. 8. Users – allows you to add user and permissions into the PViQ™ Connectivity System.
Page 35 Page Tabs Page Header Panel Port Status Panel Attributes Figure 28: Default Dashboard Page The dashboard page is a monitor only page. In the ribbon at the upper left side of the page are seven tabs that you can use to navigate between pages in the PViQ™ Connectivity Web UI.
Page 36: Patching Page
“Default Dashboard Page” figure above. This field may be changed by the user. The intent of this field is to enter a name that identifies what is connected to the back side of the patch panel on this port. All PViQ™ Connectivity Panels have 24 ports. Use the scroll bar on the right side of the page to see the rest of the ports on the panel.
Page 37 The patching page allows provisioning of the panel ports. This page is used to customize the port attributes. You can configure each port to what the port should expect (setting/clearing the security policy for the port). Figure 29: Patching Page NOTE: If any text in a field does not fit in the field box, float over the text line and a pop up will provide the full text content.
Page 38 Panel Name (actual) You can customize this field, which identifies the panel name of the port being worked Port Number (actual) This field allows you to select the port in the panel being worked on. Click the field to open a drop-down menu where you can select any of the 24 ports on the selected panel.
Page 39 NOTE: The panel is placed into Trace Mode, but only one port on that panel is being traced (indicated by the port LED flashing green-red). NOTE: Panduit recommends running only one trace at a time to avoid confusion. Alarm Status (actual) This read-only field provides the status of the alarm on this port.
Page 40 • Disconnected = no cord plugged into the port • Connected = this is either a Fiber I-Cord or a single-ended connection of any of the other cords in this group. • Cross-Connect = both ends of a copper or fiber cross-connect cord are connected (both ends are connected to PViQ™...
Page 41 • Blank = the line is blank because there is no cable connected or there is an I- Cord connected and the far-end port is unknown. Far End Horizontal Name (actual) This read-only field provides name of the device that is connected to the back side of the far-end Panel/Port.
Page 42 • The port LEDs will turn off • The alarm will clear from the Alarm Page • The event will get entered into the Logs Page • An email alert will be sent to the provisioned email address(es). In the case of an I-Cord patch cord, if the removed end is reconnected to the correct port: •...
Page 43: Alarms Page
Port Status (expected) This is the expected port status. If a cross-connect of interconnect cable is expected this field will be “Both Connected”. If no cable is connected this field will be “<No Cable Connected>”. FE Horizontal Name (expected) This field is the name of the device that is connected to the back side of the far-end Panel/Port.
Page 44: Logs Page
on a panel. Note that the summary lines provide a summation of all the current alarms on a panel. When no alarms are on a panel, the summary line does not appear. Figure 30: Alarms Page (with five active alarms on the system) Page Header Below the ribbon is the page heading “Patch Cable Alarms”.
Page 45 alarms that have happened in the system. Figure 31: Logs Page (with example of the last alarm showing) Page Header Below the ribbon is the page heading “Alarm Log”. Hover over the Help button to see a description of the page. This description also appears in the “Context Help” box. Log Data Screen Below the page header is the log data screen.
Page 46: Network Page
• 40, I-cord has been connected to the wrong switch port. • 45, I-cord provisioning cord has failed to detect CDP. • 50, I-cord has been disconnected from a switch. • 60, I-cord has been disconnected from the wrong switch port. •...
Page 47 Figure 32: Network Page (default settings) Page Header Below the ribbon is the page heading “System Attributes and Network Configuration”. Hover over the Help button to see a description of the page. This description also appears in the “Context Help” box. System Information This section contains the attributes about the PViQ™...
Page 48 NOTE: This field does not create an automatic contact, this field is for informational purposes only. To notify a contact automatically of system changes, enter the appropriate information in the Email Page. Panel Settings This section contains the attributes about the selected panel in the PViQ™ Connectivity System.
Page 49 cords to be removed, added, or changed without causing an alarm. However, these actions will still be recorded in the log file. The panel is typically put into Learn Mode during the initial install of the patch field. Application Select Click Application Select to open a pulldown menu that allows you to select the application (copper, singlemode, multimode, OM4, fieldterm) the panel/tray is being used in.
Page 50 Start Day This is a user-selectable pulldown menu that allows the customer to select the day in the week in which daylight savings time will start. Start Time This is a user-selectable pulldown menu that allows the customer to select the time of day in which daylight savings time will start.
Page 51 address from a DHCP server. In Static Mode the user must assign an IP Address, Network Mask, and the Default Gateway Address. IP Address This field will autofill if DHCP is selected for the Boot Mode. If the user prefers to assign an IP address to the PViQ™...
Page 52 updated firmware load that is located on their TFTP server. Server IP This is a user-changeable field that allows the customer to enter the IP address of the TFTP server that contains the firmware update file to be loaded on the PViQ™ Connectivity System.
Page 53 System will automatically go into Maintenance Mode and stay in this mode until the firmware update is complete. When the system goes into Maintenance Mode, the system will have an audio beep every 15 seconds. Refer to Identifying Maintenance Mode for characteristics of the system during Maintenance Mode. This check box will allow the customer to prevent the system from sounding the audio beep every 15 seconds during firmware update.
Page 54 Secondary IP This is a user-changeable field that allows the customer to enter the IP address of the Secondary (back up) NTP server that they want the PViQ™ Connectivity System to get the time from. If connection to this server fails, the system will attempt to get the time from the Tertiary (next back up) NTP server.
