echoflex ELED3 Installation Manual

Echoflex Installation Guide
Tri-Zone Dimming Controller

Overview

The ELED3 Tri-Zone Dimming
Controller is a wireless controller
with three channels to control
lights in larger spaces based on
room occupancy state, manual
switch operation, ambient light
level and gateway commands.
This document covers installation
of ELED3 Tri-Zone Dimming
Controller models. The Echoflex
Tri-Zone Dimming Controller
ELED3 Configuration Guide is
available for download at
echoflexsolutions.com.
The package contents includes the
controller and the installation guide.

Prepare for Installation

Echoflex recommends paying special attention to the installation
environment.
• High density construction materials and large metal appliances or
fixtures in the space may disrupt wireless reception.
• Mount the controller to an electrical junction box or a panel in a
location and at a height where it is not subject to tampering by
unauthorized personnel.
Supplies required to install the controller (not provided):
• Appropriately sized wire nuts
• Wire insulation
• Small cable ties
Corporate Headquarters Middleton, WI, USA
Web echoflexsolutions.com
© 2021 Echoflex Solutions, Inc. Trademark and patent info:
Echoflex intends this document to be provided in its entirety. Product information and specifications subject to change.
8189M2110 Rev A Released 2021-03
|
Phone +1 608 831 4116
|
Email info@echoflexsolutions.com
High voltage
model shown
|
