2. After configuration of PPPOE WAN,click the "Create"button to finish the setting.
Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
【Service List】 Check "INTERNET"or"VOICE_INTERNET";The broadband Internet
of routing mode is usually check the "INTERNET",the latter
supports voice functions.
【VLAN Type】Configure this option according to our network plan.If the network
plans the vlan of broadband Internet, this item needs to choose
"tag";If the network has no vlan planning for broadband Internet
access, this option is "untag".
【Vlan ID】This will appear after the selection "tag", and the vlan id of the network
plan should be filled in.
【MTU】The default is 1492; if we can ping the DNS but not access to the website
via WEB browser，we need to lower the value of MTU, such as 1400.
【Username】Type PPPoE account, normally offered by ISP, for Internet;
【Password】Type PPPoE password, normally offered by ISP, for Internet;
【Authentication Type】The default is "Auto".
【Dial Mode】The default is "Always On".
【Idle Timeout】The default is "1200"seconds.
Note: the default port is unbound, and all the LAN ports go through this WAN.
When the device has a bridge WAN and a route WAN at the same time,it needs to
bind the port for each WAN (a LAN can only be bound to a WAN, can not bind to
multiple WAN connections at the same time.
