- Page 1 BCR05 Sample Gas Cooler Installation Manual Maintenance Manual Operating Manual Spare Part List...
- Page 2 BVG D4, refrigerant plants, heat pumps and cooling units A technical documentation is completely present with the manual. Erkelenz, 08.05.2017 Jochen Podiwin Jörg Schamar Managing Director ATEX-Responsible AGT-PSG GmbH & Co.KG Page 2 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
-
Page 3: Dear Customer
The staff has experience in handling sample gas as well as in handling electrical and refrigerated devices. AGT-PSG GmbH & Co.KG Page 3 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... -
Page 4: Warranty Conditions
Return deliveries must take place in suitable and sound protective packing. Please contact directly the manufacturer AGT-PSG if the sample gas cooler fails. Basis for all warranty claims is the purchase receipt and the undamaged model identification plate. In case of queries we need the model type, serial number and year of construction (model identification plate). -
Page 5: Important Advices
CAUTION! No water! In case of fire, use an approved fire extinguisher. Never use water to extinguish fire (or near the sample gas cooler or directly to the sample gas cooler directed water). AGT-PSG GmbH & Co.KG Page 5 Errors and printing mistakes excepted... -
Page 6: Transport, Delivery And Storage
Handle with care. Heavy blows could cause irreparable damage. Only upright vertical position! Lying horizontal position vorbidden! AGT-PSG GmbH & Co.KG Page 6 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... -
Page 7: Assembly And Installation
WARNING! Possible damage! Handle with care. Heavy blows could cause irreparable damage. WARNING! Possible damage! Protect the display during installation of the cooler or during mounting work. The display is very fragile. AGT-PSG GmbH & Co.KG Page 7 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... - Page 8 Therefore use the two bores in the front area of the bottom plate. Finally remount all dismounted housing parts. Mounting rail left Fastening points left Console left 480mm Mounting rail right Fastening points right Console right 370mm AGT-PSG GmbH & Co.KG Page 8 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 9 Coolers without condensate pumps are equipped with heat- exchangers with condensate outlet at bottom (pipe, 12mm outer diameter, without thread). The picture above shows two SS316 mono-HEs with condensate connection at the bottom. AGT-PSG GmbH & Co.KG Page 9 Errors and printing mistakes excepted...
- Page 10 We also recommend to use a pre-separator in case of measuring points at high inlet temperatures and high inlet dew points greater than 65°C. The capacity of heat exchangers is thus affected favorably. AGT-PSG GmbH & Co.KG Page 10 Errors and printing mistakes excepted...
-
Page 11: Electrical Connections
The local protection of the sample gas cooler is provided by the customer. The technical data is mentioned on the model type plate and in the technical data sheet. AGT-PSG GmbH & Co.KG Page 11 Errors and printing mistakes excepted... - Page 12 Proceed with the installation according to the instructions for installing the electrical supply line. WARNING! Overcharge! Maximum rated load for the remote monitoring connection is 250V, 50Hz, 40VA. AGT-PSG GmbH & Co.KG Page 12 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 13 The electrical lines need to be applied exclusively to the rail-mounted terminals in the shielded enclosure “Advanced Security” (X1:04-05-06, notice circuit diagram). Rail-mounted terminals X1:01-02-03 3-pole remote monitoring connection X1:04-05-06 Electrical supply line (L1-N-PE) AGT-PSG GmbH & Co.KG Page 13 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 14 (voltage, frequency, gas flow rate, gas inlet temperature, ambient temperature, etc.). WARNING! Open housing! Never operate equipment with panels removed. AGT-PSG GmbH & Co.KG Page 14 Errors and printing mistakes excepted...
-
Page 15: Sequence Of Operations
During the operation, the refrigerating compressor will run continuously. The cooler must work during the full period of sample gas feed. AGT-PSG GmbH & Co.KG Page 15 Errors and printing mistakes excepted... - Page 16 (for example safety gloves, face mask, safety goggles etc.). CAUTION! Toxic and explosive gases! Corresponding guidelines must be adhered to while operating with toxic and explosive gases. AGT-PSG GmbH & Co.KG Page 16 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
-
Page 17: Temperature Monitoring
Defective refrigerant circuit Contact AGT Service Temperature < 0°C Too low ambient temperature Adhere to operation data Defective performance regulation Contact AGT Service AGT-PSG GmbH & Co.KG Page 17 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... - Page 18 If you cannot eliminate the cause for the activation of the protection switch, decommission the device at once (notice chapter “Decommissioning”)! Contact the manufacturer AGT-PSG! If you are not sure how to reset a protection switch, contact the manufacturer AGT- PSG. AGT-PSG GmbH & Co.KG...
