Document information
Title of document:
Revision:
Edition (YYYY-MM):
Type of document:
Status:
Validity
Sensors and connectors covered by this document:
Product
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
Rev. 1.5 2018-02
IRMA MATRIX R2 Option Door Contact | Mounting Manual
1.5
2018-02
Customer documentation
released
Item Type Item
DIST500-A DIST500.7-A07.OC
DIST500-F DIST500.7-F07.OC
sCON-S sCON-S-ETH-22-Kn-x-y
sCON-S sCON-S-CAN-ETH-23-K2-x-y
sCON-S-CAN-20-Kn-x
sCON-S
sCON-S-CAN-21-Kn-x-y
sCON-F-12 sCON-F-12-CC-E
sCON-F-12-PoE sCON-F-12-PoE-CC-E
Description
Sensor of the
surface mount version
Sensor of the
flush mount version
Connector (standard) with an
Ethernet interfaces for MATRIX
sensors
Connector (standard) with CAN
and Ethernet interfaces for MATRIX
sensors
Connector (standard) with a CAN
interface for MATRIX sensors
Connector and fixing unit IRMA
MATRIX,1 x Ethernet M12, 2 x CAN
M12,
Connector and fixing unit IRMA
MATRIX, 1 x Ethernet M12, PoE
power supply