Page 55 Time This is a read-only field that is automatically updated with the time that the PViQ™ Connectivity System is set to. This field is formatted to 24 hour mode (hours:minutes: seconds) and cannot be changed. Actions This section provides the buttons that are used to act on the PViQ™ Connectivity System.
Page 56: Email Page
Figure 34: Reset to Default Settings Confirmation Popup Window IMPORTANT NOTE: This action will cause the system to lose all of your customized data and configurations saved to the PViQ™ Connectivity System. Make sure you know this is what you want to do before clicking on the Yes button. Email Page From any page, click the Email tab in the page ribbon at the upper left side of the page to get to the Email Page.
Page 57 NOTE: Any changes made to this section requires a click on the Save button or the changes will be lost. Enable This is a check box to enable or disable the recipient from receiving email alerts. If recipient is not to receive email alerts, uncheck the enable box. Email Recipient(s) This field is customizable by the user.
Page 58 Enable This is a check box to enable or disable the PViQ™ Connectivity System from sending email alerts to the Email Server. If you do not want the system to send email alerts, uncheck the box. This is a user-changeable field that allows you to enter the IP address of the email server that you want the PViQ™...
Page 59: Users Page
be filled in with an authentic username. Talk to your Email Server Administrator to determine what should be entered into this field. If email server authentication is not required, this field may be left blank. Password This is a user-changeable field that allows the user to enter the authentic username’s password for the email server.
Page 60 Figure 36: Users Page A total of 10 users may be enabled to log into the PViQ™ Connectivity System. Page Header Below the ribbon is the page heading “Login Management”. Hover over Help to see a description of the page. This description also appears in the “Context Help” box. Users This section allows the user to enable and configure the users that may log into this PViQ™...
Page 61 Allowed Protocols The Allowed Protocol select button is a pulldown menu to select the allowable login protocols that this user may use to log into the PViQ™ Connectivity System. This pulldown has three options: • Both: Means the user may log into this system via Web UI or Telnet. •...
Page 62: Section 3 - Simple Network Management Protocol (Snmp)
Section 3 – Simple Network Management Protocol (SNMP) SNMP Management Configuration For details on SNMP, refer to the SmartZone Software User Manual. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 63: Section 4 - Accessing The Pviq™ Connectivity System Through The Cli
Section 4 - Accessing the PViQ™ Connectivity System Through the CLI Introduction The Command Line Interface (CLI) is an alternate method used to manage and control the PViQ™ Connectivity System status and parameters, as well as basic admin functions. NOTE: The preferred method of managing and controlling the PViQ™ Connectivity System is through the PViQ™...
Page 64 A terminal window will open, wait for the PViQ™ Panel to prompt for a “Username:” Default Username is: admin Default Password is: panduit 5. Enter the Username. Press Enter. 6. Enter the password. Press Enter. A screen similar to the below figure will appear.
Page 65 Figure 38: Pan Shell CLI Ready Window 7. You are now logged into the PViQ™ Panel. Refer to the CLI Commands list in Appendix C: PViQ™ Connectivity CLI Commands for available commands. NOTE: For security purposes, it is recommended to change the default password as soon as possible.
Page 66: Section 5 - Accessing The Pviq™ Connectivity System Through The Web Ui
PViQ™ Connectivity System. 2. The Login Page will appear. Enter the default UserName: admin and Password: panduit. Figure 39: Login Page (username and password) 3. The Dashboard Page will appear. Select the Users tab. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 67: Logging Out
Figure 40: Dashboard Page (Users tab) 4. The Users page will appear. Enter a new password for the admin username. Figure 41: Users Page (password) 5. Click Save. The default password for the admin username has been changed to the new password. If the admin username password needs to change again, perform these steps again, logging in with the new password.
Page 68: Access Types
1. Click Log Out in the top right corner (above the tab ribbon) of any page. Figure 42: Users Page (Log Out) 2. The Login Page will appear. Access Types There are three levels of access privileges: • Administrator Privileges with Web UI and Telnet Access •...
Page 69 5. Click on the Enable box (to create a check mark in the box) for that new user on the new line. 6. Click on the Save button. Figure 43: Users Page (adding a user) Modify user access privileges: 1. Go to the Users Page. 2.
Page 70: Section 6 - Configuring The Pviq™ Connectivity System Through The Web Ui
Section 6 – Configuring the PViQ™ Connectivity System Through the Web UI Introduction This section provides the steps to configure the PViQ™ Connectivity System for normal use through the PViQ™ Connectivity Web UI. This section provides the steps to: • Configure the PViQ™ Connectivity Panels with: o The Name of the Rack where each PViQ™...
Page 71 identify each PViQ™ Connectivity panel down to the RU location. NOTE: The PViQ™ Connectivity Web UI will automatically log you out after 5 minutes of inactivity with the PViQ™ Connectivity System. Changing fields is not considered activity with the PViQ™ Connectivity System until you click the Save button. It is recommended to click the Save button frequently during the procedures below.
Page 72 The user may want to change this if the customer decides to populate the panel with different media type minicom modules. Select the shape of this panel, from the Shape pulldown menu. Panduit offers flat or angled panels. This is for informational purposes only. This field may help identify the panel by site.
