- Page 1 INSTALLATION MANUAL OF REPLACEMENT SOLAR MODULES For professional use only...
-
Page 2: Table Of Contents
2 | GENERAL INFORMATION INSTALLATION MANUAL DISCLAIMER LIMITATION OF LIABILITY SAFETY PRECAUTIONS MECHANICAL / ELECTRICAL SPECIFICATIONS UNPACKING AND STORAGE MODULE INSTALLATION MODULE WIRING GROUNDING MOUNTING INSTRUCTIONS MOUNTING METHOD: BOLTING MAINTENANCE | 12 | 13 ANNEX A: ALTERNATIVE MOUNTING METHODS | 13 MOUNTING METHOD A: CLAMPING MOUNTING METHOD B: INSERTION SYSTEMS MOUNTING METHOD C: SINGLE-AXIS TRACKER... -
Page 3: General Information
| 3 GENERAL INFORMATION SAFETY PRECAUTIONS Warning This general manual provides important safety infor- mation relating to the installation, maintenance and Before attempting to install, wire, operate handling of CS-series solar modules. and / or service the module and other electrical equipment, all instructions should be Professional installer must read these guidelines read and understood. -
Page 4: Mechanical / Electrical Specifications
4 | dule storage area. MECHANICAL / ELECTRICAL SPECIFICA- · Use electrically insulated tools to reduce the risk of TIONS electric shock. · If the disconnects and over current protection devices Module electrical ratings are measured under Stan- (OCPDs) cannot be opened or the inverter cannot be dard Test Conditions (STC) of 1000 W/m2 irradiance, powered down, cover the fronts of the modules in the with an AM1.5 spectrum, and a cell temperature of... -
Page 5: Unpacking And Storage
| 5 Alternatively, a more accurate correction factor for the open-circuit voltage can be calculated using the · Stacks of modules should contain no more than 12 following formula: modules, and the frames should be aligned. · Do not place excessive loads on the module or twist = 1-α... -
Page 6: Module Installation
6 | unique serial number containing 13 (pre-March 2013) acceptable for use with CSI Solar Co., Ltd. modules, or 14 (post-March 2013) digits. provides the mounting system does not violate any other requirements of this manual. · A nameplate is also affixed to the rear of each module. This nameplate specifies the model type, as well as the ·... - Page 7 | 7 INSTALLATION REQUIREMENTS · To minimize risk in the event of an indirect lightning strike, avoid forming loops with the wiring when desig- · Ensure that the module meets the general technical ning the system. system requirements. · The recommended maximum series fuse rating is ·...
-
Page 8: Module Wiring
8 | · Only use dedicated solar cable and suitable connectors (wiring should be sheathed in a sunlight-resistant con- MODULE WIRING duit or, if exposed, should itself be sunlight-resistant) that meet local fire, building and electrical regulations. CORRECT WIRING SCHEME Please ensure that all wiring is in perfect electrical and mechanical condition. -
Page 9: Mounting Instructions
| 9 tion should comply with all applicable local electrical · CSI Solar Co., Ltd. does not provide grounding hard- codes and regulations. Grounding connections should ware. be installed by a qualified electrician. Connect module frames together using adequate grounding cables: we ·... -
Page 10: Mounting Method: Bolting
10 | by CSI Solar Co., Ltd. for special module ranges, please · Modules should be bolted to supporting structures refer to the Annex A (Alternative Mounting Methods) of through the mounting holes in the rear frame flanges this installation manual. For information about other in- only. - Page 11 | 11 Table 5: Approved bolting methods Bolting on the short frame side using four standard Bolting on the short frame side using four standard mounting holes. Mounting rails run perpendicularly to mounting holes. Mounting rails run parallel to the the long frame side.
