MRC 0001659 Quick Start Manual

TESTING
All MRC decoders have been factory programmed with address #3, 28/128 speed steps and
maximum top voltage. Never run the installed decoder on your layout without first
successfully running on test track. Otherwise, you may damage the decoder if it is not
wired correctly or if you have not properly isolated the motor, chassis and lights.
To test, place the loco on the test track. Select the "Run" mode of your DCC system and select
or acquire address #3. Move up the throttle and the loco should move forward. Push the light
button [F0] and the front headlight should come on. Change the direction of the loco and the
loco should change direction and the rear headlight (if equipped) should come on. The loco
cannot reach full speed, due to the resistor. If all above occurs, you passed the test. Con-
gratulations!
Do not run the loco for an extended period of time on the test track or the resistor
will overheat.
If your installed decoder does not pass the test, find the problem, correct it and test it again.
TROUBLE SHOOTING
The MRC 0001659 N gauge decoder should perform well with all DCC systems. See your DCC
system manual to learn how to program and operate the decoder. For more information about
register/CVs and their functions, please refer to the NMRA DCC Standard & Recommended
practices, RP-9.2.2 this is available directly from the NMRA or their website at
www.nmra.org.
Whenever the decoder doesn't work please use program track to re-program the loco address
to factory setting. This should bring the decoder to life.
FCC COMPLIANCE
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions. (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that cause undesired operation.
RETURN PROCEDURE
If it should become necessary to return your decoder, remove the decoder from the loco chassis
and return the decoder only. Please include a letter, [printed clearly], with your name, address,
daytime phone number, and a detailed description of the problem you are experiencing. Include a
$15.00 check to cover shipping and handling.
Warranty does not include abuse, neglect, or using this product for anything other
than it's intended purpose. Warranty coverage will be handled on a case by case basis,
and other charges may apply for repair/replacement of the product.
Send the decoder to:
Model Rectifier Corporation
Attn: Parts & Service
80 Newfield Avenue
Edison, NJ 08837-3817 U.S.A
     2008 MODEL RECTIFIER CORPORATION
80 NEWFIELD AVENUE
EDISON, NJ 08837-3817
Thank you for purchasing our highly advanced DCC locomotive decoder.
Combined with any DCC System, our new decoder makes your model
railroad come to life.
Printed in USA
N Gauge DCC Decoder
Item #0001659 for Kato F Unit
• 1.0 amp capacity
• Programmable for either 2-digit (1-127) or 4-digit (1-9999) ad-
dresses
• Programmable start voltage
• Programmable acceleration rate
• Programmable deceleration rate
• Programmable top voltage
• Programmable 14, 28, 128 speed steps
•
Supports advanced consisting (CV19)
• Supports programming on the main (OPS mode)
• Compatible with NMRA DCC standards
• Complies with Part 15 of FCC regulations
• Directly replaces original PC Board
• Directional headlight (F0)
