Connecting the
Internet Phone
Wizard Hardware
This chapter explains how to physically connect the Internet Phone Wizard to
a computer, telephone, and phone line. There are two basic ways to connect the
Internet Phone Wizard: Single Line or Dual Line.

Single Line Connection

When the Internet Phone Wizard is in Single Line mode, it can be used to make or
receive Internet (computer-to-computer) phone calls using Skype only. It cannot
make regular calls to normal (land-line or mobile) telephones while in Single Line
mode.
To connect the Internet Phone Wizard in Single Line mode:
1. Get the Internet Phone Wizard from its package.
2. Get the
cable from the package and insert the small, square end of the
USB
cable in the "
USB
3. Insert the other (flat and rectangular) end of the
the front or back of a computer.
4. Get the phone cable from the telephone and insert one end in the "Phone"
port on the rear panel of the Internet Phone Wizard.
5. Connect the other end of the phone cable to the telephone. The components
should be connected similarly to the figure below:
" port on the rear panel of the Internet Phone Wizard.
USB
15
3
cable in a port on
USB
