ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KTS889W-CS01-3
2
KTS889W-CS01-2
3
KTS889W-CS03-1
4
KTS889W-CS02-1
5
KTS889W-CS04-H
6
17C33A0706001Y4
7
17C02A0755131Y4
8
17C01A0717072Y4
9
17C21A0713081Y4
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.

Step 1:

Place the right arm (#1) onto a non-abrasive surface, such as
a carpet, with its pre-drilled holes accessible. At the rear of the
chair, fasten the seat assembly (#4) to the right arm (#1) by
using bolts (#6) and washers (#10). Keep the bolts loose.
See Figure 1.
Note:
The labels marked "L" and "R" on arms (#1 and #2) should
coincide with Figure 1 - Figure 3 to ensure proper assembly.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the lounge chair is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KTS889W
PART
Q'TY
RIGHT ARM
LEFT ARM
BACK
ASSEMBLY
SEAT
ASSEMBLY
OTTOMAN
BOLT M6*16
BOLT M6*14
BOLT M6*50
BOLT M6*39
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 3
-WM
10
17FA05040301-Y4
1
11
18000C23001
1
12
18000613017
1
13
18000613018
14
1
18000337004
1
15
18000337006
6
16
18000337002
2
17
17KAA0101----Y4
18
17KAA0201----Y4
2
19
2
17KAB1101----Y4
FIGURE 1
4
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
PULLEY A
PULLEY B
BOLT CAP
BOLT CAP M6
BOLT CAP M6
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
14
14
6
6
10
10
R
1
#6 BOLT M6*16
COURTYARD CREATIONS INC.
12
2
2
2
6
2
4
1
1
1
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTS889W-WM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Courtyard Creations KTS889W-WM

  • Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 3...
  • Page 2 FIGURE 2 FIGURE 3 7 15 #6 BOLT M6*16 #6 BOLT M6*16 #7 BOLT M6*14 Step 2: Step 3: At the front of the chair, fasten the seat assembly (#4) to the At the rear of the chair, fasten the left arm (#2) to the seat right arm (#1) by using bolts (#6 and #7) and washers (#10).
  • Page 3 FIGURE 6 FIGURE 7 13 10 #9 BOLT M6*39 Step 6: Step 7: Flip the chair upside down. Fasten the ottoman (#5) to the Adjust the back assembly (#3) to your desired position. tracks on the seat assembly (#4). Put the washer (#10) and See Figure 7.
