  • Page 1 1/10 scale electric touring car...
  • Page 2 X20 m dius • DIFF ASSEMBLY…………………………………………………………4 X20 m dius • FRONT & REAR ASSEMBLY…………………………………………6 • CENTRAL ASSEMBLY…………………………………………………15 SHOCKS ASSEMBLY……………………………………………………21 • • BUMPER ASSEMBLY……………………………………………………23 • FINAL ASSEMBLY……………………………………………………25 X20 m dius • EXPLODED VIEWS……………………………………………………27 TEAM SERPENT NETWORK……………………………………………45 •...
  • Page 3 HOW TO USE THE MANUAL LINES DESCRIPTION ICONS DESCRIPTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...
  • Page 4 DIFF ASSEMBLY STEP 1 DIFF BAG 4x10x0.2 Fill the differential with silicone oil 1 mm above the crosspin, do NOT 2x10 please check the default setupsheet. 5x15x0.2 4x10x0.2 4x10x0.2 2x10 AMOUNT OF OIL IN 5x15x0.2 THE DIFFS Use a digital scale to measure the exact amount of oil in the diff.
  • Page 5 STEP 1 STEP 2 SOLID AXLE BAG M2.5x6 M2.5x8 M2.5x8 M2.5x6 2x10 2x10 2x10 M2.5x8 M2.5x6 2x10...
  • Page 6 FRONT & REAR ASSEMBLY STEP 3 BAG 1 Serpent logo on top FRONT REAR Serpent logo on top M4X8 M4X8 M4X8 M4X8 Rear arm Front arm 1.7mm 1.7mm M4x8 M4x8...
  • Page 7 STEP 4 FRONT REAR 3x5x1 3x5x1 3x5x1 3x5x1 M3x8 M3x8 M3x8 M3x8 3x5x1 M3x8 3x5x1 M3x8...
  • Page 8 STEP 5 ARS MOUNT POSITION M3x6 M3x6 M3x6 M3x6...
  • Page 9 STEP 6 10x15x4 10x12x0.1 10x15x4 10x12x0.1 10x15x4...
  • Page 10 STEP 7 BAG 2 M3x12 M4x4 SHORT UPPER ARM IS USE FOR REAR FRONT M3x12 M4x4...
  • Page 11 STEP 8 M3x2.5 2x10 M2x5 5x10x4 5x10x4 2x10 4.0mm 2.7mm M2x5 2x10 M3x2.5 2x10 5x10x4...
  • Page 12 STEP 9 BAG 3 16.4mm 3x5x1 3x5x1 3x6x2.5 M3x10 Nylock Nut M3x6 3x5x1 3x6x2.5 M3x6 M3x10 Nylock Nut M3...
  • Page 13 STEP 10 BAG 4 M3x12 10x15x4 10.1 10.2 M4x4 10x15x4 10.3 SHORT UPPER ARM IS USE FOR REAR FRONT M3x12 M4x4 10x15x4...
  • Page 14 STEP 11 11.2 11.1 Nylock Nut 5x10x4 5x10x4 11.3 M2X5 3.3mm 2.0mm Nylock Nut M3 M2X5 5x10x4...
  • Page 15 CENTRAL ASSEMBLY STEP 12 P 13 BAG 5 12.1 12.3 C-CLIP R9 3x6x6 8x12x3.5 M3x10 3x5x0.3 M3x4 3x6x2.5 12.2 M3x6 5x8x2.5 M3x6 M3x10 M3x4 M3x6 M3x6 3x6x2.5 3x6x6 5x8x2.5 8x12x3.5 C-CLIP R9...
  • Page 16 STEP 14 BAG 6 14.1 FRONT REAR 14.3 14.2 M3x2.5 14.4 14.6 M3x2.5 14.5 3x6x2.5 Flanged M3x2.5 M3x2.5 3x6x2.5 Flanged M3x2.5 M3x2.5 3x6x2.5 Flanged...
