Power Junction Box
Panduit Part Numbers: JBP1D
©Panduit Corp. 2007
CONDUIT APPLICATION
IN-WALL BOX APPLICATION
DIVIDED INSERT APPLICATION
RACEWAY BREAKOUTS
INSTALLATION INSTRUCTIONS
3/4" (19.05mm)
1/2" (12.7mm)
1"(25.4mm)
RECTANGULAR BREAKOUT
RACEWAY
BREAKOUTS
For Technical Assistance call: 800-777-3300
FOR USE WITH PANDUIT
SURFACE RACEWAY
ROUTING SYSTEM
The mounting hardware
used to secure the base
shall be appropriate for the
mounting surface
