  • Page 2 The Serpent Medius X20 Mini is a state of the art 1/10 scale 4WD touringcar which will give you the true • DIFF ASSEMBLY…………………………………………….………4 • CVD ASSEMBLY……….....…………………………………6 your Serpent Medius X20 Mini Fine-tuning the initial setup is an essential part of building a high-performance FRONT &...

  • Page 3: How To Use The Manual

    HOW TO USE THE MANUAL LINES DESCRIPTION ICONS DESCRIPTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...

  • Page 4: Diff Assembly

    DIFF ASSEMBLY STEP 1 DIFF BAG Fill the differential with silicone oil 1 mm above the crosspin, do NOT 2x10 4x10x0.3 overfill. Use the silicone oil supplied in the kit. For the correct cst value please check the default setupsheet. 5x15x0.2 4x10x0.3 4x10x0.3...
  • Page 5 STEP 1 STEP 1 SOLID AXLE BAG M2.5x8 10x15x4 M2.5x8 M3x16 M2.5x8 M3x16 10x15x4...
  • Page 6 CVD ASSEMBLY STEP 2 BAJ 1 CVD BAG REAR 2x10 M3x2.5 FRONT M3x2.5 2x10...

  • Page 8: Front & Rear Assembly

    FRONT & REAR ASSEMBLY STEP 3 BAG 1 FRONT REAR M4x6 M4x6 M4x6 Wheelbase 210 M4x6 FRONT REAR Wheelbase 225 M4x6...
  • Page 9 STEP 4 REAR FRONT M3x6 M3x6 M3x6 M3x6 M3x6 M3x6...
  • Page 10 STEP 5 REAR FRONT M3x6 M3x6 M3x6 M3x6...

  • Page 11: Motormount Assembly

    MOTORMOUNT ASSEMBLY STEP 6 BAG 2 M3x6 10x15x4 5x8x2.5 FRONT REAR 12x15x0.25 10x15x4 M3x6 5x8x2.5 12x15x0.25 10x15x4...
  • Page 12 STEP 6 3x6x2.5 M3x10 Flanged 2x5x2.5 M3x6 2x5x2.5 M3x6 M2x10 M3x10 3x6x2.5 Flanged...
  • Page 13 STEP 6 4WD 5:5 4WD 6:4 4WD 7:3 4WD 7:3 M3x6 M3x6...
  • Page 14 STEP 6 M3x6 FWD &RR M3x6 M3x6 M3x6 M3x6...

  • Page 15: Rear Assembly

    REAR ASSEMBLY STEP 7 BAG 3 M3x8 REAR WB210 M3x2.5 Rear Rear WB225 Rear Rear M3x2.5 PIVOTBALL M3x4 M3x8...
  • Page 16 STEP 7 3.2mm REAR 5x10x4 5x10x4...
  • Page 17 STEP 7 6.5mm REAR 2x10 M2x5 Nylock nut M3 M3x6 M3x6 2x10 M2x5 PIVOTBALL M3x4 PIVOTBALL M3x7 M3x6 Nylock Nut M3 M3x6...

  • Page 18: Front Assembly

    FRONT ASSEMBLY STEP 8 BAG 4 M3x8 FRONT WB210 M3X2.5 Front Front WB225 Front Front M3x2.5 PIVOTBALL M3x4 M3x8...
  • Page 19 STEP 8 3.2mm FRONT 5x10x4 5x10x4...
  • Page 20 STEP 8 FRONT Nylock nut M3 2x10 4WD&RR M2x5 2x10 M3x6 2x10 PIVOTBALL M3x7 M2x5 Nylock Nut M3 M3x6...
  • Page 21 STEP 9 BAG 5 FRONT & REAR REAR REAR 2.5mm FRONT 2.5mm FRONT PIVOTBALL M3x7...
  • Page 22 ANTIROLLBAR ASSEMBLY STEP 9 M3x2.5 REAR FRONT & REAR M3x2.5 3x6x2.5 Flanged FRONT M3x2.5 M3x2.5 3x6x2.5 Flanged M3x2.5 M3x2.5 3x6x2.5 Flanged...