Page 73: Configuring The System For Daylight Saving Time
There should be no need to change this field. It may be a read-only field in future Web UI releases. Select the shielding of this panel from the Shield pulldown menu. Panduit offers shielded or angled copper panels. This is for informational purposes only. This field may help identify the panel by site.
Page 74 to click the Save button frequently during the procedure below. The following steps are used to configure and enable daylight savings time on the PViQ™ Connectivity System. 1. Open a supported web browser. Enter the IP address of the PViQ™ Connectivity System that is being configured.
Page 75: Configuring The System's Network Settings
5. Enable DST 6. Start Month 7. Start Week Save 8. Start Day 9. Start Hour/Minute 10. End Month 11. End Week 12. End Day 13. Time Offset Figure 46: Network Page (daylight savings settings) Configuring the System’s Network Settings The PViQ™...
Page 76: Configuring The Pviq™ Connectivity System Time
5. Select the Internet Protocol Mode that you want the PViQ™ Connectivity System configured to, from the Boot Mode pulldown menu. There are two IP Address Configurations that the system can be configured for (DHCP or Static). The system ships configured as DHCP. If you change the system to DHCP mode, no other fields in the Network Settings section will need to be set.
Page 77 maintain real time. Connecting the system to an NTP server will guarantee that that PViQ™ Connectivity System will maintain local real time and provide meaningful timestamps on the alarm logs in the Logs Page. NOTE: The PViQ™ Connectivity Web UI will automatically log you out after 5 minutes of inactivity with the PViQ™...
Page 78 Zone pulldown menu. The NTP server provides the UTC and the system must be set to an offset from the UTC to provide the local time. Example: US Central Standard Time (CST) is -6.00. Click on the Save button in the Actions section to save your changes. Figure 48: Network Page (time protocol) PVIQ™...
Page 79: Section 7 - Pviq™ Connectivity System Installation Configurations
Section 7 – PViQ™ Connectivity System Installation Configurations Introduction The PViQ™ Connectivity System can be configured into a network in two ways: Cross-Connect Interconnect Either configuration or a combination of both may be used to connect network elements within data centers, telecommunication room, and edge computing space. Factors such as density of IT assets within racks and cabinets as well as the frequency of asset reconfigurations will determine which method will be most effective.
Page 80: Cross-Connect Enterprise Or Edge Solution
Cross-Connect Enterprise or Edge Solution The Cross-Connect configuration may also be used in intermediate distribution areas or data communications closets to reduce the facility reconfiguration costs and cabling time (as shown in the figure below). Figure 50: Cross-Connect Enterprise or Edge Solution Interconnect Interconnect configurations utilize PViQ™...
Page 81: Interconnect Data Center Or Edge Solution
Interconnect Data Center or Edge Solution The interconnect configuration is ideal for configurations with space limited areas that have lower reconfiguration requirements and utilize higher density connections than other computing areas (as shown in the figure below). Figure 51: Interconnect Data Center or Edge Solution Interconnect Enterprise or Edge Solution The interconnect configuration may also be used in intermediate distribution areas or data communications closets where space is at a premium, and limited moves, adds,...
Page 82 Figure 52: Interconnect Enterprise or Edge Solution The Provisioning Port on the PM and Interconnect Patch Cords guides installers to the correct switch and panel ports for moves, adds, and changes. The PViQ™ Connectivity System detects connections and disconnections made between the switch and PViQ™ Connectivity Panel and visually identifies these ports through colored LEDs on the panels, as well as LEDs built into Enhanced Interconnect Patch Cords.
Page 83: Section 8 - Adding/Removing Connections Using Pviq™ Connectivity Web Ui
Section 8 – Adding/Removing Connections Using PViQ™ Connectivity Web UI Introduction This section will provide the step-by-step procedures for updating the patch field and getting it back into a secure state. In the secure state, the PViQ™ Connectivity System will set an alarm, record the alarm in the alarm log, and send an alert via email (if enabled) when there is a change to the patch filed.
Page 84 System that the added connection is being added to. NOTE: If connecting a cross-connect between two PViQ™ Connectivity Systems, you only need to log into one of the systems with an end point on that connection. The security policy will automatically be setup on the other system when the following steps are completed.
Page 85: Panel Learn Mode Method
Panel Learn Mode Method This method may be used at initial patch field setup or when adding to a patch field that is already setup. This method is typically used for initial patch field setup. The following steps are used to add cross-connections to a PViQ™ Connectivity System patch field or between two PViQ™...
Page 86: Removing A Cross-Connect Connection From The Patch Field
turning both port LEDs green and two audio beeps (indicating both ends are connected). NOTE: If the panels at both ends of the connection were not placed into Learn mode before the connections are made, you can recover by placing the second panel into Learn mode after the connection was made.
Page 87: Individual Port Security Policy Method
Individual Port Security Policy Method This method may be used for patch field teardown or when removing individual patch cords from a patch field. This method is typically used when removing one or more individual connections in the patch field. Perform the following steps to remove cross-connections to a PViQ™...
Page 88: Panel Learn Mode Method
Panel Learn Mode Method This method may be used for patch field teardown or when removing individual patch cords from a patch field. This method is typically used for patch field teardown. Perform the following steps to remove cross-connections from a PViQ™ Connectivity System patch field or between two PViQ™...