-
Page 12: Maintenance
12 | MAINTENANCE · Do not make modifications to any component of the PV module (diode, junction box, plug connectors or others). · Regular maintenance is required to keep modules clear of snow, bird droppings, seeds, pollen, leaves, bran- ches, dirt spots, and dust. ·... -
Page 13: Annex A: Alternative Mounting Methods
| 13 ANNEX A: ALTERNATIVE MOUNTING METHODS · All the basic requirements of the main installation are found. When installing inter-modules or end-type manual should also apply to alternative mounting clamps, please take the following measures into ac- methods, unless otherwise specified. count: ·... - Page 14 14 | CS6XH-P and CS6XH-M Use four clamps on the long side. Mounting rails Use four clamps on the long side. Mounting rails run perpendicularly to the long side frame. run parallel to the long side frame. A1 range = (410 – 490) mm A1 range = (340 –...
- Page 15 | 15 CS6PH-P, CS6PH-M Use four clamps on the long side. Mounting rails Use four clamps on the long side. Mounting rails run perpendicularly to the long side frame. run parallel to the long side frame. A1 range = (0 – 239) mm Maximum Load: Uplift load ≤...
- Page 16 16 | CS5PH-P, CS5PH-M Use four clamps on the long side. Mounting rails run perpendicularly to the long side frame. A1 range = (220 – 390) mm Maximum Load: Uplift load ≤ 2400 Pa Downforce load ≤ 2400 Pa A1 range = (330 – 400) mm Maximum Load: Uplift load ≤...
-
Page 17: Mounting Method B: Insertion Systems
| 17 MOUNTING METHOD B: Do not bend the module frame. INSERTION SYSTEMS Do not touch the front glass or cast shadow onto it. Do not damage the surface of the frame. The mounting method has been qualified by CSI Solar Ensure that the insertion profiles overlap the module Co., Ltd., as well as certified by VDE and CSA. - Page 18 18 | CS6PH-P and CS6PH-M Use two insertion profiles running parallel to the long Use two insertion profiles running perpendicularly to side frame. the long side frame. Maximum Load: Maximum Load: Uplift load ≤ 2400 Pa Uplift load ≤ 2000 Pa Downforce load ≤...
-
Page 19: Mounting Method C: Single-Axis Tracker
| 19 Use two insertion profiles running perpendicularly to the long side frame. An additional support bar should be placed below the module. Use two clamps on the support bar. Maximum Load: Uplift load ≤ 2400 Pa Downforce load ≤ 5400 Pa MOUNTING METHOD C: SINGLE-AXIS TRACKER CSI Solar Co., Ltd. -
Page 20: Annex B: Mechanical And Electrical Ratings
20 | ANNEX B: MECHANICAL AND ELECTRICAL RATINGS Standard Test Conditions are: Irradiance of 1000 W/ ±10% or [0; +5W] of the indicated values for Isc, Voc , AM1.5 spectrum, and cell temperature of 25°C. and Pmax. Specifications are subject to change wi- The electrical characteristics are respectively within thout notice. - Page 21 | 21 Open Short Maximum Operating Operating Max. Series Overall Circuit Circuit Weight Module Type Power voltage current Fuse Dimension Voltage Current <kg> Pmax <W> Vmp <V> Imp <A> Rating <A> <mm> Voc <V> Isc <A> CS6PH-280M 30.0 9.34 36.5 9.96 CS6PH-285M 30.3...
-
Page 22: Annex C: Module Cleaning Guidelines
22 | ANNEX C: MODULE CLEANING GUIDELINES This manual covers the requirements for the clea- dule backsheet or frame to come in contact with sharp ning procedure of CSI Solar Co., Ltd.‘s photovoltaic objects, as scratches may directly affect product safety. modules. -
Page 23: Amended Editions And Dates
| 23 If excessive soiling is present on the module surface, a non-conductive brush, sponge, or other mild agita- ting method may be used with caution. · Ensure that any brushes or agitating tools are const- ructed with non-conductive materials to minimize risk of electric shock and that they are not abrasive to the glass or the aluminum frame.
