PARTS INCLUDED
1. (1) Elastic Band
2. (1) MAGIC MOUNT™w/ Mounting Plates
3. (1) 1.5" Extension Bar
4. (2) Adjustment Knobs w/ Washers
www.scosche.com/register
TerraClamp
™
Brake /Clutch
5. (1) Clutch/Brake Mount w/ ball Joint
6. (4) Screws (Not Shown)
7. (2) Lock Washers (Not Shown)
8. (2) Spacers (Not Shown)
PSM11014
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Scosche TerraClamp MAGICMOUNT PSM11014
Summary of Contents for Scosche TerraClamp MAGICMOUNT PSM11014
- Page 1 Register your product online at � SCDSCI-IE" PSM11014 TerraClamp ™ MAGICMOUNT Brake /Clutch PARTS INCLUDED 1. (1) Elastic Band 5. (1) Clutch/Brake Mount w/ ball Joint 2. (1) MAGIC MOUNT™w/ Mounting Plates 6. (4) Screws (Not Shown) 3. (1) 1.5" Extension Bar 7.
- Page 2 MOUNTING THE MAGICPLATE'" OPTION 1 (small or large plate) OPTION 2 (small or large plate) Attach adhesive side of metal plate Attach adhesive side of metal plate directly to back of device directly to back of case OPTION 3 (large plate only) Attach adhesive side of metal plate to interior of case, between device and inside of case.
- Page 3 5. Mount the brake/clutch ball joint to the mounting adapters (E). 6. Tighten the clutch/brake assembly to the extension bar (F) using the knob tightener provided (G), see brake/clutch assembly above for potential final look. For complete warranty details, please visit us at www.scosche.com or call (BOO) 363-4490...
- Page 4 MAGICMOUNT™ 360 (H). Once the position is set, tighten the knob (G) to secure the positioning MAGICMOUNT™. NOTE: When loosened the angle of the MAGICMOUNT™ is capable of ° rotation for positioning. ©2018 SCOSCHE INDUSTRIES, INC. SI 300PSM11014 02/18...