Page 89: Adding A Copper Interconnect To The Patch Field
a. When you remove the first connection, the LED above the port will extinguish and the far end connected port will change to amber and the system will provide a single audio beep. b. When you remove the second connection, the LED above the port will extinguish.
Page 90: Individual Port Security Policy Method
Individual Port Security Policy Method The following steps are used to add copper interconnect patch cords to a PViQ™ Connectivity System patch field. 1. Connect the interconnect patch cord between the PViQ™ Connectivity System port and the network device in the patch field. a.
Page 91: Removing An Interconnect From The Path Field
d. Then Panel Mode will transition back to Secure mode, the Alarm Status will change to Secure, and the red dot will disappear. 9. The new connection has been added to the system, the security policy violation alarm for this connection will disappear, and the system involved will be left in Secure mode.
Page 92: Panel Learn Mode Method
a. The port LED and MAC LED will extinguish once the cord is removed from the port. b. The Panel Mode will change back to Secure mode. c. The Port Status and Patch Cord Type will change to Disconnected. 8. The connection has been removed from the system and the system will be left in secure mode.
Page 93: Adding A Fiber Interconnect To The Patch Field
8. You may continue remove additional interconnect patch cords from the panel that are in Learn mode. 9. Upon completion of all your removals, change all panels in Learn mode back to secure mode. For each panel in Learn mode, select Secure in the Configuration Mode field from the pulldown menu.
Page 94: Panel Learn Mode Method
System that the added connection is being added to. The Login Page will appear. Enter the appropriate username and password. Dashboard page will appear. 4. Select the Patching tab. The Patching page will appear. 5. Select the panel from the Select a Panel pulldown menu. 6.
Page 95 1. Open a supported web browser. Enter the IP address of the PViQ™ Connectivity System that the added connection is being added to. The Login Page will appear. Enter the appropriate username and password. Dashboard page will appear. 3. Select the Network tab. The Network page will appear. 4.
Page 96: Clearing A Cross-Connect Security Violation
secure mode. Clearing a Cross-Connect Security Violation A cross-connect patch cord is a cable that connects between two PViQ™ Connectivity System ports. When the Security Violation is on a port with a cross-connect cable, you will receive two violations, one from each panel at the end point of the cross-connect cable.
Page 97: Clearing A Security Violation For An Unauthorized Remove
PViQ™ Connectivity System panel where the I-Cord is connected. There are two reasons why you may receive a Security Violation from the PViQ™ Connectivity System because of a port associated with a copper interconnect patch cord. 1. An unauthorized remove of one or both ends of the provisioned interconnect patch cord.
Page 98: Clearing A Security Violation For An Unauthorized Remove
Connectivity System because of a port associated with a fiber interconnect patch cord. 1. An unauthorized remove of the PViQ™ Connectivity System side of the provisioned fiber interconnect patch cord. (The Security Policy states that this port should be connected.) 2.
Page 99: Section 9 - Adding/Removing Connections Using Mac Mode And Pviq™ I-Cords
Section 9 – Adding/Removing Connections Using MAC Mode and PViQ™ I-Cords Introduction This section will provide step-by-step scenarios for utilizing the I-Cord and Enhanced I- Cord. NOTE: MAC orders can only be issued through the SmartZone Asset and Connectivity Software Modules. The SmartZone Connectivity Software Module is the minimum SmartZone software required to operate with the PViQ™...
Page 100 2. Connect the 9-wire side of the I-Cord to the Provisioning Port of the PM. The MODE LED becomes a solid green. The target port LED also lights solid green. Figure 54: PM IU and Port during a Guided Add (provisioning connect) 3.
Page 101: Basic I-Cord Connection - Incorrect Switch Port
Figure 57: PMIU and Port when MAC is Complete IMPORTANT NOTE: If the user removes one end of the I-Cord from the patch panel without issuing a work order, a Secure Violation occurs. Simply inserting the I-Cord back into the port will NOT remove the violation in the SmartZone Software. The user MUST perform the provisioning process again.
Page 102 NOTE: If the target panel is an EM, the PM MAC will extinguish when the I-Cord is removed from the Provisioning Port and the EM MAC LED will stay on until the panel port connection is made. 3. Connect the shielded plug end of the I-Cord to an incorrect port on the switch. After a few seconds, the system recognizes the incorrect port.
Page 103: Enhanced I-Cord Connection
Figure 63: Target Port during a Guided Add 6. Remove the I-Cord from the PM Provisioning Port. The MODE LED turns off. Figure 64: PM IU during a Guided Add (moving from provisioning port to target port) 7. Connect the I-Cord to the designated port on the PViQ™ Patch Panel. The MAC LED turns off, the MODE LED changes to green briefly, then the panel returns to Secure Mode if the MAC is complete on this panel.
Page 104 Figure 66: PM IU in MAC Mode 2. Connect the 10-wire side of the I-Cord to the Provisioning Port of the PM. The MODE LED becomes a solid green. The target port LED also lights solid green. Figure 67: PM IU and Port during a Guided Add (provisioning connect) Also, the LED of the Enhanced I-Cord flashes green.
Page 105 The Enhanced I-Cord LED turns off. Figure 70: PViQ™ Enhanced I-Cord during a Guided Add (switch end correct connect) On the PViQ™ Patch Panel, the Port LED to which the cable should be connected begins flashing green. Figure 71: Target Port during a Guided Add 4.
