I N S T A L L A T I O N A N D P O W E R
Installation and Power
Chapter Contents
Unpacking and Installing the Console ........................................ 1-2
Power Supply ................................................................................. 1-3
Energizing ...................................................................................... 1-3
Audio and Control Wiring ............................................................. 1-4
Unbalanced Connections (analog audio) ...................................................................1-5
Hook-Ups ........................................................................................ 1-6
MIC 1 and MIC 2 Inputs - XLR ...................................................................................1-6
LINE 3 IN through LINE 6 IN and LINE 8 IN ...............................................................1-6
CALLER IN - RJ-45 ....................................................................................................1-7
MXM-TB OUT - RJ-45 ................................................................................................1-7
TALLY OUT - RJ-45 ....................................................................................................1-7
PGM OUT - XLR .........................................................................................................1-7
page 1 – 1
AUDIOARTS 08 / Dec 2015
