COLD MODE:

- Press mode to select cold mode, the cold
mode indicator will light up.
- Press + or - to set the temperature in a range of
16 ~ 31 ° C (61 ~ 88 ° F).
- Pressing + or - once, the temperature will
increase or decrease gradually.
- Press (E) to select high or low fan speed.
- heating MODE:
- Press mode to select heating mode, the hea-
ting mode indicator will light up.
- Press + or - to set the temperature in a range of
16 ~ 31 ° C (61 ~ 88 ° F).
- Pressing + or - once, the temperature will
increase or decrease gradually.
- Press (E) to select high or low fan speed.
(*) Only available in Temp Design and Temp
Design + model
FAN MODE:
- Press mode (D) to select the fan mode and the
fan indicator will light up. Press (E) Speed to
increase or decrease power speed.

DEHUMIDIFIER MODE:

- Press (D) to select the mode
- Dehumidification mode indicator, and the dehu-
midification mode indicator will light up.

TIMER FUNCTION:

SETTING THE TIMER ON:
- When the air conditioner is off, press the "F"
button and select the desired power-on time
through the temperature and time adjustment
buttons.
- The on time can be set up to 24 hours.
- The programmed time or remaining time will
appear in the display (G).
SETTING THE TIMER OFF:
- When the air conditioner is on, press the
"F" button and select the desired sleep time
through the temperature and time adjustment
buttons.
- The shut-off time can be set up to 24 hours.
- The programmed time or remaining time will
appear in the display (G).
COMPRESSOR PROTECTION:
- Three minutes after pressing on / restarting,
the compressor will start to operate.
PROTECTION OF THE WATER TANK:
- When the water level in the lower water plate
is below the warning level, the appliance will
notify you automatically.
- Please pour the water in the machine accor-
ding to the instructions in the chapter "water
drainage".

WATER DRAINAGE:

- This machine has two drainage methods:
manual drainage (fig 8) and continuous draina-
ge(fig 9).
- When the inside of the water tank is full, the
indicator will light up on the display.
- The device enters the standby mode.
- Remove the plug to remove the water, turn the
machine off and on again, the machine will
operate normally.
- This model has a self-evaporating function, in
the cold mode, please do not make continuous
drains to get a greater effect of cold.
- Once the appliance has been used:
- Stop the appliance by pressing button (A) on
/ off
- Unplug the appliance from the mains.
- Unplug the appliance from the mains and allow
it to cool down before starting any cleaning
operation.
- Clean the electrical assembly and the mains
plug with a damp cloth and dry them after-
wards. NEVER SUBMIT THEM IN WATER OR
ANY OTHER LIQUID.
CLEANING
- Wipe the appliance with a damp cloth impreg-
nated with a few drops of detergent. Do not use
solvents or products with an acidic or basic pH
factor such as bleach or abrasive products to
clean the apparatus.
- Do not immerse the connector in water or other
liquid or place it under the tap. If the appliance
is not maintained in good condition
- Cleaning the air filter:
- Clean the air filters every 2 weeks. If the air
filter is blocked with dust, its effectiveness will
be reduced.
