TWO GANG DEEP JUNCTION BOX
Part Numbers: JBP2D, JBD2
©Panduit Corp. 2006
CONDUIT APPLICATION
1"(25.4mm)
IN-WALL BOX APPLICATION
RECTANGULAR
BREAKOUT
POWER/DATA APPLICATION
INSTALLATION INSTRUCTIONS
3/4"(19.05mm)
1/2"(12.7mm)
The mounting hardware used to secure the base shall be appropriate for the mounting surface
RECTANGULAR
BREAKOUT
RACEWAY
BREAKOUTS
For Technical Assistance call: 866-405-6656
FOR USE WITH PANDUIT
SURFACE RACEWAY
ROUTING SYSTEM
DIVIDED INSERT APPLICATION
DATA
POWER
CABLE / ENTRANCE
BREAKOUTS (SOLD SEPARATELY)
Printed in U.S.A.
OPTIONAL USE
FOR DATA