Page 106: Enhanced I-Cord Connection - Incorrect Switch Port
Figure 73: Target Port when MAC is Complete IMPORTANT NOTE: If the user removes one end of the I-Cord from the patch panel without issuing a work order, a Secure Violation occurs. Simply inserting the I-Cord back into the port will NOT remove the violation in the SmartZone Software. The user MUST perform the provisioning process again.
Page 107 2. Connect the 10-wire side of the I-Cord to the Provisioning Port of the PM. The MODE LED becomes a solid green. The target port LED also lights solid green, identifying the correct port for the connection. Figure 75: PM IU and Port during a Guided Add (provisioning connect) Also, the LED of the Enhanced I-Cord flashes green.
Page 108 Figure 78: PViQ™ Enhanced I-Cord during a Guided Add (incorrect switch port connection) 4. Disconnect the far end of the Enhanced I-Cord from the incorrect port. The MODE LED becomes solid green. Figure 79: PM IU and Port during a Guided Add (far-end incorrect connect removed) The LED of the Enhanced I-Cord flashes green.
Page 109 The Enhanced I-Cord LED turns off. Figure 82: PViQ™ Enhanced I-Cord during a Guided Add (switch end correct connect) On the PViQ™ Patch Panel, the Port LED to which the cable should be connected begins flashing green. Figure 83: Target Port during a Guided Add 6.
Page 110: Fiber I-Cord Connection
Fiber I-Cord Connection Adding a connection via a guided MAC is not currently supported. The following procedure provides instructions to make connections using the SmartZone Asset and Connectivity Software Modules Teach option. Additional information on the SmartZone Teach option can be found in the SmartZone Software User Manual. 1.
Page 111: Fiber I-Cord Disconnection
Fiber I-Cord Disconnection The following procedure provides instructions to disconnect a Fiber I-Cord connection using a guided Move, Add or Change (MAC) order from the SmartZone Asset and Connectivity Software Modules. Additional information on the SmartZone Asset and Connectivity Software Modules can be found in the SmartZone Software User Manual. 1.
Page 112: Fiber I-Cord Guided Patching
Figure 89: PM IU when MAC Remove is Complete Fiber I-Cord Guided Patching This section describes the process for adding a connection via a guided MAC. 1. From the SmartZone Asset and Connectivity Software Modules Connectivity window, drag (or cut and paste) a fiber switch port to a location opposite the desired connection patch port.
Page 113 4. The panel signals the end of the MAC by returning to Secure Mode. The SmartZone Asset and Connectivity Software Modules trust that the far end of the I-Cord is connected to the appropriate switch port and displays the Connected icon in the connection cell.
Page 114: Section 10 - Safety, Warranty, Maintenance And Regulatory Information
Warranty Information (http://www.Panduit.com) Maintenance Agreement Panduit also offers a separate Maintenance Agreement, which includes additional benefits and features. Contact your Panduit sales representative for details. Regulatory Information Safety and regulatory compliance For important safety, environmental, and regulatory information, see Safety and Compliance Information on the Panduit website (http://www.Panduit.com)
Page 115: Section 11 - Support And Other Resources
Section 11 - Support and Other Resources Accessing Panduit Support • For live assistance, go to the Panduit.com website. • To access documentation and support services, go to the Panduit.com website. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 116: Section 12 - Acronyms And Abbreviations
Section 12 - Acronyms and Abbreviations This section contains a list and meaning of the acronyms and abbreviations used in this document. Acronym Meaning Command Line Interface DCIM Data Center Infrastructure Management DHCP Dynamic Host Configuration Protocol Expansion Module Expansion Port Cable Graphical User Interface HTTP Hypertext Transfer Protocol...
Page 117: Documentation Feedback
Documentation Feedback Panduit is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (cs@panduit.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document.
Page 118: Appendix A: Pviq™ Connectivity Hardware Installation
Appendix A: PViQ™ Connectivity Hardware Installation Hardware Installation Overview This appendix describes the steps and procedures for installing the PViQ™ Connectivity Hardware. Also refer to the installation instructions that are included in the hardware packaging. This list below represents the components that make up a maximized PViQ™ Connectivity System: •...
Page 119: Panel/Tray Mounting And Grounding
Panel/Tray Mounting and Grounding The first step in the PViQ™ Connectivity System Hardware installation procedure is to connect the patch panels or fiber trays to the rack. This installation includes four 24-port panels – one for the Panel Manager (PM) and three for the Expansion Modules (EMs). PViQ™...
Page 120: Jack Module Installation
Figure 93: PViQ™ Connectivity Panel Installation NOTE: The provided screws must be used to guarantee a good ground connection between panels/trays for proper operation of the PViQ™ Connectivity System. Figure 94: Alternate Acceptable Mounting Screws Jack Module Installation After the PViQ™ Connectivity Panel is secured to the rack or cabinet, the next step is to install terminated jack modules into the patch panel.
Page 121: Installing The Interface Units
If sufficient slack cable is available, the terminated Mini-Com Jack Modules can be installed into the PViQ™ Connectivity Panel prior to permanently mounting into the rack. This will allow for flexibility and provide easier access to the panels. NOTE: The PViQ™ Connectivity Panel accepts all Mini-Com Copper Modules. Figure 95: Side View of Jack Installation Installing the Interface Units The next step is to install the Interface Units (IUs) on the individual panels.
