MRC 0001657 Quick Start Manual

PROGRAMMING
This decoder supports all programming methods including: register, paged CV,
direct CV, and programming on the main (ops mode programming).
CV Regis ter Description
CV1 R1 Short address
CV2 R2 Start voltage
CV3 R3 Acceleration
CV4 R4 Deceleration
CV5 --- Top voltage
--- R6 Page number
CV29 R5 Basic configuration
CV7 R7 Manuf acturer version number
CV8 R8 Manufacturer ID
CV17 --- Long address upper byte
CV18 --- Long address low er byte
CV19 --- Advanced consist address
When CV21=0, all accessory functions w ill f ollow
CV21 --- its ow n address. When CV21=1, all f unctions w ill
f ollow the consist address
CV49 Sound on/off (0=on)
CV50 --- Horn type
CV51 --- Horn volume
CV52 --- Bell type
CV53 --- Bell volume
CV54 --- Bell ring rate
CV55 --- Diesel rumble volume
CV56 --- Brake squeal volume
CV57 --- Dynamic brake volume
CV58 --- Air release volume
CV59 --- Air pump volume
CV60 --- Safety pop valve volume
CV61 --- Engine cooling fan volume
CV62 --- Coupling volume
CV63 --- Random noise volume
CV64 --- Rail w heel clack
CV105 --- User identification number
CV106 --- User identification number
CV112 --- Exhaust volume
CV113 --- Coupling f ire volume
CV114 --- Light brightness (green, brow n)
CV115 --- Auto brake squeal enable/disable
CV116 --- Coupling sound type
CV117 --- Lights enable/disable
CV118 --- Accessory light #1configuration
CV119 Accessory light #2configuration
CV120 Brake release volume
Diesel sound type (0=of f, 1=rpm & notch synchro
CV122 to speed, 2=linear rpm synchro to speed, 3=notch
up/dow n (F8=notch dow n, F9=notch up))
Speed curve select (0=linear, 1=slow increase at
CV124
slow speed, 2=f ast increase at slow speed
Factory default setting: Programming to 1 w ill
CV125 ---
restore all CV's to default setting
NOTE: Due to limitations in older DCC systems, some of the sound functions or
light effects functions may not accessable. ALSO, you might be limited to factory
default CV values.
LIGHT EFFECTS WIRING
Your MRC Synchronized Diesel Sound Decoder is equipped with normal
directional lighting, plus MRC light effects. If your loco has ditch lights, mars light
or strobe light, you can solder wires to the four solder tabs (2 pairs marked with
Range Default
ACC1,ACC2) on the bottom of the decoder. The two center solder tabs are the
1-127 3
common for the accessory light effects.
0-32 0
0-32 0
All the decoder's light outputs are track output voltage (around
0-32 0
14V) supplied by your DCC system. They are designed for 12V
0-32 32
light bulb. Please contact your loco manufacturer for lights'
--- ---
operation voltage. If you have a 1.5V bulb use 1k ohm resistor or
--- 2
LED, you should connect a 2k ohm resistor in series to one of the
--- 32
leads to limit current.
--- 143
192-231 192
TROUBLE SHOOTING
0-255 3
The MRC 0001657 HO diesel sound decoder should perform well with all DCC
0-127 0
systems. See your DCC system manual to learn how to program and operate the
decoder. For more information about register/CVs and their functions, please
--- 0
refer to the NMRA DCC Standard & Recommended practices, RP-9.2.2 this is
available directly from the NMRA or their website at www.nmra.org.
0-1 0
0-1 0
Due to the nature of all sound decoders, the CV read back is not 100% correct.
0-3 0
This is not a defect of the decoder or your DCC. Whenever the decoder doesn't
0-1 2
work please use program track to re-program the loco address or program CV#
0-3 3
125 with value 1 to restore the decoder to factory setting. This should bring the
0-50 3
decoder to life.
0-3 3
0-3 3
FCC COMPLIANCE
0-3 3
This device complies with the part 15 of FCC rule. Operation is subject to the
0-3 3
following two conditions. (1) This device may not cause harmful interference,
0-3 3
and (2) This device must accept any interference received, including interfer-
0-3 3
ence that cause undesired operation.
0-3 3
0-3 3
RETURN PROCEDURE
0-3 3
0-3 3 If it should become necessary to return your decoder, unplug the decoder and
return the decoder only. Please include a letter (printed clearly) with your name,
0-255 0
address, a daytime telephone number, and a detailed description of the problem
0-255 0
you are experiencing. Please also include a $15.00 check to cover shipping and
0-3 3
handling. Be certain to return only the decoder.
0-3 3
Warranty does not include abuse, neglect, or using this product for
0-12 3
anything other than it's intended purpose. Warranty coverage will be
0-1 1(enable)
handled on a case by case basis, and other charges may apply for
0-2, 2=off 1
repair/replacement of the product.
0-1 1(enable)
Send the decoder to:
0-6 0
Model Rectifier Corporation
0-6 0
Attn: Parts & Service
0-3 3
80 Newfield Avenue
Edison, NJ 08837-3817 U.S.A
0-3 1
0-2 0
--- 0
     2007 MODEL RECTIFIER CORPORATION
80 NEWFIELD AVENUE
EDISON, NJ 08837-3817 Printed in USA
HO Gauge Synchronized
Diesel Sound Decoder with
28 Accessory Functions
Item #0001657
Thank you for purchasing our highly advanced DCC locomotive
sound decoder. Combined with any DCC System, our new
decoder with "Camegie Hall" sound quality will make your model
railroad come to life.
• Synchronized diesel prime mover with randomly associated
locomotive sounds
• 1.5 amp capacity
•
Programmable choice of 2 different horns and 2 bells
• Programmable individual sound volumes
• Programmable for either 2-digit (1-127) or 4-digit
(1-9999) addresses
• Programmable start voltage
• Programmable acceleration rate
• Programmable deceleration rate
• Programmable top voltage
• Programmable 14, 28, 128 speed steps
• Selectable factory default speed curve
•
Directional lighting (FO) at 0.2 amp rate
•
Programmable for either ditch lights, mars light, gyra
light andprime strobe light
• 28 accessory functions (F1-F28)
• Supports advanced consisting (CV19)
• Supports programming on the main (OPS mode)
• Compatible with NMRA DCC standards
• NMRA 8 pin plug included for easy installation
• Complies with Part 15 of FCC
• 20mm speaker with baffle included (other size, aftermar-
ket speakers are available from MRC)
• Dimensions: 46.0mm x 17.5mm x 5.0mm
• The decoder can be upgraded to all the horns included
in the Demo F19, and more choices of bells.
