3. FEATURES

2 Lines x 16 Characteres
a
Very Low Consumption.
a
Microprocessor Controlled. -Two years Factory Warranty. -Menu
a
Driven.
Accurate Digital readout of Disconnection
a
Automatic Data Hold Function.
a
Zero Crossing Circuitry permit testing at 00 or 1800.
a
Disconnection Phase Polarity Shown on L.C.D. display.
a
Auto-Off and Off override.
a
Polarity Trip Indicator ( Positive or Negative Phase )
a
Wiring Polarity Indicator.
a
Measure voltage between Line and Earth before testing.
a

4. CONNECTIONS

Earth (Ground)
probe connection
apply only Voltage Model @ 50Hz or 60 Hz. Voltage Model (Vac) 230 V
©Copyright Abacanto Digital SA.
Neutral probe
connection
Earth Neutral Line phase
Manual de usuario AD4112
AD Instruments
Time.
Line (Hot) probe
connection