Page 122: Installing The Mounting Bracket
Figure 97: Installing the PM/EM UI It is important to install the correct Interface Unit on the correct patch panel. The Patch Panel that houses the Panel Manager requires an IU with an RJ45 interface jack (provisioning port) located on it. The panels for the Expansion Modules will receive IUs that do not have this Provisioning Port.
Page 123 NOTE: Standard Fiber Trays do not require Mounting Brackets. 1. Locate the mounting bracket on the center of the PViQ™ Connectivity Panel. Figure 100: Mounting Bracket, step 1 2. Pivot the bracket until the tabs on the patch panel rest inside the slots of the mounting bracket.
Page 124 4. Secure the bracket to the patch panel using a Phillips-head screwdriver to push in and turn the securing screw. Figure 103: Mounting Bracket, step 4 Installing the Intelligent Modules With the mounting brackets securely in place, the next step is to install the Intelligent Modules: •...
Page 125 Figure 104: Inserting Module into Mounting Bracket The latch on the bottom of the PM or EM will snap into the slot on the bracket, and an audible “click” should be heard. Figure 105: Bottom Latch Engagement Repeat the process for each of the modules, ensuring that each is firmly locked into place before proceeding.
Page 126 • Daisy chain multiple EMs • Connect multiple PMs together Connection Points Panel Manager connections are made from the back of the unit. The figure below shows the connection points. Figure 106: PM Connections The Expansion Port is used to connect the PM to an EM through the supplied Expansion Port Cable (EPC).
Page 127 PM in the chain. Repeat this procedure for as many PMs as required (up to 30). NOTE: Either LAN connector functions as either an “In” or an “Out” connection. Panduit recommends establishing a standard convention for easier traceability. For example, use the right connector as the “In”...
Page 128 Figure 108: Connection Diagram of a 4 Panel System Table 5: Connection Types Label Connection PM Expansion Port out to EM Expansion Port in EM Expansion Port out to EM Expansion Port in Connection B repeated for an additional EM PM LAN out to PM LAN in Attaching the Power Supply The PViQ™...
Page 129 Attach the appropriate end of the AC cord to the Power Supply. Insert the Power Supply’s angled plug into the PM as shown below. Figure 109: Power Supply Connection Secure the power cable to the PM strain relief with a Pan-Ty cable tie (available separately), as shown below.
Page 130 Table 6: Power Supply Part Number by Region Region Part Number North America PVQ-PS12VDC-S Europe PVQ-PS12VDC-E United Kingdom PVQ-PS12VDC-U Japan PVQ-PS12VDC-J China PVQ-PS12VDC-C Universal PVQ-PS12VDC-UNI Label and Label Cover Installation PViQ™ Connectivity Panels should be labeled according to TIA/EIA-606-A standards. To meet this requirement, the Ultimate ID™...
Page 131 should be installed to protect the label. Four label covers are included with each PViQ™ Connectivity Panel. NOTE: Write-on labels are not included with this patch panel per TIA-EIA-606-A standard which states: “To maximize legibility, all labels shall be printed or generated by a mechanical device and shall not be written by hand.”...
Page 132 System IP Address Finding the IP Address of the Panel Manager A Panduit PViQ™ Connectivity System Utility called pviqutil.exe can be used to find the IP address of all the PMs on a given VLAN. This utility may be downloaded directly from the Panduit.com website.
Page 133 Figure 113: pviqutil Output Example The first column of the output lists all of the IP addresses on this particular VLAN. The second column is a list of the corresponding Media Access Control (MAC) addresses. 6. Find the MAC address of the PM (which you found in Step 1) in this list and note the associated IP address.
Page 134 Appendix C: PViQ™ Connectivity CLI Commands The following lists the available CLI commands and provides definitions and other information for their use. NOTE: From within the CLI, type “?” to receive a listing of all possible commands. Narrow your search by entering a basic command (such as config or show) followed by the “?.”...
Page 135 config ntp { <1,2,3> <NTP-server-ipv4-address (0.0.0.0=undefine)> } | {enable|disable} | {query in-minutes} These three forms configure the Network Time Server IP address, enable or disable NTP, and set the query interval. config password <password> Sets the password for the logged in CLI user to the entered string. config physloc <location>...
Page 136 config snmp –trapon <1-5> <all | none | [crit] [maj] [min] [adv] Enables/disables/filters SNMP v1/v2c traps for the specific receiver. config snmp –write <name> Sets the SNMP v1/v2c write community string. NOTE: Only the first username (default: admin) can execute this command. config timeout <minutes>...
Page 137 quit Ends the telnet session. reset Performs a Reset of the system. There are eight levels of reset available, as described below: reset system <1-8> 1 = reset the PM 2 = reset all the EMs 3 = reset the PM and all EMs 4 = obtain a new IP address from the DHCP Server 5 = clear the SNMP community string 6 = clear the database...
Page 138 email trap number (or set of trap numbers) from the database. Note: the web UI manages traps by Categories which are groups of trap numbers. set email user [add | delete] <email address> Adds an email user (or set of users) to the database, or deletes an email user (or set of users) from the database.
Page 139 set timeout <minutes> By default, the telnet session will timeout after 10 minutes of inactivity. The timeout time is specified in minutes. Maximum value is 30000 minutes (approximately 20 days). set timezone behind:ahead utc number-of-minutes Sets the parameters for system timezone. show Displays the current setting for various parameters within the system.
