2 Unpacking and Installation
2.2.2
Top and bottom of MADSEN Alpha OAE+
A. Probe socket
2.2.3
The docking station
Front indicators
10
Top
POWER
Lit when power is supplied to the docking station.
Lit when data is being transferred as follows:
•
during transfer of a report to the PC
•
during printing from label printer
USB
Lit when docking station is connected to the PC via a USB cable.
Bottom
B. Docking Station connectors
Otometrics - MADSEN Alpha OAE+