  • Page 23: Steering Assembly

    STEERING ASSEMBLY STEP 10 10.1 10.2 10.2 M3x4 M3x4 M3x4 4x8x3 3x6x2 3x6x2 4x8x3 M3x8 M3x8 PIVOTBALL M3x7 PIVOTBALL M3x7 M3x4 M3x8 3x6x2 M3x4 3x6x2 4x8x3...
  • Page 24 STEERING ASSEMBLY STEP 10 10.4 4WD&RR M3x6 M3x6...
  • Page 25 STEP 11 BAG 6 11.1 600290 Servo lever steering 23T alu M3x6 600291 Servo lever steering 24T alu 600292 Servo lever steering 25T alu M3x8 M3x6 M3x8 M3x6 M3x6 M3x8...
  • Page 26 STEP 11 11.2 M3x6 M3x6...

  • Page 27: Central Assembly

    CENTRAL ASSEMBLY STEP 11 11.3 FWD&4WD 5:5 RR&4WD 6:4-7:3 M3x6 M3x6 M3x6...
  • Page 28 STEP 11.4 M3x6 M3x8 M3x8 M3x6 M3x8...

  • Page 29: Shocks Assembly

    SHOCKS ASSEMBLY STEP12 SHOCK BAG 12.1 12.2 12.3 12.4 12.5 E-CLIP 2.3 E-CLIP 2.3 10.5mm E-CLIP 2.3...
  • Page 30 STEP 13 BAG 7 3x6x2 13.1 FRONT M3x8 M3x6 3x6x2 M3x6 M3x8 M3x8 13.2 3x6x2 REAR 401964 Chassis brace set fr X20 '21 401965 Chassis brace set rr X20 '21 401966 Front stiffner set X20 '21 401967 Rear stiffner set X20 '21 M3x8 401960 Lower chassis weight 5gr (2) X20 '21 401963 Chassis brace fr/rr alu X20...

  • Page 31: Bumper Assembly

    BUMPER ASSEMBLY STEP 14 14.1 14.2 M3x10 M3x10 M3x8 M3x8 M3x10...
  • Page 32 STEP 14 M3x8 14.3 401602 Body-height fine-tuner alu (4) 401954 Bumper top carbon X20 '21 M3x8 M3x8 M3x8...

  • Page 33: Final Assembly

    FINAL ASSEMBLY STEP 15 15.1 M3x6 M3x6...
  • Page 34 STEP 15 15.2...
  • Page 35 STEP 15 15.3 Nut M4 flanged Nut M4 flanged Nut M4 Flanged...
  • Page 36 X20mini WB210...
  • Page 37 X20mini WB210...
  • Page 38 X20mini 4WD 5:5...
  • Page 39 X20mini 4WD 6:4...
  • Page 40 X20mini 4WD 7:3...
  • Page 41 X20mini WB225...
  • Page 42 X20mini WB225...
  • Page 43 X20mini 4WD...
  • Page 44 X20mini 4WD...
  • Page 45 X20mini FWD...
  • Page 46 X20mini FWD...
  • Page 47 X20mini FWD...
  • Page 48 X20mini FWD...
  • Page 49 X20mini FWD...
  • Page 50 X20mini RR...
  • Page 51 X20mini RR...
  • Page 52 X20mini RR...
  • Page 53 X20mini RR...

