- Page 1 By Ron Bull (rbull@co.walla-walla.wa.us) at 2:52 pm, Sep 16, 2019 INSTALLATION MANUAL OF STANDARD SOLAR MODULES (UL) For professional use only...
- Page 2 CS6U-xxxM. mort, que le panneau soit connecté ou non. Please retain this manual for future reference. We recommend checking www.canadiansolar.com GENERAL SAFETY UNPACKING AND STORAGE PRECAUTIONS regularly for the most updated version. · All Modules must be installed by licensed electrici-...
-
Page 3: Module Installation
Installation Manual 12 modules, and the frames should be aligned. material to stop the production of electricity when installing or working on a module or wiring. www.canadiansolar.com. Main electrical charac- · Do not place excessive loads on the module or... -
Page 4: Module Wiring
· Use 6-12 AWG (4-14 mm2) copper wire only. All · A maximum of two strings can be connected in · Installers may only use single conductor cable EN-Rev IM/UL-AM-EN/3.5 Copyright © June 2016. Canadian Solar Inc. www.canadiansolar.com By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019... -
Page 5: Mounting Method: Bolting
Please refer to Annex B for more The tightening torque is 3-7 Nm (2.2-5.2 ft-lbs). (www.canadiansolar.com). For information about details. other installation hardware, please contact your · Each module must be securely fastened at a local representative. -
Page 6: Maintenance
· Rev 3.4 was amended and released in Mar, 2016. · Rev 3.5 was amended and released in June, 2016. Maximum Load: Compatible module type: CS6U-xxxP and CS6U- By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019 xxxM EN-Rev IM/UL-AM-EN/3.5 Copyright © June 2016. Canadian Solar Inc. www.canadiansolar.com... - Page 7 By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019 CANADIAN SOLAR INC. 545 Speedvale Avenue West, Guelph, Ontario, Canada N1K 1E6 www.canadiansolar.com...
- Page 8 P-119147 DIRECTORY OF PAGES SCOPE OF WORK PV-1 PROJECT SUMMARY THIS PROJECT INVOLVES THE INSTALLATION OF A PHOTOVOLTAIC POWER SYSTEM. SOLAR PANELS WILL BE PV-2 SITE PLAN RACKED USING A PREENGINEERED RACKING SYSTEM FROM IRONRIDGE. THE RACKED MODULES WILL BE ELECTRICALLY PV-3 SINGLE-LINE DIAGRAM CONNECTED WITH DC TO AC POWER MICROINVERTERS AND...
- Page 9 P-119147 GENERAL NOTES EQUIPMENT LIKELY TO BE WORKED UPON WHILE ENERGIZED SHALL BE INSTALLED IN LOCATIONS THAT SATISFY MINIMUM WORKING CLEARANCES PER NEC 110.26. CONTRACTOR SHALL USE ONLY COMPONENTS LISTED BY A NATIONALLY RECOGNIZED TESTING LABORATORY FOR THE INTENDED USE. CONTRACTOR IS RESPONSIBLE FOR FURNISHING ALL EQUIPMENT, CABLES, ADDITIONAL CONDUITS, RACEWAYS, AND OTHER ACCESSORIES NECESSARY...
-
Page 10: Single-Line Diagram
PM1-56 P-119147 GENERAL•ELECTRICAL•NOTES MODULES 320W MODULE REF. QTY. MAKE AND MODEL PMAX TEMP. COEFF. OF VOC FUSE RATING UTILITY HAS 24-HR UNRESTRICTED ACCESS TO ALL -0.116V/°C (-0.29%/°C) PM1-56 CANADIAN SOLAR CS3K-320MS KUBLACK 320W 293W 10.14A 9.61A 40.1V 33.3V PHOTOVOLTAIC SYSTEM COMPONENTS LOCATED AT THE MICRO- INVERTERS SERVICE ENTRANCE. -
Page 11: Safety Labels
P-119147 LABELING NOTES MSP - MAIN SERVICE PANEL SEE NOTE NO. 4 (MSP) POINT-OF-INTERCONNECTION OR AT MAIN SERVICE DISCONNECT (MSP) (CUTLER HAMMER) ALL PLAQUES AND SIGNAGE REQUIRED BY 2017 NEC AND 2015 IFC WILL BE INSTALLED AS REQUIRED. PHOTOVOLTAIC SYSTEM EQUIPPED ! CAUTION ! LABELS, WARNING(S) AND MARKING SHALL COMPLY WITH RAPID SHUTDOWN... - Page 12 P-119147 GROUND ARRAY DOC ID: 119147-150145-0 8/9/19 DATE: L.V. CREATOR: L.V. REVIEWER: By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019...
- Page 13 P-119147 GROUND ARRAY DESIGM DOC ID: 119147-150145-0 8/9/19 DATE: L.V. CREATOR: L.V. REVIEWER: By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019...
- Page 14 P-119147 SITE IMAGES DOC ID: 119147-150145-0 8/9/19 DATE: L.V. CREATOR: L.V. REVIEWER: By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019...
- Page 15 By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019...
- Page 16 2. Wire, Conduit, and OCPD Code Compliance Validation Conductor, Conduit, and OCPD Sizing Validation 2.1. #1: AC Combiner Output: AC Combiner to Main Service Panel 1. Maximum System Voltage Test 1.1. Enphase inverter w/56 Canadian Solar CS3K-320MS KuBlack (320W)s F. Minimum Required EGC Size 2 AWG Circuit Section Properties see 250.122(B)
- Page 17 * For detailed information, please refer to the Installation Manual. instructions before using our PV modules. CANADIAN SOLAR INC. 545 Speedvale Avenue West, Guelph, Ontario N1K 1E6, Canada, www.canadiansolar.com, support@canadiansolar.com CANADIAN SOLAR INC. 545 Speedvale Avenue West, Guelph, Ontario N1K 1E6, Canada, www.canadiansolar.com, support@canadiansolar.com Feb.
- Page 18 Enphase IQ 7 and IQ 7+ Microinverters Data Sheet Enphase Microinverters INPUT DATA (DC) IQ7-60-2-US / IQ7-60-B-US IQ7-60-2-US / IQ7-60-B-US IQ7PLUS-72-2-US / IQ7PLUS-72-B-US Region: AMERICAS Commonly used module pairings¹ 235 W - 350 W + 235 W - 440 W + Module compatibility 60-cell PV modules only 60-cell and 72-cell PV modules...
- Page 19 By Ron Bull (rbull@co.walla-walla.wa.us) at 2:53 pm, Sep 16, 2019...
