Appendix Technical Data - FP PostBase Dynamic Scale Operator's Manual

24
PostBase Vision Dynamic Scale
Appendix
Technical Data
This chapter contains the technical data of the PostBase Dynamic Scale.
The technical data for all other system components of the PostBase Vision franking
system, information on the ink cartridge, the mail piece and envelope specification,
as well as the licence information and the data security declaration, can be found in
the PostBase Vision – Installation and safety manual, which you received together
with the PostBase Vision franking machine.
Dimensions *
– Length
– Width
– Height
Weight *
Power connection
Power consumption
Noise emission
Operating conditions
* Values without packaging
Subject to short-term modification.
471 mm (18.6")
440 mm (17.3")
220 mm (8.7")
10,0 kg (22.1 lb)
100 - 240 V / 1,5 A / 50 - 60 Hz
60 W
< 70 dB(A)
+15 °C to +35 °C (59 °F to 95 °F)
Only use in closed rooms
Do not expose to direct sunlight
Rel. humidity 15 % to 80 % non-condensing