  • Page 54: Exploded Views

    EXPLODED VIEWS 401814 401931 401931 401814 110119 401814 401812 401931 110119 401812 401973 401973 401973 401973 110122 401977 110122 401958 Chassis weight 10gr X20 '21 401966 Front stiffner set X20 '21 401961 Chassis weight RX 5gr X20 '21 401967 Rear stiffner set X20 '21 401964 Chassis brace set fr X20 '21 401965 Chassis brace set rr X20 '21...
  • Page 55 401825 401917 opt 110503 401592 401985 110132 110433 110503 110122 401825 401981 401917 opt 110510 401944 110503 110188 401825 401984 401917 opt 401983 401994 1399 401946 opt 110231 110503 401994 1311 401946 opt 401980 401944 401980 401825 401917 opt 120038 110132 600263 110122...
  • Page 56 808214 401655 110124 808214 401809 401822 401815 401430 401655 401818 401721 110162 401974 110500 411063 110500 401933 110165 500212 401975 401387 opt 401809 500211 opt 110452 110208 401933 401808 411063 401924 110108 110402 401991 110122 401409 401387 Wheelhexagon 1mm offset (2) 401816 Suspension bracket spacer 1mm (4) X20 500211 Wheelhexagon +0.75mm offset (2)
  • Page 57 401655 808214 401822 110162 808214 401655 110124 401815 401809 110402 401924 411063 110500 110208 401933 110165 500212 401975 401387 opt 500211 opt 110452 110500 401933 411063 401974 110108 401808 401991 401387 Wheelhexagon 1mm offset (2) 401816 Suspension bracket spacer 1mm (4) X20 500211 Wheelhexagon +0.75mm offset (2)
  • Page 58 401976 110108 411253 110108 401979 401721 401372 401430 110164 110108 401990 401808 401430 110122 110464 401928 401133 110108 401969 401808 401978 401372 401971 1399 110162 110108 401990 401813 401988 401721 110124 401987 opt 110162 401430 110122 401133 401989 opt 401721 401990 401972 110162...
  • Page 59 401915 401904 110124 1650 110464 110464 110124 1650 401843 802361 401843 110124 1650 401919 110109 110464 401920 110114 401919 1650 110464 110124 401982 110124 110104 401954 Bumper top carbon X20 '21 401602 Body-height fine-tuner alu (4) 804293 Body support washers med + high (5+5)
  • Page 60 401991 CVD driveshaft set (2) X20M 110208 401661 401992 401381 110162...
  • Page 61 401837 160146 160129 401834 401842 401835 401838 401839 1650 401839 401841 401840 opt 160154 110300 401836 160129 401853 401852 opt 1650 401854 opt 401855 opt 401843 Shockset (2) X20 401840 Shock piston 3-holes (4) X20 401852 Spring fr/rr 2,5 (2) 401854 Spring fr/rr 2,7 (2) 401855 Spring fr/rr 2,8 (2)
  • Page 62 401592 Geardiff V3 composite 401598 804176 401593 401784 opt 110422 110443 110208 401594 401594 401595 804200 401594 110136 110422 110443 110208 401593 401594 401598 804176 401784 opt 401784 Seal 5x9x2 diff (2)

  • Page 63: Team Serpent Network

    TEAM SERPENT NETWORK X20 mini SPARE PARTS www.serpent.com/400020/spares/ X20 mini OPTIONALS PARTS www.serpent.com/400020/Optionals/ SERPENT TOOLS www.serpent.com/product/Tools/ SERPENT MERCHANDISING www.serpent.com/product/Merchandising/...
  • Page 64 SERPENT WEBSITE AND BLOG www.serpent.com www.teamserpent.com www.dragon-rc.com SERPENT PROMO PAGES http://promo.serpent.com SERPENT FACEBOOK GROUPS http://promo.serpent.com/indexfb.htm SERPENT ADVANCED MANUALS http://promo.serpent.com/sam/ SERPENT SOCIAL MEDIA www.facebook.com/SerpentMRC www.youtube.com/user/SerpentMRC www.twitter.com/SerpentMRC www.plus.google.com/+SerpentModelcars/posts www.weibo.com/teamserpent...
  • Page 65 INSTRUCTION MANUAL Manual X20M #98597-1...
