- Page 1 Automatic Passenger Counting IRMA – Infrared Motion Analyzer Generation IRMA MATRIX R2 Option Door Contact Mounting Manual iris-GmbH | Ostendstrasse 1 – 14 | 12459 Berlin | Germany Rev. 1.5 | 2018-02 Subject to alterations!
- Page 2 2/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Document information Title of document: IRMA MATRIX R2 Option Door Contact | Mounting Manual Revision: Edition (YYYY-MM): 2018-02 Type of document: Customer documentation Status: released Validity Sensors and connectors covered by this document:...
-
Page 3: Table Of Contents
3/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Contents General .......................... 4 On this document .......................... 4 Symbols / abbreviations used ....................4 Important information when working with IRMA MATRIX sensors ........ 4 Option: IRMA MATRIX sensor with door contact ............5 Mounting of the surface mount version with door contact magnet ...... -
Page 4: General
A cove is a vehicle interior lining - here in particular above the door, into which the sensor is to be Cove fitted. Important information when working with IRMA MATRIX sensors IRMA MATRIX sensors must only be installed by qualified expert staff trained by iris GmbH and observing the pertinent regulations and the installation manual. Rev. 1.5 2018-02... -
Page 5: Option: Irma Matrix Sensor With Door Contact
5/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released All considerations on the installation position and orientation of the sensors are based on the assumption that the viewer is inside the vehicle. Option: IRMA MATRIX sensor with door contact Optionally a door contact magnet (electromagnet) is available which can be fitted for signalization of the door status. - Page 6 6/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released IRMA MATRIX sensor, surface mount version 3.1 Lugs of the magnet support Mounting set sCON connector with CAN/Ethernet interface Door contact magnet (also referred to as Chassis or cove above the door "magnet") with support...
- Page 7 7/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Align the holding lugs parallel to the sensor position (see photo on the left). Rear of the sensor: The round magnet and the support lugs must come to sit in the recesses.
-
Page 8: Flush Mount Version With Door Contact Magnet
8/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Flush mount version with door contact magnet Mounting with sCON-Standard (S) Fig. 2: Flush mount version: mounting of door contact magnet with sCON-S sCON connector for sensors 3.3 2 holes for the cylinder head screws for... - Page 9 9/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Mounting with sCON-F-12-PoE Fig. 3: Flush mount version: mounting of door contact magnet with sCON-F-12-PoE sCON-F-12-PoE connector for PoE cable on ETH connection sensors Cove (here e.g. 4 mm thick)
- Page 10 10/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Mounting with sCON-F-12 Fig. 4: Flush mount version: mounting of door contact magnet with sCON-F-12 sCON-F-12 connector for ETH connecetion sensors CAN connection Cylinder head screws (2 screws) Cove (here e.g. 4 mm thick)
- Page 11 11/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Rear side of the sensor: The round magnet must come to sit in the recess. When mounted, the sensor is located on the left and towards the vehicle outside marked with "Exterior"...
- Page 12 12/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released With the following connectors sCON-F-12-PoE and sCON-F-12, you mount the door contact magnet on the sCON connector first and afterwards you mount the sCON connector including the magnet on the sensor (with the cove between the two).
-
Page 13: Connection Of The Door Contact Magnet
13/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Tighten the 3 small mounting screws with an hexagon socket screw key (2,5 mm). When tightening the mounting screws, observe the maximum permissible torque of 3 Nm! The sensor must not be attached on one side only. -
Page 14: Configuration/Installation Of The Door Contact
14/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released Configuration/installation of the door contact If the external door contact is activated, the control of the door information via the on- board computer or gateway is not interpreted. The sensor is controlled only by the signals from the external door contact. -
Page 15: Technical Data Of The Door Contact Magnet
15/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual released "Hall Sensor Polarity“: - Here the door contact logic can be selected as either "logically positive" or "logically negative". Logically positive means: 0 V = "Door closed"; 24 V = "Door open,"... - Page 16 16/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 17 17/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 18 18/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 19 19/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 20 20/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 21 21/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
- Page 22 22/22 IRMA MATRIX R2 Option Door Contact | Mounting Manual Fehler! Verweisquelle konnte nicht gefunden werden. Rev. 1. 2018-...