Page 140 Displays the current MAC address of the PM. show mode Displays the current mode of each panel. show ntpconfig Displays the current NTP settings. show offsetname Displays the current name of each panel. show paneltype Displays a chart of the current Shape, Shielding type and Application for PViQ™ panels.
Page 141 Displays the current setting for time and date. show timeout Displays the current command idle timeout in minutes. show traplog <count> Displays the most recent traps received by the traplog. The number of traps displayed is equal to the <count> parameter. Entering the command without parameters with show all 128 traplog entries.
Page 142 Stops email alerts initiated with the start command. help List available parameters for a given command or lists all available commands. For example: config help PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 143 Appendix D: Output Examples of Common CLI Commands This appendix contains examples of the output for several common CLI commands and gives information on the use. To display the current configuration parameters: PSH > config ip Example 1: config ip To display and change the current modes of the panels: PSH >...
Page 144 Example 3: show mode To display the current Firmware Revision: PSH > show fw Example 4 – show fw NOTE: The screen capture in Example 4 shows the hardware data for the PM (labeled as “PE: 1” or Panel Element 1). The remaining elements are not shown. To display Port information for a given panel: PSH >...
Page 145 Example 5: show port PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 146 Appendix E: Firmware Update Procedure A firmware update may be initiated by the PViQ™ Connectivity Web UI, by the Command Line Interface, or by the SmartZone Connectivity Software Module. General Firmware Update Steps There are common steps that must be executed for performing a firmware update by the Web UI and CLI.
Page 147 IP address of the TFTP server (this information will be needed in future steps). 1. Open a web browser and connect to the Panduit Web site at: https://www.panduit.com/ 2. Download the file(s) and place on your TFTP server.
Page 148 2. Execute the RunStandAloneMT.bat file. 3. Make note of the IP address that is listed on the line that states: a. Listening On: xxx.xxx.xxx.xxx b. Example: Listening On: 192.168.0.250 c. You will need to enter this IP address when performing the PViQ™ Connectivity System Firmware Update.
Page 149 the step 3 of the Executing the Standalone TFTP Server section above. i. Example of the above standalone TFTP server: 192.168.0.250 b. If you are using a TFTP server on your network us the IP address that your network administrator provided for the network TFTP server. 6.
Page 150 Save 5. FW Filename 6. Server IP 7. Delay 10. Disable Beep 8. Max Retry 11. Start Update 9. Retry Interval 11a. Status Figure 114: Network Page (FW Update) CLI Method By default, no users may access the PViQ™ Connectivity System through Telnet. Each user needing Telnet access to the PViQ™...
Page 151 System from firmware version 02.00.00 or later. The .s19 file is used when upgrading the PViQ™ Connectivity System from a firmware version earlier than version 02.00.00. NOTE: Because some operating systems may convert uppercase letters to lowercase, ensure that <filename> contains only lowercase letters. 2.
Page 152 Appendix F: PViQ™ Connectivity System Alarm Categories and Codes There are 18 different alerts supported in the PViQ™ Connectivity System as listed in the Logs Page section above. There are two Management Alerts (1, 999), eight Security Alerts (10, 40, 60, 100, 110, 145, 290, 295) and eight Patching Alerts (20, 30, 45, 50, 70, 80, 90, 140) supported in the PViQ™...
Page 153 Alarm codes assigned for Patching alarms: Category Code Trap Description PViQ mode has changed. I-cord has been connected to a switch. I-cord provisioning cord has failed to detect CDP. I-cord has been disconnected from a Patching switch. Report the switch info for the I-cord that has been connected to a switch port.
Page 154 Appendix G: Interacting with the PViQ™ Connectivity System Interface Units PViQ™ Connectivity System Interface Unit (IU) Overview The PViQ™ Connectivity System has several standard operating modes. These various modes may be accessed through unique combinations of key presses using the Function Keys (the Confirmation Key and Next Key), or through the Web UI.
Page 155 Entering Secure Mode Secure Mode is the default mode after initial power up. It is also the mode to which the system typically returns after resets or following the completion of activities initiated by other modes. Entering Trace Mode To enter Trace Mode: Press and hold the left Function Key of the IU for approximately 2 seconds.
Page 156 Entering Maintenance Mode To Initialize Ports on the PViQ™ Connectivity System in Maintenance Mode: Press and hold both Function Keys on the PM Interface Unit for about 5 seconds. NOTE: Only the PM panel/tray can initiate Maintenance Mode for the PViQ™ Connectivity System.
Page 157 The Maintenance Mode has a default 30-minute time limit before it will exit. Five minutes before this time limit is reached, the panel will begin producing 2 short beeps every 5 seconds, serving as a pre-timeout warning. At any point after these warnings begin, the Maintenance Mode time can be extended for an additional 30 minutes by pressing and releasing the left Function Key, acknowledged by a beep to confirm the request.
Page 158 Performing a Maintenance Mode Reset With the panel in Maintenance Mode Press and hold both Function Keys on the PM Interface Unit. Result: The panel will move through each level of the resets at approximately 5 second intervals. At the end of the initial 5 seconds, the panel will produce a Level 1 reset indication.