  • Page 17 STEP 15 BAG 7 15.1 21.8mm M3x6 15.3 M3x6 3x5x4 15.2 3x5x1 3x5x1 M3x6 3x5x4 3x5x1 M3x6 M3x6 M3x6...
  • Page 18 STEP 16 16.1 16.2 3x6x6 3x5x2 3x5x1 M3x10 M3x6 M3x6 M3x6 12.5mm M3x10 3x5x1 3x5x2 M3x6 M3x6 3x6x6...
  • Page 19 STEP 17 BAG 8 17.1 17.2 M3x10 M3x10 3x5x4 3x5x4 M3x12 M3x12 3x5x4 M3x10 M3x12 3x5x4 M3x10 M3x12...
  • Page 20 STEP 18 18.1 18.2 M3x6 M3x6 M3x8 M3x8 18.3 M3x8 M3x8 M3x6 M3x8 M3x8...
  • Page 21 SHOCKS ASSEMBLY STEP 19 SHOCK BAG 19.1 19.2 19.3 19.4 19.5 E-CLIP 2.3 11.2mm E-CLIP 2.3...
  • Page 22 STEP 20 20.2 20.1 M3x8 3x6x2 3x6x2 M3x8 3x6x2 M3x12 M3x12 M3x2.5 M3x2.5 3x6x2 M3x8 3x6x2 M3x8...
  • Page 23 BUMPER ASSEMBLY STEP 21 BAG 9 21.1 21.2 Nylock Nut 2x10 M3x10 M3x10 M3x6 M3x6 M3x8 2x10 M3x10 M3x6 M3x8 Nylock Nut M3...
  • Page 24 STEP 21 21.3 21.4 M3x6 M3x10 M3x10 M3x6...
  • Page 25 FINAL ASSEMBLY STEP 21 P 22 21.5 22.1 2x10 M3x6 2x10 M3x6 Body Clip...
  • Page 26 STEP 22 22.2 Nut M4 flanged Nut M4 flanged...
  • Page 27 EXPLODED VIEWS 401592 Geardiff V3 composite 401598 401593 401594 110136 110208 110443 804176 401784 opt 110136 110445 401594 110445 401593 401594 401595 401598 804176 804200 401784 opt 401594 110443 110208 110445 401594 401594 110445 401784 Seal 5x9x2 diff (2)
  • Page 28 401723 Solid axle set 110130 110130 110208 401359 401724 401600 opt 401725 opt 401744 401725 opt 401744 401359 110208 401600 Solid axle alu S411 mono for blades 401725 Drive adaptor solid axle (2)
  • Page 29 1397 401851 110311 401833 120040 401826 401851 110408 1311 401124 110108 110230 110231 120008 Spur gear 64P / 104T 120040 Spur gear 64P / 110T 120009 Spur gear 64P / 108T 120039 Spur gear 64P / 102T 120010 Spur gear 64P / 112T 120013 Spur gear 64P / 106T 120012...
  • Page 30 401843 Shockset (2) X20 110300 401840 opt 401841 110300 401836 401853 401852 opt 401854 opt 401855 opt 1649 160154 160129 401837 160129 1649 160139 401842 opt 401834 160146 401835 401838 401839 401839 401840 Shock piston 3-holes (4) X20 401852 Spring fr/rr 2,5 (2) 401854 Spring fr/rr 2,7 (2) 401855...
  • Page 31 110409 401814 110189 401830 401814 401830 401814 110189 401829 110409 401819 401829 401860 opt 401861 opt 401862 opt 110409 110104 110122 110104 401860 Chassis alu soft X20 401865 Stiffner fr/rr mount X20 401872 Chassis brace set fr X20 401861 Chassis alu medium X20 401866 Chassis stiffner center mid carbon X20 401873...
