Airbags for Damage Prevention
SuperFlow Safety
& Operation Instructions
Prior to connecting the inflator to
hose, wrap threads (1/4 NPT) with
Teflon tape. Screw on inflator until
tight.
6
Set compressor regulator to
appropriate settings (see chart
on back). Additional assistance is
available from an ITW Shippers
representative.
Position the air bag at least 1"
above the floor to keep if from
rubbing in transit.
Squeeze trigger to begin inflation.
When air blows out of the back of
the inflator, desired pressure has
been achieved.
Remove inflator and attach valve
cap. Ensure that cap is tightly
secured.
Create a bulkhead. The air bag is
properly installed when Zebra
stripes touch lading. If stripes show,
and you can read the warning
"if you can read this, the void is
too large", deflate air bag and
reduce the void.
To deflate, simply unscrew cap
and gently press blue flapper to
release air.
Place air bag into container.
Weight of additional air bags will
complete deflation process.
TM
Advertisement
Table of Contents
Related Manuals for ITW SuperFlow
Summary of Contents for ITW SuperFlow
- Page 1 Teflon tape. Screw on inflator until tight. Set compressor regulator to appropriate settings (see chart on back). Additional assistance is available from an ITW Shippers representative. Position the air bag at least 1” above the floor to keep if from rubbing in transit.
- Page 2 Do’s and Don’ts for using ITW Shippers Products’ SuperFlow inflation system Do’s: Don’ts: Use filter and regulator on air line. NEVER use inflator as blowgun for cleaning. Position the air bag approximately 1” above the NEVER obstruct rear vacuum opening while floor to keep it from rubbing in transit.
