LTU-Pro Quick Start Guide
Click for
Package Contents
Table of Contents
LTU-Pro
Bracket Clamp
Gigabit PoE (24V, 0.5A) with
Mounting Bracket
Installation Requirements
LTU PtMP AP, such as model LTU-Rocket
13 mm wrench
Surge protection should be used for all outdoor installations. We recommend that you use
two Ethernet Surge Protectors, model ETH-SP-G2, one near the device and the other at the
entry point to the building. The ETH-SP-G2 will absorb power surges and safely discharge
them into the ground.
Note:
http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]
LTU-Pro Quick Start Guide
×
Carriage Bolts (Qty. 2)
For guidelines about grounding and lightning protection, follow your local
Mount Bracket
Power Cord
Bracket Clamp
Flange Nuts (Qty. 2)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ubiquiti LTU-Pro
Summary of Contents for Ubiquiti LTU-Pro
- Page 1 LTU-Pro Quick Start Guide LTU-Pro Quick Start Guide × Click for Package Contents Table of Contents LTU-Pro Mount Bracket Bracket Clamp Bracket Clamp Carriage Bolts (Qty. 2) Flange Nuts (Qty. 2) Gigabit PoE (24V, 0.5A) with Power Cord Mounting Bracket...
-
Page 2: Hardware Overview
LTU-Pro Quick Start Guide electrical regulatory codes. Outdoor, shielded Category 6 (or above) cabling and shielded RJ45 connectors are required for all wired Ethernet connections. Hardware Overview http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]... - Page 3 LTU-Pro Quick Start Guide Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the device is powered on. USB-C Port Reserved for future use. 5 GHz LED http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
-
Page 4: Pole Mounting
The LED will light blue when the GPS signal strength is Blue sufficient. This requires a minimum of three satellite connections. UNMS LED Flashing White Bootup in progress. Ready for use, not connected to Ubiquiti® Network White Management System (UNMS™). See “UNMS Management”. Blue Ready for use, connected to UNMS. - Page 5 LTU-Pro Quick Start Guide http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
- Page 6 LTU-Pro Quick Start Guide http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
- Page 7 LTU-Pro Quick Start Guide http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
- Page 8 LTU-Pro Quick Start Guide http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
- Page 9 LTU-Pro Quick Start Guide http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
-
Page 10: Connecting Power
LTU-Pro Quick Start Guide Connecting Power WARNING: The switch port must comply with the power specifications listed in the “Specifications”. http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]... -
Page 11: Accessing The Configuration Interface
LTU-Pro Quick Start Guide Optional Accessing the Configuration Interface 1. Make sure that your host system is connected via Ethernet to the device. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. - Page 12 LTU-Pro Quick Start Guide The LTU Configuration Interface will appear, allowing you to customize your settings as needed. To have your AP configure your device, proceed to “Find My AP”. UNMS Management You can manage your device using UNMS, which lets you configure, monitor, upgrade, and back up your devices using a single application.
-
Page 13: Installer Compliance Responsibility
LTU-Pro Quick Start Guide 3. Click Find AP. 4. The device will scan for nearby APs. Click Select for the appropriate AP. To run the search again, click Scan. 5. Follow the on-screen instructions. Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer’s responsibility to make sure the device is operated within local country regulatory requirements. -
Page 14: Specifications
LTU-Pro Quick Start Guide The Auto Output Power field is provided to the professional installer to assist in meeting regulatory requirements. Specifications LTU-Pro Dimensions 316.5 x 316.5 x 174.3 mm (12.46 x 12.46 x 6.86") Weight 1.3 kg (2.87 lb) -
Page 15: Safety Notices
LTU-Pro Quick Start Guide Operating Temperature -40 to 60° C (-40 to 140° F) Operating Humidity 5 to 95% Noncondensing Certifications CE, FCC, IC Operating Frequency (MHz) Worldwide 2400 - 2483.5* 4800 - 6200* US/CA U-NII-1 5150 - 5250 U-NII-2A... -
Page 16: Limited Warranty
LTU-Pro Quick Start Guide e. Protective bonding must be installed in accordance with local national wiring rules and regulations. Limited Warranty ui.com/support/warranty The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions. -
Page 17: Australia And New Zealand
LTU-Pro Quick Start Guide Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. IMPORTANT NOTE Radiation Exposure Statement This equipment complies with radiation exposure limits set forth for an uncontrolled environment. -
Page 18: Weee Compliance Statement
Operation in the 5.8 GHz frequency band is prohibited in BFWA member states. Other countries listed may use the 5.8 GHz frequency band. WEEE Compliance Statement Declaration of Conformity Online Resources © 2020 Ubiquiti Inc. All rights reserved. http://dl-origin.ubnt.com/qsg/LTU-Pro/LTU-Pro_EN.html[05.02.2020 14:09:00]...
