- Page 1 Gold Drum HV Power Cable Kit June 2012 (Ver. 1.0) www.elmomc.com...
- Page 2 • This guide contains proprietary information belonging to Elmo Motion Control Ltd. Such information is supplied solely for the purpose of assisting users of the Gold Drum HV Power Cable Kit in assembling the required cables for these drives. •...
- Page 3 Germany Tel: +49 (0) 7721-944 7120 • Fax: +49 (0) 7721-944 7130 • info-de@elmomc.com China Elmo Motion Control Technology (Shanghai) Co. Ltd. Room 1414, Huawen Plaza, No. 999 Zhongshan West Road, Shanghai (200051) China Tel: +86-21-32516651 • Fax: +86-21-32516652 •...
- Page 4 Gold Drum HV Power Cable Kit Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) Table of Contents Chapter 1: Introduction ....................5 Chapter 2: Motor Power Cables (CBL-MTRDRUM x 3 & CBL-PEDRUMOUT) ....6 Chapter 3: Main Power Cable (CBL-TAMSET) .............. 10 www.elmomc.com...
-
Page 5: Chapter 1: I Ntroduction
MAN-DRUHVPCBLKIT (Ver. 1.0) Chapter 1: I ntroduction This document provides the wiring details for the cables used to connect Elmo's Gold Drum HV Power Cable Kit servo drive with the end-user application. The servo drive-side pinouts are provided in Chapter 3 of the Gold Drum HV Installation Guide. -
Page 6: Chapter 2: M Otor Pow Er Cables
Chapter 2: M otor Pow er Cables (CBL-M TR DR UM x 3 & CBL-P EDR UM OUT) The Gold Drum HV Power Cable Kit receives power from main and auxiliary supplies and delivers power to the motor. The general pinout connections for the Motor Power cable is as follows:... - Page 7 Gold Drum HV Power Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) The cables are connected as follows (refer to Figure 2 and Figure 3 for the cable details): Terminal Lugs Ends to to G-DRUM HV Motor Figure 1: Motor Power Cable Ends...
- Page 8 Gold Drum HV Power Cable Kit Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) Figure 2: Motor Power Cable Drawing www.elmomc.com...
- Page 9 Gold Drum HV Power Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) Figure 3: Motor Power PE Cable Drawing www.elmomc.com...
-
Page 10: Chapter 3: M Ain P Ow Er Cable (Cbl-Tam Set)
Gold Drum HV Power Cable Kit Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) Chapter 3: M ain P ow er Cable (CBL-TAM SET) The general pinout of the main power cable cable is as follows: Function Cable Protective Earth CABLE MOTOR PE OUT YELLOW/GREEN 8G... - Page 11 Gold Drum HV Power Cable Kit Cable Kit Main Power Cable (CBL-TAMSET) MAN-DRUHVPCBLKIT (Ver. 1.0) The cables are connected as follows: Terminal Lugs Ends to to VP+, VN-, PE, TAM 100 or other Power at G-DRUM HV Supply Figure 4: Main Power Cable Ends...
- Page 12 Gold Drum HV Power Cable Kit Cable Kit MAN-DRUHVPCBLKIT (Ver. 1.0) Figure 6: Main Power Cable Drawing www.elmomc.com...
