MAULE
Airplane Serial No.__________________
Airplane Serial No.__________________
Registration No.____________________
Registration No.____________________
THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES.
THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES.
THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES.
FAA APPROVED: _____________________
DATE:
DATE
Performance That Counts!
2099 Georgia Highway 133 South • Moultrie, GA 31788 •
2099 Georgia Highway 133 South
(229) 985-2045 •
Fax: (229) 985-2048 or (229) 890-2402 •
FAA APPROVED
FOR
MX-7-180C
Manager, Aircraft Certification Office
anager, Aircraft Certification Office
Federal Aviation Administration
Federal Aviation Administration
Atlanta, Georgia USA
August 26, 1996
www.mauleairinc.com
www.mauleairinc.com
Advertisement
Table of Contents
Related Manuals for MAULE MX-7-180C
Summary of Contents for MAULE MX-7-180C
- Page 1 FAA APPROVED MAULE MX-7-180C Airplane Serial No.__________________ Airplane Serial No.__________________ Registration No.____________________ Registration No.____________________ THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES. THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES. THIS DOCUMENT MUST BE KEPT IN THE AIRPLANE AT ALL TIMES.
-
Page 2: Log Of Revisions
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MX-7-180C Page i Page i LOG OF REVISIONS REV. DESCRIPTION APPROVAL AND DATE APPROVAL AND DATE PAGES Corrected crosswind component ( Corrected crosswind component (Ref. 3.3.F.) 2,17, Revised C.G. Range Revised C.G. -
Page 3: Log Of Supplements
Inst. of S-TEC System 50 Two Axis Autopilot ST-609-50 (28v) - Maule Dwg 9200A. 02/14/00 Inst. of S-TEC System 55 Two Axis Autopilot ST-620 (14v) - Maule Dwg 9196A. (Land) 04/04/00 Inst. of S-TEC System 55 Two Axis Autopilot ST-620 (14v) - Maule Dwg 9196A. (Sea) 04/04/00 Inst. -
Page 4: Table Of Contents
MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MX-7-180C Page iii TABLE OF CONTENTS ITEM COVER PAGE LOG OF REVISIONS…………………………………………………….. i LOG OF SUPPLEMENTS……………………………………………..… ii TABLE OF CONTENTS………………………………………………..iii & iiii GENERAL SECTION I Plan View………………………………………………………….. Maximum Weight…………………………………………. 2 Center of Gravity Limits…………………………………. -
Page 5: Table Of Contents
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. AIRPLANE FLIGHT MANUAL MAULE MX-7-180C Page iiii TABLE OF CONTENTS WEIGHT AND BALANCE AND EQUIPMENT LIST WEIGHT AND BALANCE AND EQUIPMENT LIST WEIGHT AND BALANCE AND EQUIPMENT LIST SECTION V Weight and Balance Data……………………………….. -
Page 6: Plan View
MAULE AEROSPACE TECHNOLOGY, INC. SECTION I AIRPLANE FLIGHT MANUAL GENERAL MAULE MX-7-180C PAGE 1... -
Page 7: Section I
MAULE AEROSPACE TECHNOLOGY, INC. SECTION I AIRPLANE FLIGHT MANUAL GENERAL MAULE MX-7-180C SECTION I GENERAL: NORMAL CATEGORY OPERATION MAXIMUM WEIGHT: 2500 Pounds CENTER OF GRAVITY LIMITS: +15.9 to +20.5 @ 2500 lbs. +12.4 to +20.5 @ 1740 lbs. or less... -
Page 8: Limitations
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION II AIRPLANE FLIGHT MANUAL LIMITATIONS MAULE MX-7-180C SECTION II LIMITATIONS AIRSPEED LIMITS: All airspeeds are Indicated Airspeeds (IAS). : All airspeeds are Indicated Airspeeds (IAS). A. AIRSPEED INDICATOR MARKINGS: AIRSPEED INDICATOR MARKINGS:... -
Page 9: Power Plant Limits
MAULE AEROSPACE TECHNOLOGY, INC. SECTION II AIRPLANE FLIGHT MANUAL LIMITATIONS MAULE MX-7-180C POWER PLANT LIMITS: Engine: Lycoming O-360-C1F Engine Limits: 180 hp @ 2700 rpm, Full Throttle Continuous Propeller: Hartzell Constant Speed HC-C2YR-1BF/F7666A (76") Fuel: 100/100LL Minimum Grade Aviation Gasoline... -
Page 10: Flight Load Factors
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION II AIRPLANE FLIGHT MANUAL LIMITATIONS MAULE MX-7-180C FLIGHT LOAD FACTORS: FLIGHT LOAD FACTORS: Flaps Fully Retracted: 3.8g Positive to 1.5g Negative ve to 1.5g Negative Flaps Extended: 1.9g Positive to 0g Negative Flaps Extended: 1.9g Positive to 0g Negative... - Page 11 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION II AIRPLANE FLIGHT MANUAL LIMITATIONS MAULE MX-7-180C PLACARDS: (Cont’d) On the instrument panel at the On the instrument panel at the optional auxiliary tank transfer switches: FUEL TRANSFER PUMPS PUSH FOR...