  • Page 32 401825 110503 401592 401811 110458 110503 401825 110503 401825 401811 401825 110503 401812 401812 401723 401600 opt 401812 401812 110122 110122 401600 Solid axle alu S411 mono for blades...
  • Page 33 110110 401815 110112 401817 401809 401816 110409 808214 401818 110118 110409 401655 401124 110112 401824 110231 808214 110118 401809 110112 401809 401823 401822 401655 401815 401655 401817 401816 401655 401822 110122...
  • Page 34 110162 401409 110208 401381 401127 401394 opt 401661 401394 CVD driveshaft (2)
  • Page 35 401698 Double joint cardan set (2) 4X 110221 401615 401614 110222 401614 401612 401733 401613...
  • Page 36 401699 401808 110500 401790 110165 110208 411063 110402 411048 110208 110500 110402 110500 110165 500212 411063 500211 opt 401307 opt 401698 411063 411048 411048 110500 500212 500211 opt 401810 411048 401808 411063 500211 Wheelhexagon +0.75mm offset (2) 401387 Wheelhexagon 1mm offset (2)
  • Page 37 110231 401833 110108 401828 401849 110108 401808 401484 401850 401807 110409 401429 110108 401807 411187 110410 401429 110409 110108 401807 401808 401372 401807 110402 600290 opt 600291 opt 401429 600292 opt 401807 401807 401430 401807 401848 401429 110122 401807 110122 600290 Servo lever steering 23T alu 600291...
  • Page 38 401856 opt 401807 401857 opt 401858 110162 401859 opt 401807 401807 401807 110162 411187 401856 opt 110162 401807 110162 401857 opt 110162 401813 401858 401807 1399 1399 401859 opt 401807 411187 401813 110162 411187 110162 401807 401813 1399 411187 401813 401856 Antirollbar 1,2mm X20 401857...
  • Page 39 401843 Shockset (2) X20 802211 802211 110464 110208 110464 802211 401843 401821 110117 802211 110109 110208 110464 110464 110124 110117 401843 110104 110109 110124 110124 110104 401864 Shocktower stiffner carbon fr/rr X20 401865 Stiffner fr/rr mount X20 401871 Shocktower stiffner set fr/rr X20...
  • Page 40 401843 Shockset (2) X20 401843 110464 401820 110124 110117 110108 110464 110124 401843 110108 110124 110124 110117 401864 Shocktower stiffner carbon fr/rr X20 401865 Stiffner fr/rr mount X20 401871 Shocktower stiffner set fr/rr X20...
  • Page 41 110108 110108 401827 110100 401832 401832 110100 401832 401832 401832 401484 110127 401832 401484 110127...
  • Page 42 802211 401602 opt 804293 opt 110208 1667 802211 802211 110208 1667 110402 401846 401844 401847 401643 110108 110104 110109 401602 Body-height fine-tuner alu (4) 804293 Bodymount adjustable front (3)
  • Page 43 110452 110452 110452 110108 110452...
  • Page 44 TEAM SERPENT NETWORK SPARE PARTS www.serpent.com/400033/spares/ OPTIONALS PARTS www.serpent.com/400033/Optionals/ SERPENT TOOLS www.serpent.com/product/Tools/ SERPENT MERCHANDISING www.serpent.com/product/Merchandising/...
  • Page 45 SERPENT WEBSITE AND BLOG www.serpent.com www.teamserpent.com www.dragon-rc.com SERPENT PROMO PAGES http://promo.serpent.com SERPENT FACEBOOK GROUPS http://promo.serpent.com/indexfb.htm SERPENT ADVANCED MANUALS http://promo.serpent.com/sam/ SERPENT SOCIAL MEDIA www.facebook.com/SerpentMRC www.youtube.com/user/SerpentMRC www.twitter.com/SerpentMRC www.plus.google.com/+SerpentModelcars/posts www.weibo.com/teamserpent...
  • Page 46 INSTRUCTION MANUAL Manual Cobra X20 #400033...
