Related Manuals for Frico SIReAC
Summary of Contents for Frico SIReAC
- Page 1 Original instructions SIRe Competent Air Curtains Water With quick guide SIReAC ..36 ..2 ..19 ..54 For wiring diagram, please see p.71-73 For more languages, please see www.frico.se...
-
Page 2: Connect The System
SIRe Competent Air Curtains Water Enter ID Quick guide / Start up The control system can control one or more Check that all constituent parts are present units in parallel (max 9). Each unit must have (see section Constituent parts). a unique ID number (1-9) which is set in the ID selector of the PC board. -
Page 3: Table Of Contents
Advice about location Connect the system Wiring diagram Enter ID Start up Constituent parts SIReAC Option Water control - valve package Operating modes Door that is opened and closed Doors that are always or often left open for longer periods... -
Page 4: Constituent Parts
SIRe Competent Air Curtains Water Constituent parts SIReAC Integrated in the air curtain SIReIT, SIReUA1, Wall unit SIReB1, internal control unit cover integrated temperature Competent and PC board Base sensors Advanced SIReC1X, SIReDC, magnetic SIReCC, PC Board HUB door contact... - Page 5 SIRe Competent Air Curtains Water Option SIReCC, SIReRTX, external SIReUR, kit SIReCJ6, SIReCJ4, modular cables room temperature for recessed joint piece joint piece sensor installation Type RSK-no. E-no. Description HxWxD [mm] SIReRTX 673 09 22 87 510 12 External room temperature sensor 70x33x23 673 09 21 87 510 11...
-
Page 6: Water Control - Valve Package
SIRe Competent Air Curtains Water Water control - valve package SD230 TBVC BPV10 SD230 TBVCMP Water control - option BPV10 VAT, adjustment tool for valve package Type RSK-no. Description Flow Connection VOS15LF 673 09 35 On/off DN15 VOS15NF 673 09 36 On/off Normal DN15... -
Page 7: Operating Modes
SIRe Competent Air Curtains Water Operating modes has been closed, high speed mode remains to cool the unit from any excess heat during the fixed time that is set under Installer menu > Door that is opened and closed Settings fan > Door over run > High speed The control function notes whether the door over run and at low speed during a fixed is open or closed as standard, this mode is... -
Page 8: Function Description Of Current Stage
SIRe Competent Air Curtains Water Function description of current stage Summer If summer mode is selected under Main Menu The task of the Current stage function is to > Summer / Winter, heating is blocked. balance the room climate when a door is •... - Page 9 SIRe Competent Air Curtains Water Table - Current stage for units with 5 fan controls Current Heating stage Table - Current stage for units with 3 fan controls Current Heating stage...
-
Page 10: Control Unit Sireua1 Overview
SIRe Competent Air Curtains Water Control unit SIReUA1 Overview Status window °C Status window DOOR Forward arrow Back arrow Rotary dial Fan step Heating step Week program: Week program: Alarm Night Red LED Week program: Mode Out of operation Green LED Explanations Status window Status window... -
Page 11: Main Menu
SIRe Competent Air Curtains Water Main menu Summer / Winter To permit or block heating. Heating is Current settings permitted in winter mode. Summer mode is displayed with a crossed out heating symbol Displays set room temp, high speed limit, in the status window. -
Page 12: Installer Status Screen
SIRe Competent Air Curtains Water Installer menu To check which days a certain program is active, select a week day by pressing the To enter the Installer menu, code 1932 is forward arrow, the program is marked and entered. Select the digits using the rotary dial those days that the program is used will be and confirm using the forward arrow. -
Page 13: Settings Fan
SIRe Competent Air Curtains Water Week program is activated by selecting On, Factory setting: under Week program on/off. In On-mode, Over run mode: Auto (Set time) a sun, moon or Off in the Status window High speed over run: 30 s (0 – 180 s) appears to indicate day, night respectively Low speed over run: 120 s (0 –... -
Page 14: Filter Guard Settings
SIRe Competent Air Curtains Water Calibration sensors Filter timer on/off If the sensor displays the wrong values these Filter alarm is activated by selecting On, can be calibrated. Some display errors may under Filter timer on/off. occur, but this is primarily due to the location (cold/hot surfaces etc). -
Page 15: General Settings
Summer/ Winter) to factory setting. Support menu The Support menu is password protected and is used for support in contact with Frico or > Installer menu > General > Installer menu > User reset settings authorised service personnel. -
Page 16: Alarm And Error Codes
See Table - Alarms and Table – the fault cause cannot be found contact Error codes. authorised service personnel or Frico. Reset alarm Note! Before resetting, check that the fault is rectified and there is nothing to prevent the... - Page 17 Fault on or missing internal sensor Check connection of the sensor. If there is no faults in the unit (applies to units with sensor, contact Frico for support. internal sensor). E10 ID Error Two or more SIReB1 (X) in the Contact Frico for support.
-
Page 18: Connecting External Control - Including Bms Functions
SIRe Competent Air Curtains Water Connecting external control - including BMS functions SIReC1X External night reduction External alarm IN Ext. speed ctrl. 0-10V DC IN External ON/OFF Door switch ALARM OUT (BMS) External night reduction External on/off 5-30V AC/DC External signal activates the air on/off (potential-free switch) Closes to activate the night curtain. -
Page 19: Wiring Diagram
SIRe Competent Air Curtains Water ALARM OUT (BMS) (potential free contact, max 3A, 230V) EXTERNAL ON/OFF 5-30V AC/DC EXTERNAL RPM 0-10V DC IN EXTERNAL ALARM IN (potential free contact) EXTERNAL SETBACK TEMP. ON/OFF (potential free contact) - Page 20 SIRe Competent Air Curtains Water ALARM OUT (BMS) (potential free contact, max 3A, 230V) EXTERNAL ON/OFF, 5-30V AC/DC EXTERNAL RPM 0-10V DC IN EXTERNAL ALARM IN (potential free contact) EXTERNAL SETBACK TEMP. ON/OFF (potential free contact)
- Page 21 SIRe Competent Air Curtains Water ALARM OUT (BMS) (potential free contact,max 3A, 230V) DOOR CONTACT (potential free contact) EXTERNAL ON/OFF, 5-30V AC/DC EXTERNAL RPM 0-10V DC IN EXTERNAL ALARM IN (potential free contact) EXTERNAL SETBACK TEMP. ON/OFF (potential free contact)
- Page 22 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 Fax: +46 31 26 28 25 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