- Page 19 Dismantle the right panel and the top panel of the sample gas cooler. Open the encapsulated control unit (20.0). Reset the device protection switch (F1). Remount accurately all dismantled components. Encapsulated control unit (20.0) Protection switch refrigerant compressor (F1) AGT-PSG GmbH & Co.KG Page 19 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 20 Dismantle the right panel of the sample gas cooler. Reset the low-pressure and high-pressure limiter (20.1). Remount accurately all dismantled components. Combi-Instrument Pressure Limiter (20.1) Safety switch low-pressure Safety switch high-pressure AGT-PSG GmbH & Co.KG Page 20 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 21 Dismantle the right panel of the sample gas cooler. Reset the safety temperature limiters (20.2/20.3). Remount accurately all dismantled components Safety switch refrigerant compressor (20.2) Safety switch refrigerant pressure line (20.3) AGT-PSG GmbH & Co.KG Page 21 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
-
Page 22: Check And Maintenance
CAUTION! Toxic and explosive gases! Corresponding guidelines must be adhered to while operating with toxic and explosive gases. WARNING! Open housing! Never operate equipment with panels removed. AGT-PSG GmbH & Co.KG Page 22 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... - Page 23 The encapsulated control unit is defective if the flameproof encapsulation is damaged, or if one of the components does not function any longer. In this case decommission the device at once (notice chapter “Decommissioning”)! AGT-PSG GmbH & Co.KG Page 23 Errors and printing mistakes excepted...
-
Page 24: Spare Parts
Only qualified personnel should perform troubleshooting, maintenance or repair operations. Please contact directly the manufacturer AGT-PSG if the sample gas cooler fails. Tampering the safety and security devices is not permissible. -
Page 25: Packaging And Shipping
BCR05 Return / Maintenance and Repair Packaging and Shipping If you want to send a device for maintenance or repair to AGT-PSG, please note the following information on packaging and shipping: Please use the original packaging of the device. If this is not available, use another stable packaging in which the cooler is well protected from the weather and mechanical damage. - Page 26 Liquid Solid Powdery Gaseous Please include the current material safety data sheet of the hazardous material! Company, Contact Location, Date, Stamp, Signature AGT-PSG GmbH & Co.KG Page 26 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
-
Page 27: Dimension Sheet
Installation-, Operating-, Maintenance-Manual, Spare Part List BCR05 Dimension Sheet AGT-PSG GmbH & Co.KG Page 27 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... - Page 28 Installation-, Operating-, Maintenance-Manual, Spare Part List BCR05 RI Flow Schema AGT-PSG GmbH & Co.KG Page 28 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 29 Installation-, Operating-, Maintenance-Manual, Spare Part List BCR05 Electrical Components Overview AGT-PSG GmbH & Co.KG Page 29 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 30 Installation-, Operating-, Maintenance-Manual, Spare Part List BCR05 Electrical Components Details AGT-PSG GmbH & Co.KG Page 30 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
-
Page 31: Circuit Diagram
Installation-, Operating-, Maintenance-Manual, Spare Part List BCR05 Circuit Diagram AGT-PSG GmbH & Co.KG Page 31 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017... - Page 32 This prevents any alternation of dew points. The temperature control unit 21.0 monitors the dew point temperature. It provides an alarm at unacceptable exceeding or undercut of temperature. AGT-PSG GmbH & Co.KG Page 32 Errors and printing mistakes excepted Translation - Manual BCR05 Rev. 06/2017...
- Page 33 If the temperature rises over the permitted maximum temperature, it switches off the refrigerant compressor – defined acting point 85°C. After problem solving it needs a manual reset. AGT-PSG GmbH & Co.KG Page 33 Errors and printing mistakes excepted...
- Page 34 The startup capacitor is equipped with a discharge resistor that discharges the capacitor by the switch-off of the time relay. AGT-PSG GmbH & Co.KG Page 34 Errors and printing mistakes excepted...
-
Page 35: Technical Data
Power consumption 220W at 230VAC – starting current 6,3A Weight 38,5kg 40,5kg at standard conditions, dew point 65°C inlet temperature, 10-25°C ambient temperature AGT-PSG GmbH & Co.KG Richard-Lucas-Str. 6, D-41812 Erkelenz, Deutschland Tel: +49 (0)2431/9627-0, Fax: +49 (0)2431/9627-31 www.agt-psg.de, info.agt@agt-psg.de...
