- Page 1 PlantVisorPRO Embedded Foglio istruzioni Technical leaflet...
- Page 2 Technical leaflet...
- Page 3 CAREL or its branch offices/affiliates have been warned of the possibility of damage.
-
Page 4: Table Of Contents
CONTENTS Introduction ....................................11 Installation ....................................12 Technical specifications ................................16 Dimensions....................................16 Accessories ....................................16 Note ......................................16... -
Page 6: Introduction
This solution is made up three fundamental parts: a device featuring exceptional stability and reliability, a robust operating system that offers excellent performance, and a monitoring and telemaintenance product that has been tested and appreciated in hundreds of installations (PlantVisorPRO). The purpose of this document is to provide instructions on setting up the system. -
Page 7: Installation
(7). Then plug the power cable into connector (1) and the 220 Vac power supply. Finally, connect the CAREL 485 network. The connector used depends on the type of converter selected. - Page 8 PlantVisorPRO Embedded Wait until the “Install language” button is enabled, then select the language for installing PlantVisorPRO, and click “Install language”. Fig. 2.3 Once installation is complete, the following screen is displayed: click “ignore” to not install extra modems for the time being click “modem settings”...
- Page 9 “printer settings” to install a printer now Fig. 2.5 Configuration At the end of start-up phase (see the previous paragraph), the PlantVisorPRO management console is opened. This indicates that the system is fully operating. Fig. 2.6 The ”System Manager” button allows to access the operative system. The access to these functions is password protected.
- Page 10 PlantVisorPRO Embedded Once the password has been entered, the following window will be displayed. Fig. 2.8 To access the desired function, simply select it and click Run. To exit, simply click Close. The following functions are available: Task Manager. Manages the processes that are currently running Explorer.
-
Page 11: Technical Specifications
4. Dimensions The dimensions of PlantVisorPRO Embedded are 260 x 240 x 62 mm (10.24 " x 9.45" x 2.44”). For the correct ventilation of the device, there must be at least 15 cm of free space on each side. - Page 13 Agenzia / Agency: CAREL S.p.A. Via dell’Industria, 11 - 35020 Brugine - Padova (Italy) Tel. (+39) 049.9716611 Fax (+39) 049.9716600 http://www.CAREL.com - e-mail: CAREL@CAREL.com...