-
Page 12: Normal Procedures
MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES SECTION III NORMAL PROCEDURES: NORMAL PROCEDURES: PREFLIGHT INSPECTION: PREFLIGHT INSPECTION: A. INTERIOR: BAT Switch…………………………………... BAT Switch…………………………………..ON Fuel Gauges………………………………… Fuel Gauges…………………………………… CHECK INDICATIONS CHECK INDICATIONS Auxiliary Fuel Pumps………………………... -
Page 13: Operating Check Lists
MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES PREFLIGHT INSPECTION: (Cont'd) Right Landing Gear…………………………… CHECK TIRE INFLATION & BRAKE LINE SECURITY Right Wing & Controls……………………….. INSPECT SAME AS LEFT WING Wing Main & Aux Fuel Tank Drain…………. DRAIN (2) Right Fuselage, Side, Top &... - Page 14 MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES OPERATING CHECK LISTS: (Cont'd) NOTE: FOR A HOT START, DO NOT PRIME. A HOT ENGINE MAY FLOOD ON A START ATTEMPT. TO CLEAR A FLOODED ENGINE, PULL MIXTURE FULL LEAN AND OPEN THROTTLE, CRANK WITH STARTER.
- Page 15 MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES D. BEFORE TAKEOFF: Fuel Selector………………………………….. ON FULLEST TANK OR BOTH Flaps…………………………………………… AS DESIRED FOR T.O. (MAX. 24°) Trim Controls………………………………..SET FOR TAKEOFF Flight Controls………………………………… CHECK FOR FREEDOM AND PROP- ER TRAVEL Mixture Control…………………………….….
-
Page 16: Normal Flight Operations
MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES NORMAL FLIGHT OPERATIONS: A. NOTE: FLAP SETTINGS: The following Flap Settings are available: Flap Configuration Flap Handle Position Flap Position Cruise Handle Full Down -7° Flaps Up First Notch 0°... - Page 17 MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES NORMAL FLIGHT OPERATIONS: (Cont’d) D. RUDDER TRIM: NOTE: To assure full effectiveness of the Right Rudder Trim: Unlock "T" handle (½ turn left), depress right rudder as you pull "T" handle full out.
-
Page 18: Door-Off Operation
MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES DOOR-OFF OPERATION: This aircraft may be operated with either one (not both) of the front doors removed, or when both front doors are installed, with the rear passenger door or rear passenger and baggage doors off. -
Page 19: Emergency Procedures
MAULE AEROSPACE TECHNOLOGY, INC. SECTION IV AIRPLANE FLIGHT MANUAL EMERGENCY MAULE MX-7-180C PROCEDURES SECTION IV EMERGENCY PROCEDURES EMERGENCY BASIC RULES: To assist the pilot when an emergency occurs, three basic rules are established which apply to most emergencies occurring while airborne. They should be remembered by each crew mem- ber. -
Page 20: Partial Power Failure During Flight Of After T.0
MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES ENGINE FAILURE AFTER TAKEOFF OR FORCED LANDING: (Cont’d) Switch Fuel Selector to fullest tank Electric Fuel Pump - ON Mixture Rich, Ignition ON Alternate Air Control - Pull ON... -
Page 21: Engine Fire During Flight
MAULE AEROSPACE TECHNOLOGY, INC. SECTION III AIRPLANE FLIGHT MANUAL NORMAL MAULE MX-7-180C PROCEDURES 4.12 ENGINE FIRE DURING FLIGHT: Accomplish ENGINE EMERGENCY SHUT DOWN Make forced landing 4.13 SMOKE AND FUME ELIMINATION: Cabin Heat Knob - IN Cabin Air Knob - IN... - Page 22 MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE SECTION V WEIGHT AND BALANCE Serial Number______________________ Registration Number______________________ It is the responsibility of the airplane owner and the pilot to insure that the airplane is loaded properly.
- Page 23 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE WEIGHT AND BALANCE: WEIGHT AND BALANCE: (Cont'd) DETAILED CALCULATIONS OF EMPTY WEIGHT AND EMPTY WEIGHT CENTER OF DETAILED CALCULATIONS OF EMPTY WEIGHT AND EMPTY WEIGHT CENTER OF...
- Page 24 MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE WEIGHT AND BALANCE: (Cont'd) The above empty weight includes unusable fuel of ** lbs. at 24 inches and 8 quarts of oil at minus 36.5 inches, plus all items of equipment as marked on the accompanying Equipment Lists.
- Page 25 MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE FORM 68 PAGE 20...
- Page 26 MAULE AEROSPACE TECHNOLOGY, INC. MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE FORM 68 PAGE 21 Rev. E dated:...
- Page 27 MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE FORM 68 PAGE 22...
- Page 28 MAULE AEROSPACE TECHNOLOGY, INC. SECTION V AIRPLANE FLIGHT MANUAL WEIGHT AND MAULE MX-7-180C BALANCE SERIAL NO._________________REG.NO.__________________MODEL__________________ EQUIPMENT CHANGE - WEIGHT AND BALANCE ITEM'S (MAKE & MODEL) WEIGHT MOMENTS Previous Aircraft Empty New Empty Weight ______________________lbs. New Empty Center of Gravity ______________ins.
- Page 29 It is recommended that owner's name, address and aircraft serial number be registered with Maule Air (ext. 0) for any Maule Se name, address and aircraft serial number be registered with Maule Air (ext. 0) for any Maule Se name, address and aircraft serial number be registered with Maule Air (ext.