Page 159 The panel will also exit Maintenance Mode after a 30-minute period of inactivity. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 160 Appendix H: Changing Your PC to Be a Standalone DHCP Server The PViQ™ Connectivity System is shipped in Dynamic Host Configuration Protocol (DHCP) mode. The only way to initially access the system is to connect it into a network with a DHCP server. If you network does not have a DHCP server, then you will need to create a standalone DHCP server.
Page 161 second lease time of the IP address. d. Save and close the file Figure 119: OpenDHCPServer.ini File Edits 6. You may want to execute the DHCP server from a convenient place. Copy the executable to your desktop on your PC. a.
Page 162 Figure 120: Control Panel 2. In the Control Panel window, select Network and Sharing Center. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 163 Figure 121: Network and Sharing Center 3. Select Change adapter settings from the menu on the left. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 164 Figure 122: Change Adapter Settings 4. Right-click Ethernet and select Properties. Figure 123: Properties 5. Select Internet Protocol Version 4 (TCP/IPv4) (you may need to scroll down). Then click the Properties button. PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 165 Figure 124: Internet Protocol Version 4 (TCP/IPv4) - Properties PVIQ™ CONNECTIVITY SYSTEM USER MANUAL V 1.0...
Page 166 Figure 125: Internet Protocol Version 4 6. Select the Use the following IP address radio button. The Use the following DNS server addresses radio button then selects automatically. 7. Enter the following details into the appropriate boxes: a. IP address: 192.168.0.250 b.
Page 167 Figure 126: Port Configurations WARNING: Do not connect this configured port on this PC to a DHCP network after these changes have been made. If you must connect this wired port to a DHCP network, then you must go back into these settings and change the properties back to “Obtain an IP address automatically”.
Page 168 Figure 127: Open DHCP Server Popup Window 2. Power up the PViQ™ Connectivity System. 3. Use a standard Ethernet Patch cord to connect the provisioned Ethernet port on your PC to the Ethernet port on the back of the Panel Manager module in the PViQ™...
Page 169 Appendix I: Configuring the PViQ™ Panel Manager for Deployment with SmartZone Software The PViQ™ Connectivity System Firmware Web UI version configuration is identical to the pre-Web UI version, except HTTP is enabled. If you are using SmartZone Software but want HTTP disabled, consult this appendix for the steps necessary to disable HTTP. Some customers may not want the web interface.
Page 170 A terminal window will open, wait for the PViQ™ Panel to prompt for a “Username:” Default Username is: admin Default Password is: panduit (or the new password, changed in the earlier steps) 5. Enter the Username. Press Enter. 6. Enter the password. Press Enter.
Page 171 This secure deployment Appendix may be used to train end users and system integrators on the management interfaces of the product that must be secured. To make first time deployment of the product more convenient, Panduit configures all management interfaces with default credentials. These interfaces must be configured appropriately to avoid unexpected access to the product.
Page 172 4409 submission Email for Mail (Authenticated Notification client SMTP) 6387 Panduit PVIQ RPC Device discovery Protocol server Best Practices for Secure Configuration of PViQ To minimize the threat surface of a deployed product, it may be configured to only expose interfaces that are essential to the secure operation of the device.
Page 173 v3Md5User None v3Md5DesUser v3Md5AesUser AES-128 v3ShaUser SHA-1 None v3ShaDesUser SHA-1 v3ShaAesUser SHA-1 AES-128 • Modern SNMP Network Management Station (NMS) or DCIM software provide SHA-1 authentication and AES-128 encryption. o Use the v3ShaAesUser SHA-1, AES-128. o Delete all other users. •...
Page 174 OID (.1.3.6.1.4.1.19536.7.9.3.1.0). User Management • The default user is “admin” and password is “panduit”. Change the password of the admin user on your first login. • Users of the HTTP Web UI and Telnet CLI share a common authentication database.
Page 175  set http off o SNMP may be disabled from the Telnet CLI.  config snmp disable rear o Telnet and SNMP may be disabled from the SNMP MIB. • Do not disable all management interfaces. Only disable the ones that won’t be used.
Page 176 o Change the passwords for the v3ShaAesUser. o Optionally, you may rename the v3ShaAesUser to a new name and use it in future commands. • Use the SNMPv3 Network Management Station or snmpset tool to set the SNMPv3 trap username in the panduitNetSNMPTrapRecvUser OID (.1.3.6.1.4.1.19536.2.2.2.3.2.1.7.1) using the new authentication and encryption passwords: o snmpset -v3 -l authPriv -u v3ShaAesUser -a SHA -A...
Page 177 text for the field shows: Select a file that contains both a TLS Certificate and Private Key. The SmartZone Connectivity panel manager ships with a default certificate. It is recommended that the device administrator create a custom key/certificate pair for each panel manager using the ECC curve SECP256R1. The PM also supports RSA2048 keys.
Page 178 enabled, an App Password may be used. Always use a web browser with https:// to manage the device. Best Practice for Password Complexity/Strength A best practice is to use a non-trivial password. For example, a reasonable password security policy may say: passwords must be 8-32 characters in length, and to have at least one numeric character, and at least one special character.
Page 179 • Level 4 – Set IP configuration to DHCP (factory default) • Level 5 – Clear SNMP community string, SNMP credentials and login credentials to the factory default • Level 6 – Clear the internal PViQ™ Connectivity System database to the factory default, followed by a Level 3 reset •...
